Vestil PAL-D Owner's Manual

VESTIL MANUFACTURING CORPORATION
2999 North Wayne St., Angola, IN 46703
Phone (260) 665-7586 • Fax (260) 665-1339
E-mail: sales@vestil.com • www.vestil.com
Fork Truck Attachments
Contents
Safety Instructions for the Operator ................ 2
Installation Instructions .................................... 2
Operation Instructions ..................................... 2
Loading Instructions ........................................ 2
FAILURE TO READ AND COMPLY WITH OWNER'S MANUAL MAY RESULT IN ACCIDENT, LOSS, DAMAGE, INJURY OR DEATH!
WARNINGS & SAFETY INSTRUCTIONS
Read owner's manual completely before operating unit!
• Read and understand the owner's manual before using the
pallet dumper/retainer.
• Ensure that all safety and warning labels stay in place and
are legible. See the labels page in this manual.
• Observe all applicable OSHA laws regulating the use of this
Fork Truck Attachment.
• Secure the pallet dumper/retainer to the forklift mast using
the provided restraint strap before use.
• Never operate the pallet dumper / retainer unless you are
watching it.
• Never use the pallet dumper / retainer if the cradle is in need
of repairs or in the case of a malfunction.
• Do not stand below any part of a raised pallet dumper /
retainer.
• Never exceed the 2000 pound maximum loading capacity of
the pallet dumper/retainer.
• Consult factory for uneven loading or overhung loading.
• When elevation is not required, always transport the
pallet in the lowered position.
• Always transport pallet only in horizontal position when
fork truck is moving.
• Do not allow pallet to impact the floor, ground, or dumping
station etc., or there may be damage to the unit.
• Remove pallet and all loads before working on unit.
• Consult factory if adding or performing any modification
to the original equipment.
• Use only maintenance parts supplied or approved by the
manufacturer.
Revised 11-07
A company dedicated to solving ergonomic and
material handling problems since 1955 .
OWNER'S
MANUAL
PALLET DUMPER / RETAINER
PAL-D/R
Routine Maintenance ....................................... 3
Location of Center of Gravity............................ 4
Safety Label Identification ................................ 5
Warranty ........................................................... 6
• Not to be used as a personnel lift.
• WARNING : Never use the platform to lift or support any type
of structural load.
• Fork truck manufacturers are to be consulted when
accessories are used that affect the truck's capacity and safe
operation. The unit's load-loss and center-of-gravity will be
made available on request. See OSHA 1910.178(a)5.
RECEIVING INSTRUCTIONS
Every unit is thoroughly tested and inspected prior to
shipment. However, it is possible that the unit may incur
damage during transit. If damage is noticed when unloading,
make a note of it on the BILL OF LADING. Remove all packing
and strapping material, then inspect the unit again for damage.
IF DAMAGE IS EVIDENT, FILE A CLAIM WITH THE CARRIER
IMMEDIATELY!
PAL-D/R
