Enterasys Matrix X Router Installation Manual page 37

Table 2-3 Module Power Specifications
Module
CM
Fan tray
X4-FM
X8-FM
X16-FM
X-GT16-00
X-T32-00
X-G32-00
X-M2-00
X-M8-01
1. The actual power draw of the X-GT16-00 is 105 Watts. However, for the purposes of budgeting the
number of power supplies required, use 155 Watts.
Table 2-4 Redundancy Configurations for DC Power Supply
No. of Power Supplies
2
3
4
4
5
6
6
1. The sum of individual power draws for all installed fan trays, control and fabric modules, and IOMs.
Power (Watts)
97 Watts
85 Watts
30 Watts
62 Watts
98 Watts
1
155 Watts
155 Watts
155 Watts
155 Watts
190 Watts
Max Redundant System Load
1500 Watts
3000 Watts
3000 Watts
4500 Watts
6000 Watts
4500 Watts
6000 Watts
Matrix X Router DC Power Supply Installation Guide 2-3
Power Supply Redundancy
@ 48 VDC
Thermal Output (BTU/HR)
331.1 BTU/HR
290.1 BTU/HR
102.4 BTU/HR
211.6 BTU/HR
334.5 BTU/HR
520.0 BTU/HR
520.0 BTU/HR
520.0 BTU/HR
520.0 BTU/HR
648.0 BTU/HR
1
Redundancy Configuration
N + 1
N + 1
N + 1
N + 1
1 + 1
1 + 1
1 + 1
