SecureStack C2
Redundant Power System
C2RPS-SYS
Installation Guide
Caution:
Do not use this product with SecureStack C2 PoE devices. Any SecureStack
C2 device with a "P" suffix in the model number (C2xxxx-xxP) indicates a SecureStack
C2 PoE-compliant device and is not compatible with this power system.
Precaución:
El RPS no es compatible con switches SecureStack C2 con PoE. No
intente conectar el cable de corriente del RPS a ningún switch SecureStack C2 que
tenga el sufijo "P" en el nombre del modelo, tal como C2xxxxx-xxP. De lo contrario, el
dispositivo puede dañarse.
9033977-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enterasys C2RPS-SYS
Summary of Contents for Enterasys C2RPS-SYS
-
Page 1: Installation Guide
SecureStack C2 Redundant Power System C2RPS-SYS Installation Guide Caution: Do not use this product with SecureStack C2 PoE devices. Any SecureStack C2 device with a “P” suffix in the model number (C2xxxx-xxP) indicates a SecureStack C2 PoE-compliant device and is not compatible with this power system. - Page 3 Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2005 Enterasys Networks, Inc. All rights reserved. Part Number: 9033977‐01 April 2005 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS MATRIX, LANVIEW, MATRIX, NETSIGHT, WEBVIEW, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals...
-
Page 4: Product Safety
Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Notice This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia ... - Page 5 Electromagnetic Compatibility (EMC) This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. Compatibilidad Electromágnetica (EMC) Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 89/336/EEC, EN 55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 6: Declaration Of Conformity
Application of Council Directive(s): 89/336/EEC European Representative Address: Enterasys Networks, Ltd. Conformance to Directive(s)/Product Standards: EC Directive 89/336/EEC Equipment Type/Environment: Networking Equipment, for use in a Commercial Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. Declaration of Conformity 73/23/EEC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 73/23/EEC EN 60950 or Light Industrial Environment. - Page 7 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc. on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware installed on the Enterasys product (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, or other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, and supersedes all prior discussions, representations, understandings or agreements, whether oral or in writing, between the parties with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program provided in this package subject to the terms and conditions of this Agreement. RESTRICTIONS. Except as otherwise authorized in writing by Enterasys, You may not, nor may You permit any third party to: (i) Reverse engineer, decompile, disassemble or modify the Program, in whole or in part, including for reasons of error correction or interoperability, except to the extent expressly permitted by applicable law and to the extent the parties shall not be permitted by that applicable law, such rights are expressly excluded. Information necessary to achieve interoperability or correct errors is available from Enterasys upon request and upon payment of Enterasys’ applicable fee. (ii) Incorporate the Program, in whole or in part, in any other product or create derivative works based on the ...
- Page 8 APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions. You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the 1980 United Nations Convention on Contracts for the International Sale of Goods, the United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the Program is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China, Romania, Russia, Rwanda, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202‐3 and its successors, and use, duplication, or disclosure by the Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO YOU IN WRITING BY Enterasys, Enterasys DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON‐ INFRINGEMENT WITH RESPECT TO THE PROGRAM. IF IMPLIED WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THIRTY (30) DAYS AFTER DELIVERY OF THE PROGRAM TO YOU. ...
- Page 9 AUDIT RIGHTS. You hereby acknowledge that the intellectual property rights associated with the Program are of critical value to Enterasys and, accordingly, You hereby agree to maintain complete books, records and accounts showing (i) license fees due and paid, and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and its authorized representatives, upon reasonable notice, the right to audit and examine during Your normal business hours, Your books, records, accounts and hardware devices upon which the Program may be deployed to verify compliance with this Agreement, including the verification of the license fees due and paid Enterasys and the use, copying and deployment of the Program. Enterasys’ right of examination shall be exercised reasonably, in good faith and in a manner calculated to not unreasonably interfere with Your business. In the event such audit discovers non‐compliance with this Agreement, including copies of the Program made, used or deployed in breach of this Agreement, You shall promptly pay to Enterasys the appropriate license fees. Enterasys reserves the right, to be exercised in its sole discretion and without prior notice, to terminate this license, effective immediately, for failure to comply with this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock or assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to ...
- Page 10 viii...
-
Page 11: Table Of Contents
Guidelines for Rackmount Installation ...2-4 Rack Mounting the Chassis ...2-5 Connecting the PSM Cables and AC Power Cords ...2-6 Appendix A: Specifications C2RPS-CHAS8 Chassis Specifications ... A-1 C2RPS-PSM Specifications ... A-2 C2RPS-PSM Redundant Power Supply Output Connector ... A-2 Compliance Standards ... A-3 Contents... - Page 12 Fastening the C2RPS-CHAS8 to the Rack ...2-6 C2RPS-PSM Cable...2-7 Power Connectors on C2RPS-PSM (rear view)...2-7 C2RPS-PSM Cable and AC Power Cord Connections...2-8 C2RPS-PSM Redundant Power Supply Connector Pin Locations ... A-2 Tables Contents of C2RPS-CHAS8 Carton...2-2 Contents of C2RPS-PSM Carton ...2-2 C2RPS-CHAS8 Specifications...
-
Page 13: About This Guide
Note: In this document, the following terms are used: • RPS refers to the complete SecureStack C2RPS-SYS redundant power system. • Chassis refers to the C2RPS-CHAS8 chassis. • PSM refers to the C2RPS-PSM power supply module. • PSM cable refers to the C2RPS-PSM Cable (12 Vdc power cable). -
Page 14: Using The Securestack C2 Manual Set
Using the SecureStack C2 Manual Set Using the SecureStack C2 Manual Set Other manuals have been developed for the SecureStack C2 non‐PoE switch devices that can be connected to the RPS for power redundancy. Caution: The RPS does not support PoE-compliant SecureStack switches. Do not try to connect the power cable from this RPS to any SecureStack switch with a “P” suffix in the model name, such as C2xxxxx-xxP. -
Page 15: Conventions Used In This Guide
Conventions Used in This Guide Conventions Used in This Guide The following conventions are used in this guide: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. Precaución: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen. - Page 16 Conventions Used in This Guide xiv About this Guide...
-
Page 17: Chapter 1: Introduction
This chapter provides a functional overview of the Redundant Power System (RPS), which includes the following: For information about... RPS Overview C2RPS-CHAS8 Chassis C2RPS-PSM Power Supply Module RPS Deployment Strategies Getting Help Overview The RPS provides a simple and economical solution for providing a backup power source for up to eight SecureStack Ethernet switch devices. When a PSM is connected to a switch device, the PSM continuously monitors the internal power supply of the switch device. If a power interruption is detected, the PSM is automatically triggered to provide power for the switch device, preventing an interruption in network traffic. The end result is a more reliable network infrastructure, protecting the network from a single source of failure from a network device power supply. Depending on your system requirements, the RPS can consist of the following components to support up to eight switch devices: • One C2RPS‐CHAS8 chassis • Up to eight C2RPS‐PSM • Up to eight AC power cords (one per C2RPS‐PSM) • Up to eight C2RPS‐PSM Cables (one per C2RPS‐PSM) Note: The chassis is shipped with one PSM. Additional PSMs are ordered separately. -
Page 18: C2Rps-Chas8 Chassis
RPS Overview C2RPS-CHAS8 Chassis The chassis is a an eight‐slot frame without AC power connections or electronics. The chassis can be installed in a standard 19‐inch rack and populated with up to eight PSMs. Each PSM operates independently. Figure 1‐1 shows the front view of the chassis with covers only; Figure view if the chassis was fully populated with PSMs. Figure 1-1 1 Power supply slot cover (8) Figure 1-2 _______________________________________________________________________________ 1-2 Introduction SecureStack C2RPS-CHAS8 (front view without PSMs) À Á SecureStack C2RPS-CHAS8 (rear view with eight PSMs) 1‐2 shows the rear 2 Captive screw (2 per cover) -
Page 19: C2Rps-Psm Power Supply Module
C2RPS-PSM Power Supply Module The PSM provides the following: • Hot swap capability. • One 12 Vdc, 150 Watts of maximum‐continuous power output to a connected SecureStack C2 switch device. • Front panel Status LED that indicates if the PSM is operating correctly. Figures 1‐3 and 1‐4 show the front and rear view of the C2RPS‐PSM. Figure 1-3 C2RPS-PSM (front view) Â Intake cooling fans AC power LED Figure 1-4 C2RPS-PSM (rear view) Redundant Power Supply connector (12 Vdc and PSM status outputs) À... -
Page 20: Rps Deployment Strategies
RPS Deployment Strategies RPS Deployment Strategies The RPS can be deployed in a variety of situations with mission‐critical applications. For example: • For use in a voice and data network where switches are connected to IP phones and PCs. Connecting an RPS to the switches can prevent voice network failures caused by switch failures. • For use in traditional data 10/100/1000 Ethernet switches carrying mission‐critical data. These applications would typically use one RPS to support up to eight SecureStack C2 switch devices as shown in Figure internal power‐supply failure, the following occurs: The SecureStack C2 switch device internal DC‐power source is immediately switched over from the internal DC‐power supply to the RPS DC‐power input. The SecureStack C2 switch device saves this status information for future retrieval, if necessary. Figure 1-5 À 1 C2RPS-CHAS8 chassis (front view with eight PSMs) 2 C2RPS-PSM Cables for 12 Vdc and status information from PSMs 1-4 Introduction 1‐5. If a SecureStack C2 switch device experiences an ... -
Page 21: Getting Help
• Any previous Return Material Authorization (RMA) numbers http://www.enterasys.com/support 603-332-9400 1-800-872-8440 (toll-free in U.S. and Canada) For the Enterasys Networks Support toll-free number in your country: http://www.enterasys.com/support/gtac-all.html support@enterasys.com To expedite your message, please type [C-SERIES] in the subject line. Getting Help SecureStack C2 Installation Guide 1-5... - Page 22 Getting Help 1-6 Introduction...
-
Page 23: Chapter 2: Installation
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. This chapter provides the installation instructions to install all the components of an RPS. To correctly install an RPS, follow the order of information listed below. For information about... Required Tools Unpacking Chassis and Power Supply Module(s) Installing C2RPS-PSMs Installing C2RPS-CHAS8 into the Rack Connecting the PSM Cables and AC Power Cords Required Tools A flat‐blade screwdriver is required to install the C2RPS‐CHAS8 and C2RPS‐PSMs. -
Page 24: Installing C2Rps-Psms
C2RPS-CHAS8 SecureStack C2 Redundant Power System Installation Guide (9033977-xx) Release Notes Table 2-2 Contents of C2RPS-PSM Carton Item C2RPS-PSM 150 Watt DC Power Supply Module USA, NEMA Power Cord C2RPS-PSM Cable Notice Card Installing C2RPS-PSMs Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic equipment. -
Page 25: Replacing An Installed C2Rps-Psm
Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precaucionesde seguridad para evitar descargas de electricidad estática. Unplug the AC power cord of the PSM from the AC power source first, then from the rear of the PSM. Loosen the captive screws securing the PSM until it is released from the chassis front panel. Installing C2RPS-PSMs  Á 3 Chassis power supply slot 4 Captive screws (2) SecureStack C2 Installation Guide 2-3 à Ã... -
Page 26: Installing C2Rps-Chas8 Into The Rack
Installing C2RPS-CHAS8 into the Rack Pull the PSM out and remove it from the chassis. Repeat steps 1 through 3 for each additional PSM you plan to remove. Note: If you plan to remove and not replace a C2RPS-PSM, immediately reinstall coverplates over any empty power supply slots to prevent EMI leakage from the chassis. To install a PSM, proceed as follows: Align the PSM with the slot, then slide the PSM forward until its front panel is flush against the chassis front panel. Fasten the PSM to the chassis using the captive screws. Perform steps 1 and 2 for each PSM being replaced. When completed, proceed to “Connecting the PSM Cables and AC Power Cords” on page 2‐6. -
Page 27: Rack Mounting The Chassis
• An ambient temperature of between 5°C (41°F) and 40°C (104°F) must be maintained at the installation site with fluctuations of less than 10°C (18°F) per hour. Caution: To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 101.6 cm (4.0 in.) at the front and rear of the chassis. Precaución: Para asegurar una buena ventilación y evitar que el sistema se sobrecaliente, deje un espacio mínimo de 10.16 cm (4 pulgadas.) con respecto a la parte delantera y trasera del chasis. -
Page 28: Connecting The Psm Cables And Ac Power Cords
Connecting the PSM Cables and AC Power Cords Figure 2-2 Â 1 C2RPS-CHAS8 chassis 2 Rails of 19-inch rack Connecting the PSM Cables and AC The PSMs are connected to the SecureStack Ethernet switch devices using PSM cables. To connect the PSMs, proceed as follows: Connect one end of the PSM cable (shown in Figure Supply connector on the switch device. Then connect the other end to the Redundant Power Supply connector at the rear of the PSM shown in Figure 2‐4 and Figure Connect a standard AC power cord to the AC input power connector on the PSM shown in Figure The green Power LED on the front of the PSM will glow to indicate a successful connection. If the LED remains off, proceed as follows: Check the AC power cord connection at the AC power source and make sure the power source is within specification. b. Check the AC power connection to the PSM. Swap the AC power cord with a known good one. d. -
Page 29: C2Rps-Psm Cable
Note: No change in switch configuration is necessary for this installation. Figure 2-3 C2RPS-PSM Cable Figure 2-4 Power Connectors on C2RPS-PSM (rear view) À 1 Redundant Power Supply connector Connecting the PSM Cables and AC Power Cords Á 2 AC power connector (rear of chassis) SecureStack C2 Installation Guide 2-7... -
Page 30: C2Rps-Psm Cable And Ac Power Cord Connections
2-8 Installation C2RPS-PSM Cable and AC Power Cord Connections À Â 4 Switch device Redundant Power Supply connector 5 AC power cord (type varies depending on country) 6 AC power outlet with ground connection (type varies depending on country) Ã... -
Page 31: Appendix A: Specifications
This appendix provides information about the following: For information about... C2RPS-CHAS8 Chassis Specifications C2RPS-PSM Specifications C2RPS-PSM Redundant Power Supply Output Connector Compliance Standards Enterasys Networks reserves the right to change the specifications at any time without notice. C2RPS-CHAS8 Chassis Specifications Table A‐1 provides the physical specifications for the C2RPS‐CHAS8. Table A-1 C2RPS-CHAS8 Specifications Item Power supply slots Dimensions without mounting brackets Net Weight (Unit Only) -
Page 32: C2Rps-Psm Specifications
Regulatory and Safety standards. The use of non-approved cables will void your warranty. Figure A-1 A-2 Specifications A‐2 for the input/output port specifications. C2RPS-PSM Redundant Power Supply Connector Pin Locations Specification 47 - 63 Hz 85 - 264 Vac 12 Vdc 1.0 A min., 8.5 A or 13.0 A max. -
Page 33: Compliance Standards
Table A-3 C2RPS-PSM Redundant Power Supply Connector Pin Functions Pin Number Compliance Standards The C2RPS‐PSM meets the safety and electromagnetic compatibility (EMC) requirements listed in Table Table A-4 Compliance Standards Item Safety Electromagnetic Compatibility (EMC) (Applies to RPS system with eight modules installed and working with eight network devices.) Function Ground... - Page 34 Compliance Standards A-4 Specifications...
