This chapter provides the DC power supply specifications and regulatory compliance
information.

Specifications

Table 2‐1 lists the physical specifications. Table
Table 2-1 Physical Specifications
Item
Dimensions
Weight
MBTF
Operating Temperature
Storage Temperature
Operating Relative Humidity
Table 2-2 Electrical Specifications
Item
DC Input
DC Output
Max Output Power
DC Power Supply Specifications
Specification
4.04 H x 13.87 W x 34.93 D (cm)
1.59 H x 5.46 W x 13.75 D (in.)
2.38 kg (5.25 lb)
1,026,237 hours
0°C to 55°C (32°F to 131°F)
-30°C to 73°C (-22°F to 164°F)
5% to 95% (non-condensing)
Specification
Rated -48 to -60 VDC
Min Operating Input Voltage = -40 VDC
Max Operating Input Voltage = -72 VDC
Min Operating Nominal Voltage = 36 V
Max Operating Nominal Voltage = 72 V
Min Load = 0 Amps
Max Load = 37.5 Amps
1500 Watts
2‐2 lists the electrical specifications.
Matrix X Router DC Power Supply Installation Guide 2-1
