- Page 1 Setup guide Model S10 Greenhouse only V4 / From January 2023 If you have a Smart Sprout please also use the smart setup guide whilst assembling your S10...
- Page 2 If you have any questions while setting up, send us an email (help@harvst.co.uk) or check out our forums: https://grow.harvst.co.uk Important information Sprout Mini Greenhouses are intended for outdoor use and should be secured to a fence or wall with the provided fixings. Harvst accept no liability for incorrectly used products.
-
Page 3: Exploded Diagram
Exploded diagram Tools provided Tools required (not supplied) 3mm allen key Tape measure to identify parts 8mm spanner Secateurs for cutting pipe Pozidrive screwdriver... - Page 4 Parts list (aluminium pieces) 450mm x2 580mm x2 Lid sides with corner cubes Rear top upright 450mm Rear assembly x1 Side panel crossbar 910mm uprights 2 pre installed screws per piece 600mm base Front assembly x1 600mm x2 1308mm uprights Lid front (no screws) 600mm bases Rear brace (screws in both...
- Page 5 14” x 22” mesh panel x1 Side panel top assembly x2 14”x 22” top mesh panel with notch in front Door handles x4 Lid prop x2 Panels...
- Page 6 Black rear lower panel x1 Black rear top panel x1 Clear lid panel x1 Clear side panels x 8...
- Page 7 Clear side top panel - le x1 Clear side top panel - right x1 Note: Holes for piping S10 door panels Top door pair - with stickers shorter x2 Lower door pair Longer x2 Fixings and small parts M5 x 8mm x18...
- Page 8 4.5 x 30 dome head screw x2 4.5 x 30 countersunk M5 Nyloc x6 M5 square nut x23 head screws x2 10cm cable ties x20 M5 washer x2 Blanking plug x14 Joining strap x2 4mm tubes for shelves 90mm x6 Lid top plate x1 Mounting plate x1 190mm x2...
- Page 9 Ensure that your screwdriver is fully engaged with the screw head when you tighten, so that you donʼt round off the head of the screw. Note the orientation of each piece in the description; specifically the closed face. WARNING Every care has been taken during manufacture to avoid sharp edges or burrs, however you should still take care when handling metal parts.
- Page 10 Step 2 - Attach the door handles Do this step first to allow the adhesive tape to cure while you assemble the rest of the greenhouse. Youʼll fit the doors at the end. Parts Fix the door handles to the doors as shown in the drawing 4 x door handle above, using the tape fixed to the handles.
- Page 11 Step 3 - Assemble the base Parts: This step is best done on a flat surface where you can 1 x front assembly. 1308mm easily access the screws at the bottom, such as a table or uprights workbench. 1 x rear assembly. 910mm uprights 2 x side base extrusion 45cm...
- Page 12 Slot the front and rear assemblies over the base extrusions The closed faces on the assembly uprights face outside the greenhouse. The side base parts have the single channel facing up, and the double channel facing down. Slot the assemblies over the screws on the side base parts and tighten.
- Page 13 Step 3 - Fit the rear upright joining straps Move the frame down onto the floor. Parts 2 x joining strap 8 x M5 x 8 button head 8 x M5 square nut Insert the 8mm bolts into the joining straps, and put a square nut on the back of each, loosely.
- Page 14 Step 4 - Fit the top rear uprights Parts With the holes as shown in the drawing below, slide the top rear 2 x top rear upright 558mm uprights down over the joining straps. The closed face should be to the rear of the greenhouse. Tighten the upper pair of bolts.
- Page 15 Step 5 - Insert square nuts into cross bars Parts 4 x side cross bar 45cm 4 x M5 square nut Insert a square nut into the inside channel of each crossbar that will go on the le side of the greenhouse.
- Page 16 Step 6 - Side panels and side crossbars Parts: 8 x clear side panel 2 x clear top side panel 4 x side cross bar 45cm 4 x side cross bar with nuts 45cm Peel the protective plastic off the side panels.
- Page 18 Step 8 - Lower rear panel and rear brace Parts: 1 x Lower rear panel (shorter panel) 1 x Rear brace (600mm with screws This step can be made easier by squeezing the edges of the panels that will be in the slots of the frame so that they are slightly deformed.
- Page 19 Step 9 - Fit the right side top assembly Parts: 1 x Right side top assembly 3 x M5 * 8mm button head bolt 3 x M5 square nut 1 x M5 * 10mm button head bolt Insert the 8mm bolts into the assembly in positions marked 1,2,3, and add the square nuts on the inside, loosely.
- Page 20 Step 10 - Fit the le side top assembly Parts: Repeat step 9 for the le hand side top assembly 1 x Le side top assembly 3 x M5 * 8mm button head bolt 3 x M5 square nut Step 11 - Fix lid li er bracket to adapter plate This step is only relevant if you have purchased an automatic lid opener.
- Page 21 Step 13 - Insert the front crossbar Parts 2 x M5 x 30mm bolt 2 x M5 nyloc nut 2 x M5 washer Use the M5 x 30 bolts to secure the front crossbar to the rear of the side assembly corner brackets.
- Page 22 Step 14 - Insert the rear upper panel Parts: 1 x rear upper panel Insert the rear upper panel in the orientation shown in the le diagram. Note: Ensure the panel holes are in the top le orientation when installing the panel This step can be made easier by squeezing the edges of the panels that will be in the slots of the frame so that they are slightly deformed.
- Page 23 Repeat above steps for the le lid side Peel back the film from the lid panel faces. The white side is outside facing. Slot the clear lid panel into the internal area in the lid paying attention to the notches in the panel corner as circled in the diagram below.
- Page 24 Insert 3 square nuts into the outside slot of the le and right side bars. Slide the ridge bar slotted face over the screws of the sidebar. Once positioned, tighten the 2 screws in the side bars to fix the lid ridge in place.
- Page 25 Step 16 - Add lid props to lid This is easiest done on a flat table or worktop. Parts 2 x lid props 2 x m5 x 10 button head bolts Note orientation of the lid prop Secure the lid prop bracket. Measure 100mm from the rear of the lid sidebar to the centre of the bolt and secure the bolt through the lid prop hole and into the square nut in the slot.
- Page 26 The 1 x lid top plate bottom lip of the plate below the harvst logo slots into 1 x lid li er assembly from step 19 the gap between lid panel and the front lid bar. The two holes on the lid top plate align with the holes on the lid panel.
- Page 27 Step 19 - Fit the lid to the greenhouse Parts Place the lid on top of the greenhouse, making sure that the rear 2 x 30mm pan head panel slots into the black channel on the underside of the lid. screw 1 x Lid Secure it with two pan head 30mm...
- Page 28 Step 21 - Understand how the shelves fit Refer to the drawing below to see the recommended position of the shelves. Note: If you have a smart sprout please refer to your smart control guide for layout of additional shelves Parts: 6 x 90mm length 4mm pipe 2 x 190mm length 4mm pipe...
- Page 29 Step 22 - Fit the shelves Parts: Slide the square nuts for the 13mm water Mesh shelves pipe to the middle of the crossbars on the le 2 x shelf support per shelf hand side of the frame, before you insert the 4 x 10cm cable tie per shelf shelf supports.
- Page 30 The front shelf support goes in upside down. Step 23 - Install irrigation, heating and lighting If you have a smart sprout, refer to the smart sprout S10 setup guide for adding additional parts...
- Page 31 Step 24 - Fit the top doors Parts Pop the doors into the sliding channels by flexing them 2 x clear doors slightly. The le hand door goes in the rear (inside) channel With handles fitted and the right hand door goes in the front (outside) channel. Shorter pair With stickers Step 25 - Fit the bottom doors...
- Page 32 Storm lock Parts: 4 x M5 x 10mm bolt In very strong winds, you may want to lock the lid so that it doesnʼt blow open. The o-ring fitted to the sides of the lid should be stretched over the frame bolt as shown below: Note: When the storm lock is fitted, you must disengage the automatic lid li er from the pegs on the lower mounting bracket.
-
Page 33: Regular Maintenance
Open the front doors, unclip the li er mechanism, and then open the lid. The lid opener piston is not covered under our manufacturer's guarantee. Help and support For tips, advice and questions, visit our Forums at: https://grow.harvst.co.uk/forums For setup assistance or other queries contact help@harvst.co.uk...
