- Page 1 Setup guide Model S14 Greenhouse only, Solar, 3-season and 4-season versions Visit www.harvst.co.uk/setup for more information, videos and photos...
- Page 2 Parts / assembly diagram...
- Page 3 Thank you for buying a Harvst greenhouse. If you have any questions while setting up, send us an email (help@harvst.co.uk) or have a look at our forums at https://grow.harvst.co.uk There are also videos at https://www.harvst.co.uk/setup...
- Page 4 Parts list (aluminium pieces) Weʼve fitted the front and rear uprights to the side base parts for you, to save time and help you get started. Weʼve also pre-fitted screws into bars, where required. 440mm x3 1210mm x1 2 lid sides, with plastic corners Front upper crossbar 1 lid centre (box profile as alternative)
- Page 5 Fixings and small parts Button head Cap head 4.5 x 30 screw x4 M5 x 8mm x8 M5 x 8mm x16 M5 nut x11 M5 Nylock x1 M5 washer x2 M5 x 40mm x3 M5 square nut x18 Blanking plug x8 20cm cable tie x2 14cm tie x100 Fixing bracket x2...
- Page 6 Panels Tools provided 3mm allen key, 4mm allen key 8mm spanner Pozidrive screwdriver Tools required You will also have mesh shelves, the quantity Tape measure to check parts depending on which model you have bought. Secateurs for cutting pipe...
- Page 7 Slotting parts together The greenhouse is based on parts that slot together using 30mm stainless steel screws, as shown in the diagram below. Ensure that your screwdriver is fully engaged with the screw head when you tighten, so that you donʼt round off the head of the screw.
- Page 8 Step 2 - Attach the door handles Do this step first to allow the adhesive tape to cure while you assemble the rest of the greenhouse. Youʼll fit the doors at the end. Parts Fix the door handles to the doors as shown in the drawing 2 x door handle above, using the tape fixed to the handles.
- Page 9 Step 4 - Assemble the base Parts: 1 x le assembly 1 x right assembly 1 x front base 121cm 1 x rear base 121cm This step is best done on a flat surface where you can easily access the screws at the bottom, such as a table or workbench.
- Page 10 Step 5 - Insert square nuts to side cross bars Parts Insert three square nuts into the inside channel of 4 x side cross bar 45cm each cross bar that will go on the le side of the 10 x square nut greenhouse.
- Page 11 Step 7 - Fit the side panel top assemblies Parts: 1 x Right side panel top assembly 3 x M5 * 8mm button head bolt 3 x M5 square nut Insert the bolts into the assembly, and add the square nuts on the inside, loosely.
- Page 12 Step 8 - Fix lid li er bracket to adapter plate OPTIONAL - if you have an automatic lid opener The lid li er bracket is in the lid opener box. (see drawing below for named parts) Parts: 1 x lid li er bracket 1 x adapter plate 2 x M5 x 8mm button head 2 x M5 nut...
- Page 13 Step 10 - Add the lid prop bolt This is the pivot bolt for the lid prop. Parts: Put the bolt through the hole just to the right of the middle of 1 x M5 x 40mm bolt the crossbar, from the front (the lid li er bracket is on the rear). 1 x M5 nut Secure it with the nut.
- Page 14 Step 13 - Fit the shelf support bars More shelves are supplied with the 4-season model, since the additional lighting allows plants to be grown closer together. For the 3-season, Solar and Greenhouse-only models, choose where you would like your shelves to be. The top shelf support is mounted upside down and takes the narrower mesh panels, to allow the lid li er piston to swing clearly.
- Page 15 4mm hoses into the riser pipe as you see fit. Example setup. See website for irrigation details. See our website for a range of videos which show you how to connect up various different water sources to your greenhouse irrigation. www.harvst.co.uk/setup...
- Page 16 Step 15 - Fit the grow lights - optional The 4-Season greenhouses can be fitted with grow lights. Up to a maximum of eight per control unit output (see notes on control unit maximum capacity). Per shelf: With the cables on the le , fix the lights to the underside of the mesh shelves using cable ties through the small holes.
- Page 17 Step 17 - Install rear panels Parts Insert the two rear panels with the drilled panel on the le . 2 x rear panel 1 x PVC H-trim 84cm If you have a control system to install, complete the next step 2 x long cable tie before inserting the section of H-trim between the panels.
- Page 18 Step 20 - Fit the lid prop Parts Put the hole in the lid prop over the stud 1 x lid prop, 55cm formed by the bolt on the front crossbar. 1 x M5 nyloc nut Put on the nyloc nut, tightening it just so that Note: The nyloc nut has a little plastic ring the plastic “bites”...
- Page 19 Step 23 - Insert the lid polycarbonate Parts Slot in the lid polycarbonate sheets. 2 x clear lid panel Make sure the white UV protected side is upwards. Youʼll need to flex the lid side bars apart slightly. Step 24 - Fit the lid front bar Parts 1 x lid front bar 121cm 2 x 30mm screw...
- Page 20 Step 26 - Fit the lid li er to the lid Parts: Turn the lid upside down. 2 x M5 x 8mm bolt The two square nuts in the centre channel will now be visible. 1 x lid li er Refer to the drawing above and fix the li er arm plate to the square nuts using the bolts, with a 15mm gap to the front bar.
-
Page 21: Regular Maintenance
Open the front doors, unclip the li er mechanism, and then open the lid. The lid opener piston is not covered under our manufacturer's guarantee. Help and support For tips, advice and questions, visit our community at https://grow.harvst.co.uk/forums...
