- Page 1 Setup guide Model S14 Greenhouse only, Solar, 3-season and 4-season versions Visit www.harvst.co.uk/setup for more information, videos and photos...
- Page 2 Parts / assembly diagram...
- Page 3 Thank you for buying a Harvst greenhouse. If you have any questions while setting up, send us an email (help@harvst.co.uk) or have a look at our forums at https://grow.harvst.co.uk There are also videos at https://www.harvst.co.uk/setup...
- Page 4 Parts list (aluminium pieces) Weʼve fitted the front and rear uprights to the side base parts for you, to save time and help you get started. Weʼve also pre-fitted screws into bars, where required. 450mm x3 1210mm x1 2 lid sides, with corner blocks Front upper crossbar 1 lid centre (box profile as alternative)
- Page 5 Fixings and small parts Button head Button head Button head Cap head M5 x 8mm x16 M5 x 10mm x6 M5 x 16mm x1 M5 x 8mm x8 M5 x 30mm x3 M5 x 40mm x2 M5 square nut x22 M5 nut x11 M5 Nyloc x1 Shelf bracket x4...
- Page 6 Panels Tools provided 3mm allen key, 4mm allen key 8mm spanner Pozidrive screwdriver Tools required You will also have mesh shelves, the quantity Tape measure to check parts depending on which model you have bought. Secateurs for cutting pipe...
- Page 7 Slotting parts together The greenhouse is based on parts that slot together using 30mm stainless steel screws, as shown in the diagram below. Ensure that your screwdriver is fully engaged with the screw head when you tighten, so that you donʼt round off the head of the screw.
- Page 8 Step 2 - Attach the door handles Do this step first to allow the adhesive tape to cure while you assemble the rest of the greenhouse. Youʼll fit the doors at the end. Parts Fix the door handles to the doors as shown in the drawing 2 x door handle above, using the tape fixed to the handles.
- Page 9 Step 3 - Assemble the base Parts: 1 x le assembly 1 x right assembly 1 x front base 121cm 1 x rear base 121cm This step is best done on a flat surface where you can easily access the screws at the bottom, such as a table or workbench.
- Page 10 Step 4 - Insert square nuts to side cross bars Parts See the drawing in step 6 and insert square nuts into 4 x side cross bar 45cm the cross bars. 6 x square nut Two will be for the shelves, and the third will be for supporting the irrigation pipe (itʼs worth fitting the nuts now even if you donʼt have the irrigation kit yet).
- Page 11 Step 6 - Fit right side panel top assemblies Parts: 1 x Right side panel top assembly 3 x M5 * 8mm button head bolt 3 x M5 square nut 1 x M5 * 10mm button head bolt Insert the 8mm bolts into the assembly in positions marked 1,2,3, and add the square nuts on the inside, loosely.
- Page 12 Step 8 - Fix lid li er bracket to adapter plate OPTIONAL - if you have an automatic lid opener The lid li er bracket is in the lid opener box. (see drawing below for named parts) Parts: 1 x lid li er bracket 1 x adapter plate 2 x M5 x 8mm button head 2 x M5 nut...
- Page 13 Step 10 - Add the lid prop bolt This is the pivot bolt for the lid prop. Note: If your crossbar does not have a slot, you will be provided with longer bolts (M5x40mm) which go all the way through the bar from the front. Parts: Put the M5 nut loosely onto the 16mm bolt.
- Page 14 Step 11 - Insert the front crossbar Parts 1 x M5 x 30mm bolt 1 x M5 x 40mm bolt 2 x M5 nut 2 x M5 washer Bolt the front upper bar to the rear of the brackets on the front of the greenhouse, using the 30mm bolt on the le and 40mm bolt on the right.
- Page 15 Step 13 - Fit the shelf brackets to the frame Parts 4 x M5 x 8mm cap head bolt 4 x shelf angle bracket Screw the brackets loosely onto the cross-bars of the end panels, using the M5x8mm bolts and the nuts in the channels of the cross bars.
- Page 16 Step 15 - Slot in the lower shelves (4-season only) Parts Refer to the drawing in step 12 to see how the lower shelves 2 x notched shelf support slot in. 2 x 4mm plastic tube 2 x mesh shelf Push the 4mm tube into the slot on the inside of the crossbar, to prevent the front shelf support from sliding forwards.
- Page 17 Step 18 - Fit the lid prop Parts Put the hole in the lid prop over the stud 1 x lid prop, 535mm formed by the bolt on the front crossbar. 1 x M5 nyloc nut Put on the nyloc nut, tightening it just so that Note: The nyloc nut has a little plastic ring the plastic “bites”...
- Page 18 Step 19 - Lid centre bar This is easiest done on a flat table or worktop. Parts Slide the lid centre bar into the lid rear bar, with the closed 1 x lid rear bar 125cm side upwards. 1 x lid centre bar 45cm 2 x square nut Slide the square nuts into the centre bar, in the channel opposite the closed face.
- Page 19 Step 20 - Lid side bars Parts 1 x lid assembly from step 20 4 x square nut 4 x M5 * 10mm 2 x lid sidebar 45cm with corner cubes Le and Right lid sides will be marked with the corner cubes facing towards you, as per the drawing at the bottom of this page.
- Page 20 Step 21 - Insert the lid polycarbonate Parts Slot in the lid polycarbonate sheets. 2 x clear lid panel Youʼll need to flex the lid side bars apart slightly. Make sure the white UV protected side is upwards. There is a corner taken off the polycarbonate to fit the corner cubes - ensure that is in the right position before moving to the next step.
- Page 21 Tip: Thereʼs a video on our website which shows how we recommend you fit the piston to the automatic lid opener www.harvst.co.uk/setup...
- Page 22 Step 27 - Fit the lid to the greenhouse Parts Place the lid on top of the greenhouse, making sure that the rear panel 2 x 30mm screw slots into the black channel on the underside of the lid. 1 x Lid Before you tighten the screws, ensure the sides of the greenhouse are firmly pushed together to secure the rear...
-
Page 23: Regular Maintenance
Open the front doors, unclip the li er mechanism, and then open the lid. The lid opener piston is not covered under our manufacturer's guarantee. Help and support For tips, advice and questions, visit our community at https://grow.harvst.co.uk/forums...
