Mocka Eclipse Assembly Instructions Manual page 8

Eclipse
Console Table
13
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
14
V
Z
W
J
10
K
17
7
Attach 4x wedges (J) into the corners of the back of the unit and secure with
4x screws (K). Tighten with a screwdriver. Attach 1x safety strap (V) to the top
of the back side of the unit as shown using 1x washer (Z) and 1x screw (W).
Tighten with a screwdriver. Attach panel [17] to panels [7], [8] and [10] with
4x bolt (L). Tighten with an Allen Key (P).
J
K
J
K
V
Z
W
L
6
L
8
17
P
L
L
