- Page 1 VPC-10 Voltage & Continuity Tester Users Manual • Mode d’emploi • Bedienungshandbuch • Manual d’Uso • Manual de uso...
- Page 3 VPC-10 Voltage & Continuity Tester Users Manual May 2010, Rev.2 ©2010 Amprobe Test Tools. All rights reserved. Printed in China...
- Page 4 To obtain service during the warranty period, return the product with proof of purchase to an authorized Amprobe Test Tools Service Center or to an Amprobe dealer or distributor. See Repair Section for details. THIS WARRANTY IS YOUR ONLY REMEDY.
- Page 5 Non-Warranty Repairs and Replacement – US and Canada Non-warranty repairs in the United States and Canada should be sent to a Amprobe® Test Tools Service Center. Call Amprobe® Test Tools or inquire at your point of purchase for current repair and replacement rates.
- Page 6 VPC-10 Voltage & Continuity Tester 1) Measuring Probe (Pos) 2) Ground Probe (COM) 3) Negative DC voltage Detection LED indication 4) Positive DC voltage Detection LED indication 5) AC Voltage range 6) DC voltage range 7) AC voltage Detection LEDs...
-
Page 7: Table Of Contents
CONTENTS SYMBOLS ................2 UNPACKING AND INSPECTION ........2 INTRODUCTION ..............3 OPERATION ............... 3 Automatic Operation ........... 4 Voltage Measurement ..........5 Continuity Testing ............7 SPECIFICATION ..............10 MAINTENANCE AND REPAIR ........... 11 BATTERY REPLACEMENT ..........12... -
Page 8: Symbols
SYMBOLS � Battery � Warning! Dangerous Voltage � Double Insulation Caution! Refer to the user’s manual before � using this Meter. � Alternating Current (AC). Ground (maximum permitted voltage between � terminal and ground). � Direct Current (DC). Symbol Application around and removal from �... - Page 9 This manual contains information and warnings that must be followed for operating the tester safely and maintaining the tester in a safe operating condition. If the tester is used in a manner not specified by the manufacturer, the protection provided by the tester may be impaired.
-
Page 10: Unpacking And Inspection
INTRODUCTION The VPC-10 and voltage tester is designed to be rugged and easy to use for the testing of voltage and continuity. It comes with a buzzer that provides indication of voltage or continuity. -
Page 11: Operation
OPERATION Note: All function operations described hereafter are via the stationary “Yellow” probe for positive (+) polarity and the attached “Black” probe for Ground reference (-), or otherwise specified. Automatic Operation The tester automatically turns on when you place the probes across a complete circuit. -
Page 12: Maintenance And Repair
Input Impedance: 1MW Temperature: Operating: -10°C to +50°C (14°F to 122°F), Storage: -30°C to +60°C (-22°F to 140°F) Altitude: Operating: 3000m; Storage: 10,000m Relative Humidity: 90%(0°C-30°C); 75%(30°C-40°C); 45%(40°C-50°C) Battery Type and Life: AA (2); 350 hours with NEDA 15F or IEC R6 Safety: Complies with EN61010-1 for use in overvoltage CAT III environments EMC Regulations: EN50081-1, EN50082-1... -
Page 13: Battery Replacement
BATTERY REPLACEMENT Replace the batteries immediately if the continuity LED doesn’t turn on when touching both probes together. Follow picture below: • Disconnect probes from Voltage • Do not over-tighten screws 2 x AA FIG.1/ +VDC Measurement... - Page 14 Fig.2/ -VDC Measurement Fig.3/ Continuity Testing...
- Page 15 Fig.4 / AC Measurement >208V both LEDs on...
