ADM1063
Pin No.
1 Mnemonic
LFCSP TQFP
37 44 D1N
38 45 D1P
39 46 VDDCAP
40 47 GND
1
Note that the LFCSP has an exposed pad on the bottom. This pad is a no connect (NC). If possible, this pad should be soldered to the board for improved mechanical stability.
2
In a typical application, all ground pins are connected together.
Description
External Temperature Sensor 1 Cathode Connection.
External Temperature Sensor 1 Anode Connection.
Device Supply Voltage. Linearly regulated from the highest of the VPx, VH pins to a typical of
4.75 V. Note that the capacitor must be connected between this pin and GND. A 10 μF
capacitor is recommended for this purpose.
2
Supply Ground.
Rev. C | Page 8 of 32
