- Page 1 DAER1250 Electric router USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. GENERAL POWER TOOL SAFETY WARNINGS ................... 3 2. SPECIFIC SAFETY RULES ........................4 3. EXPLANATION OF SYMBOLS ........................ 5 4. TECHNICAL SPECIFICATIONS ......................6 5. ASSEMBLY AND ADJUSTMENT ......................6 6. OPERATION ............................. 7 7. CLEANING, MAINTENANCE, AND LUBRICATION................8 8. - Page 3 Fig 1 Fig 2 Fig .3 Fig. 4 Fig.5 Fig.6 Fig.7 Fig.8 Fig.9 Fig 10 Fig.11 Fig.12 Fig.13...
-
Page 4: General Power Tool Safety Warnings
1. GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains‐operated (corded) power tool or battery‐operated (cordless) power tool. -
Page 5: Specific Safety Rules
part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. -
Page 6: Explanation Of Symbols
material causing loss of control of the cutter. 8. Always hold the tool with two hands during start-up. The reaction torque of the motor can cause the tool to twist. 9. The direction of feeding the bit into the material is very important and it relates to the direction of bit rotation. -
Page 7: Technical Specifications
READ AND SAVE ALL INSTRUCTIONS FOR FUTURE USE 4. TECHNICAL SPECIFICATIONS Voltage/Frequency: 220 - 240 V ~ 50 Hz Power: 1200 W Speed: 11500-26000 rpm Working size: 6-8 mm Functional Description (Fig 1&2） Your Router has been designed for professional heavy duty routing of wood, wood and plastics productions. -
Page 8: Operation
Locking lever to tighten the heighth of machine body (Fig. 5) The cutting machine body is spring tensioned. Take care when releasing the locking lever(13), Grasp both handles and brace yourself before releasing the lever. Press the housing downwards to the desire heighth and tighten the locking lever . -
Page 9: Cleaning, Maintenance, And Lubrication
- Connect a dust cover. - Make sure the lock lever is always locked before switching on Switching on and off(Fig. 11&12) 1. Connect the plug to the power mains, the power on indicator is illumed until disconnect from the power mains. -
Page 10: Spare Parts
8. SPARE APRTS... - Page 11 Description Description screw ST4.2X16 spring upper cover head cover screw M4X90 steel sleeve Φ18XΦ22X12 spring washer Φ4 bearing faster nut washer Φ4 right handle power-on indicator cable press plate lampshade screw ST4.2X12 housing cord &plug screw ST4X8 cord sleeve rear cover capacitor speed control switch switch...
- Page 13 Manufactured under license of Daewoo International Corporation, Korea...
