Summary of Contents for Daewoo DAWS-025
- Page 1 DAWS-025 Cordless pruning shear USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. PACKING LIST ............................3 2. SAFETY MARKS ............................3 3. PRODUCT DESCRIPTION ........................3 4. TECHNICAL SPECIFICATIONS ....................... 4 5. DESCRIPTION PART ..........................4 6. PRODUCT OPERATION .......................... 5 7. OPERATION PRECAUTIONS ........................8 8. SAFETY NOTES ............................9 9. -
Page 3: Packing List
1. PACKING LIST lncluded in the case 1. Electric pruning shear 2. Lithium battery 3. Battery charger 4. Tool kit 2. SAFETY MARKS NOTE 1. Please read through the manual carefully. 2. Battery can only be charged indoors. 3. Double insulation,grounding not required. 4. -
Page 4: Technical Specifications
4. TECHNICAL SPECIFICATIONS Driver: Gear Cut diameter: up to 25 mm Power: 16.8 V DC Brushless Speed: 2300 rpm Battery: 2.0 Ah Lithium battery Charger voltage: AC 110-240 V Charging time: 2 hours Material of blade: Stainless alloy Protect system: Yes N.W/G.W.: 20/22 kgs Includes: Tool kit, BMC case, 2 batteries and power indicator. -
Page 5: Product Operation
6. PRODUCT OPERATION Setting up 1. Open the package, insert the the baltery into the power connector of the pruner with designated direction, see 2. Press the power bullan till the LEO display indicator change to green. After !he sound "Di- Di Di Di"... - Page 6 Packing up 1. Press the trigger and hold far a few seconds and then release, the blade will clase and will not open. 2. Switch off the battery, disconnect the battery. 3. Tidy up, clean up and pack the pruner into the tool box. Failure tips Buzzer sound Failure...
- Page 7 Cautions 1. Before charging, please ensure battery power switch is in OFF position. During charging, it is normal far the charger and battery to be warm. 2. lf the battery is not use for a long period of time, it recommended to charge the battery once every 3 months, this is to ensure the battery life is not affected by low usage.
-
Page 8: Operation Precautions
Fixed and movable blades can be re placed individually; do not worry about the size of the replace- ment blade aperture, the opening will automatically return to normal size during power ON after completing blade replacement. 7. OPERATION PRECAUTIONS Usage and care for pruning shear 1. -
Page 9: Safety Notes
of battery. 14. Do not connect the battery to charging outlets or car cigarette lighter socket. 15. Do not use the battery on equipment other !han the designated pruning shear. 16. Do not dlrect contact wlth llthlum cells In the battery. 17. - Page 10 lrregularity Measures 1. In the event the pruning shear is not able to cut through an object, released the trigger immediate- ly and the moving blade will return to its open position automatically. 2. In the event the pruning shear is cutting through a branch of particularly hardness,released the trigger immediately and the moving blade will return to it´s open position automatically.
-
Page 11: Exploded View And Spare Part List
9. EXPLODED VIEW AND SPARE PART LIST... - Page 12 1. Box (part No.1.2.35.34 assembled together, can not sell separately) - x1 2. Cone gear (assembled with box,can not sell separately) - x1 3. Trigger board - x1 4. Cross recess pan head screw （for trigger board) - x1 5. Down blade - x1 6.
-
Page 13: Ec Declaration Of Conformity
We: GBR Corp. LTD, Room 1002, 10/F., David House, 8-20 Nanking Street, Jordan, Kowloon, Hong Kong, China Declare that the Product detailed below: Cordless pruning shear Model: DAWS-025 Brand: Satisfies the requirement of the Council Directives: 2006/42/EC (Machinery) 2014/35/EU (Low Voltage) 2014/30/EU (Electromagnetic Compatibility) Name and address of authorized person to compile the technical file: Ente... -
Page 14: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 15 Manufactured under license of Daewoo International Corporation, Korea...
