KR PORTABLE SYSTEM
1) CH1 Line Input. XLR line level input with +4 dBu sensitivity.
2) CH2 Mic/Line Input. XLR input, with selectable sensitivity for Mic (-30 dBu) or Line (+4 dBu).
3) Mic/Line switch. Selects CH2 input sensitivity for Mic ( -30 dBu) or Line ( +4 dBu) level.
4) Phantom Power switch. Turns phantom power (48V) on/off on CH2 input.
5) Limiting LEDs. Independent LEDs for the CH1 and CH2 inputs, which blink when the optical limiter
engages to protect the corresponding preamp circuit. Limiter threshold is +5 dBu.
6) CH1 Parallel Line Out. XLR parallel output providing a direct signal from the CH1 Line Input. This
output cannot be processed or controlled via the K-Framework software.
7) CH2 Parallel Line Out / DSP Out. When the DSP Out switch is not pressed (off), this connector
provides a direct signal from the CH2 input. Press the DSP Out switch to use this output as an
auxiliary XLR balanced output controlled via the K-Framework software.
8) DSP Out Switch. See point 7.
9) AES/EBU Digital Input. XLR input connector for two-channel AES/EBU digital audio, accepting
sample rates up to 96 kHz.
10) AES/EBU Digital Output. XLR output, providing two-channel digital audio from AES/EBU Input,
This output cannot be processed or controlled via the K-Framework software.
11) REMOTE RS485 Link Input. XLR input for connecting the KMT from another RS485 device in a
K-Framework network. RS485 Link Input can also be used to connect a computer running the
K-Framework software (requires K-USB USB-to-RS485 adapter).
12) REMOTE RS485 Link Output. XLR output for connecting additional RS485 devices in a K-Framework
network.
13) REMOTE USB Input. Connects a computer running the K-Framework software, for remote control
of the KMT. Users can manage an entire network of RS485 devices with one PC connected via
USB.
14) Speaker Out. Powered Speakon output, used to drive passive speakers, like a mid-high module
or a passive subwoofer.
15) Power switch. Turns the KMT system on and off.
16) AC Input. PowerCon input for AC power.
17) AC Link. PowerCon output for feeding AC mains power to additional K-array components with a
PowerCon AC input socket.
18) Power On LED. Indicates the system is ON.
19) Touch Screen Control Panel. Provides access to the main functions of the onboard DSP (see
Section 8)
20) 5 Volt Power Connector. Provides 5VDC/500mA to power e-fun accessories.
IMPORTANT NOTE
By default, the analog channel CH2 and the digital channel CH4 are not routed
to any output. To activate them, go to the Matrix Page on the LCD screen (see
Chapter 8).
