  • Page 1 Manual ® HIMax X-COM 01 E Communication Module...
  • Page 2 All of the HIMA products mentioned in this manual are trademark protected. Unless noted otherwise, this also applies to other manufacturers and their respective products referred to herein. ® ® ® ® ® ® ® HIQuad , HIQuad X, HIMax...

  • Page 3: Table Of Contents

    X‑COM 01 E Table of Contents Table of Contents Introduction Structure and Use of This Manual Target Audience Presentational Conventions 1.3.1 Warning Messages 1.3.2 Useful Additional Information Safety Intended Use 2.1.1 Environmental Conditions 2.1.2 ESD Protective Measures Residual Risk Safety Precautions Emergency Information Product Description Replacement and Compatibility...
  • Page 4 Table of Contents X‑COM 01 E 4.3.1 The Module Tab 4.3.2 The Routings Tab 4.3.3 The Ethernet Switch Tab 4.3.4 The VLAN Tab (Port-Based VLAN) 4.3.5 The LLDP Tab 4.3.6 The Mirroring Tab 4.3.7 Network Ports in Use for Ethernet Communication Operation Handling Diagnostics...

  • Page 5: Introduction

    SILworX Table 1: Additional Applicable Manuals Registered customers can download the product documentation from the HIMA Extranet. Target Audience This document is aimed at the planners, design engineers, programmers and the persons authorized to start up, operate and maintain the automation systems. Specialized knowledge of safety-related automation systems is required.

  • Page 6: Presentational Conventions

    1 Introduction X‑COM 01 E Presentational Conventions To ensure improved readability and comprehensibility, the following presentational conventions are used in this document: Bold To highlight important parts. Names of buttons, menu functions and tabs that can be clicked and used in the programming tool. Italics Parameters and system variables, references.

  • Page 7: Useful Additional Information

    X‑COM 01 E 1 Introduction 1.3.2 Useful Additional Information Additional information is designed as follows: The text giving additional information is located here. Useful tips and tricks are designed as follows: The tip text is located here. HI 801 566 E Rev. 13.00.00 Page 7 of 46...

  • Page 8: Safety

    Observe all local safety requirements and use the protective equipment required on site. Emergency Information A HIMA system is a part of the safety equipment of an overall system. If the controller fails, the system enters the safe state. In case of emergency, no action that may prevent the HIMA system from operating safely is permitted.

  • Page 9: Product Description

    Use the SILworX programming tool to select the interfaces for the available protocols. Refer to the HIMA website and the HIMax safety manual (HI 801 003 E) for more information on the standards used to test and certify the module and the HIMax system.

  • Page 10: Safety Function

    3 Product Description X‑COM 01 E Safety Function No safety function is performed by the communication module. 3.2.1 Response in the Event of a Fault If faults occur, the module enters the temporary STOP_ERROR state. The module is then rebooted and restarted from the INIT state. No process data is exchanged with external communication partners in the STOP_ERROR state.

  • Page 11: Type Label

    X‑COM 01 E 3 Product Description Type Label The type label specifies the following important details: ▪ Product name ▪ Mark of conformity ▪ Bar code (2D or 1D code) ▪ Part number (Part-No.) ▪ Hardware revision index (HW-Rev.) ▪ Operating system revision index (OS-Rev.) ▪...

  • Page 12: Structure

    3 Product Description X‑COM 01 E Structure Essential functional units of the module are: ▪ Processor system ▪ Ethernet switch ▪ Ethernet interface ▪ Fieldbus submodule ▪ Indicators, see Chapter 3.5.8. ▪ For details on the associated connector boards, see also Chapter 3.7.1 and Chapter 3.7.2.

  • Page 13: Block Diagram With X-Cb 001 04 Connector Board

    X‑COM 01 E 3 Product Description 3.5.2 Block Diagram with X-CB 001 04 Connector Board The following block diagram illustrates the structure of the module with the X-CB 001 04 connector board: Fieldbus submodule 1 for PROFINET IO Processor system Controller V2.4+ Ethernet interface Fieldbus submodule 2...

  • Page 14: Processor System

    3 Product Description X‑COM 01 E 3.5.3 Processor System The processor system uses self-tests to control and monitor communication. Data is exchanged between communication and processor modules via the redundant system bus. The system bus has a redundant structure for reasons of availability. Redundancy is only ensured if both system bus modules are inserted in the base plates and configured accordingly.

  • Page 15: Automation Network And Fieldbus Interfaces On The X-Cb 001 04 Connector Board

    X‑COM 01 E 3 Product Description 3.5.7 Automation Network and Fieldbus Interfaces on the X-CB 001 04 Connector Board The automation network and the fieldbus interfaces are activated through the integrated submodule. The submodules determine the interface transmission standard and must be specified when ordering the module.

  • Page 16: Indicators

    3 Product Description X‑COM 01 E 3.5.8 Indicators The following figure shows the front view of the module with the LEDs. Figure 4: Front View Page 16 of 46 HI 801 566 E Rev. 13.00.00...

  • Page 17: Table 6: Blinking Frequencies Of The Leds

    X‑COM 01 E 3 Product Description The LEDs indicate the operating state of the module. All LEDs should be considered together. The LEDs on the module are divided into the following groups: ▪ Module status indicators (Run, Error, Stop, Init) ▪...

  • Page 18: Module Status Indicators

    3 Product Description X‑COM 01 E 3.5.9 Module Status Indicators These LEDs are located on the upper part of the front plate. Color Status Description Green Module in the RUN state, normal operation. Blinking1 Module state STOP / LOADING OS Module not in the RUN state, observe the other status LEDs.

  • Page 19: System Bus Indicators

    X‑COM 01 E 3 Product Description 3.5.11 System Bus Indicators The system bus indicator LEDs are labeled Sys Bus. Color Status Description Green Physical and logical connection to the system bus module in slot 1. Blinking1 No physical connection to the system bus module in slot 1.

  • Page 20: Ethernet Indicators

    3 Product Description X‑COM 01 E 3.5.13 Ethernet Indicators The LEDs of the Ethernet indicators are labeled Ethernet. Color Status Description Eth 1…4 Green Communication partner connected. No communication detected on interface. Blinking-x Communication detected on interface. Blinking1 IP address conflict detected. All Ethernet indicator LEDs are blinking.

  • Page 21: Product Data

    X‑COM 01 E 3 Product Description Product Data General information ≤ 5 % Supply voltage 24 VDC, -15…+20 %, r SELV, PELV Current consumption 0.3 A at 24 VDC Memory for fieldbus protocols 128 kB Protection class Protection class III in accordance with EN 61131-2 0…+60°C Ambient temperature Transport and storage...

  • Page 22: Connector Board

    3 Product Description X‑COM 01 E Connector Board The connector board forms a functional unit with the module and connects the module to other systems via the Ethernet and fieldbus interfaces. The connector board must be inserted into the appropriate slot prior to mounting the module on the base plate. Two connector boards with various connection sockets are available for this module.

  • Page 23: Table 13: Connection Sockets On The X-Cb 001 02 Connector Board

    X‑COM 01 E 3 Product Description Fieldbus interface FB1 (X1) D-sub connector, 9 poles FB2 (X2) D-sub connector, 9 poles Ethernet interface port Eth1 (X3) RJ-45 connection socket Eth2 (X4) RJ-45 connection socket Eth3 (X5) RJ-45 connection socket Eth4 (X6) RJ-45 connection socket Table 13: Connection Sockets on the X-CB 001 02 Connector Board The transmission standard for the fieldbus interfaces is determined by the installed fieldbus...

  • Page 24: Ports On The X-Cb 001 04 Connector Board

    3 Product Description X‑COM 01 E 3.7.2 Ports on the X-CB 001 04 Connector Board The designations for the connector socket are printed on the connector board. Figure 7: X-CB 001 04 Connector Board Page 24 of 46 HI 801 566 E Rev. 13.00.00...

  • Page 25: Table 14: Connection Sockets On The X-Cb 001 04 Connector Board

    X‑COM 01 E 3 Product Description Ports for the automation network interface and the fieldbus interface AN1 (X7) RJ-45 connection socket for the automation network. AN2 (X8) RJ-45 connection socket for the automation network. FB (X2) D-sub connector, 9 poles Ethernet interface port Eth1 (X3) RJ-45 connection socket...

  • Page 26: Start-Up

    4 Start-Up X‑COM 01 E Start-Up This chapter describes how to install and configure the module. For further details, refer to the system manual (HI 801 001 E). Mounting Observe the following points when mounting the module: ▪ Only operate the module with the appropriate fan components. For further details, see the system manual (HI 801 001 E).

  • Page 27: Figure 8: Example Of How To Insert The Mono Connector Board

    X‑COM 01 E 4 Start-Up Figure 8: Example of how to Insert the Mono Connector Board HI 801 566 E Rev. 13.00.00 Page 27 of 46...

  • Page 28: Figure 9: Example Of How To Secure The Mono Connector Board With Captive Screws

    4 Start-Up X‑COM 01 E Figure 9: Example of how to Secure the Mono Connector Board with Captive Screws These instructions also apply for redundant connector boards. The number of used slots varies in accordance with the connector board type. The number of captive screws depends on the connector board type.

  • Page 29: Mounting And Removing A Module

    X‑COM 01 E 4 Start-Up 4.2.2 Mounting and Removing a Module This chapter describes how to mount and remove the HIMax module. A module can be mounted and removed while the HIMax system is operating. NOTICE Damage to bus and power sockets due to module jamming! Failure to comply with these instructions can damage the controller.

  • Page 30: Figure 10: Mounting And Removing A Module

    4 Start-Up X‑COM 01 E Inserting and removing a module Securing and releasing a module Swiveling the module in and out Figure 10: Mounting and Removing a Module If the HIMax system is operating, do not open the cover plate of the fan rack for more than a few minutes (<...

  • Page 31: Configuring The Module In Silworx

    3. Right-click COM Module and select Detail View from the context menu to open the detail view. The parameters set in the properties of the COM module are not available for the HIMA system communication, until they have been re-compiled with the user program and transferred to the controller.
  • Page 32 4 Start-Up X‑COM 01 E Designation Description ARP Aging Time [s] A COM module stores the MAC addresses of the communication partners in a MAC/IP address assignment table (ARP cache). The MAC address remains stored in the ARP cache if messages from the communication partner are received within 1x…2x ARP Aging Time.

  • Page 33: The Routings Tab

    X‑COM 01 E 4 Start-Up Designation Description ICMP Mode The Internet Control Message Protocol (ICMP) allows the higher protocol layers to detect error states on the network layer and optimize the transmission of data packets. Message types of Internet Control Message Protocol (ICMP) supported by the CPU module: ▪...

  • Page 34: The Ethernet Switch Tab

    4 Start-Up X‑COM 01 E 4.3.3 The Ethernet Switch Tab The Ethernet Switch tab contains the following parameters: Designation Description Port (Eth1…Eth4) in accordance with the arrangement on the connector Name board. Only one configuration is allowed/possible for each port. Range of values: 1…4 ▪...

  • Page 35: The Lldp Tab

    X‑COM 01 E 4 Start-Up 4.3.5 The LLDP Tab LLDP (Link Layer Discovery Protocol) periodically sends information on the own device via multicast (e.g., MAC address, device name, port number) and receives the same information from the neighboring devices. LLDP uses the following values depending on whether PROFINET IO is configured on the communication module: PROFINET IO on the COM module Chassis ID...

  • Page 36: Network Ports In Use For Ethernet Communication

    4 Start-Up X‑COM 01 E 4.3.7 Network Ports in Use for Ethernet Communication UDP ports SNTP (time synchronization between controller and remote I/O, and external devices). Modbus salve (can be changed by the user). 6010 SafeEthernet and OPC. 8000 Programming and operation with SILworX.. 8001 Port on the remote I/O for configuring the remote I/O using the controller.

  • Page 37: Operation

    X‑COM 01 E 5 Operation Operation The module runs within a HIMax base plate and does not require any specific monitoring. Handling Direct handling of the module is not foreseen. The module is operated from within the PADT. For further details, refer to the SILworX documentation.

  • Page 38: Maintenance

    (HI 801 003 E). 6.1.2 Loading of Enhanced Operating System Versions As part of product maintenance, HIMA is continuously improving the operating systems of the modules. HIMA recommends using system downtimes to load current versions of the operating system into the modules.

  • Page 39: Decommissioning

    X‑COM 01 E 7 Decommissioning Decommissioning To decommission the module, remove it from the base plate. For more details, refer to Chapter Mounting and Removing the Module. HI 801 566 E Rev. 13.00.00 Page 39 of 46...

  • Page 40: Transport

    8 Transport X‑COM 01 E Transport To avoid mechanical damage, the components must be transported in packaging. Always store the components in their original product packaging. This packaging also provides protection against electrostatic discharge (ESD). Note that the product packaging alone is not sufficient for transport.

  • Page 41: Disposal

    9 Disposal Disposal Industrial customers are responsible for correctly disposing of decommissioned hardware. Upon request, a disposal agreement can be arranged with HIMA. All materials must be disposed of in an ecologically sound manner. HI 801 566 E Rev. 13.00.00...

  • Page 42: Appendix

    Appendix X‑COM 01 E Appendix Glossary Term Description Analog input Analog output Address resolution protocol, network protocol for assigning the network addresses to hardware addresses Communication module Cyclic redundancy check Digital input Digital output Electromagnetic compatibility European standard Electrostatic discharge Fieldbus Function block diagrams Hardware...

  • Page 43: Index Of Figures

    X‑COM 01 E Appendix Index of Figures Figure 1: Sample Type Label Figure 2: Block Diagram with X-CB 001 02 Connector Board Figure 3: Block Diagram with X-CB 001 04 Connector Board Figure 4: Front View Figure 5: Views Figure 6: X-CB 001 02 Connector Board Figure 7: X-CB 001 04 Connector Board...

  • Page 44: Index

    Appendix X‑COM 01 E Index Automation network ........15 System bus indicators ......19 Block diagram ........12, 13 Module status indicators ......18 Diagnostics ..........37 Processor system ........14 Ethernet indicators ......... 20 Safety function ........... 10 FB/AN indicators ........19 Safety-related protocols .......
  • Page 46 MANUAL X-COM 01 E HI 801 566 E For further information, please contact: HIMA Paul Hildebrandt GmbH Albert-Bassermann-Str. 28 68782 Brühl, Germany Phone: +49 6202 709-0 +49 6202 709-107 E-mail: info@hima.com Learn more about HIMax online: www.hima.com/en/products-services/himax/ www.hima.com...
