DAN90AGG
DAN60AGG
DAN64GAG
DAN95GAG
DAN2GAG
DAN90GAS
Instruction manual
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference;for
you or any person not familiar with the operation of the appliance.
1
Advertisement
Related Manuals for Daniela DAN90AGG
Summary of Contents for Daniela DAN90AGG
- Page 1 DAN90AGG DAN60AGG DAN64GAG DAN95GAG DAN2GAG DAN90GAS Instruction manual NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;for...
-
Page 2: Environmental Note
Environmental note o The packaging materials that uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 3: Important Safety Information
Important safety information Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the retailer where you purchased your unit from. - Page 4 o Repairs may only be carried out by authorised service agents and licensed professionals. Child Safety o Strongly recommend that the appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction o Children being supervised not to play with the appliance General Safety...
- Page 5 o IMPORTANT: Before attempting to clean the appliance, it should be disconnected from the mains and cool down. o Great care should be taken whilst using this appliance and when following the cleaning procedure. o You should not use a steam jet or any other high pressure cleaning equipment to clean the appliance.
-
Page 6: Specifications
Specifications DAN90AGG PRODUCT SPECIFICATIONS: A = 14.4 MJ/h large burner B = 10.8 MJ/h small burner C = 6.5 MJ/h medium burner D = 3.8 MJ/h small burner • Front control operation • Automatic ignition • Heavy duty cast iron pan stands Flame failure safety device •... - Page 7 Specifications DAN64GAG / DAN60AGG PRODUCT SPECIFICATIONS: A = 14.4 MJ/h wok burner B = 2 x 6.5 MJ/h medium burners C = 3.8 MJ/h small burner D = Control panel • Front control operation • Automatic ignition • Heavy duty cast iron pan stands Flame failure safety device •...
- Page 8 Specifications DAN95GAG / DAN90GAS PRODUCT SPECIFICATIONS: A = 14.4 MJ/h large burner B = 10.8 MJ/h small burner C = 6.5 MJ/h medium burner D = 3.8 MJ/h small burner • Front control operation • Automatic ignition • Heavy duty cast iron pan stands Flame failure safety device •...
- Page 9 Specifications DAN2GAG PRODUCT SPECIFICATIONS: A = 1 x 10.8 MJ/h large burner B = 1 x 3.8 MJ/h small burner C = Control panel • Front control operation • Automatic ignition • Heavy duty cast iron pan stands Flame failure safety device •...
-
Page 10: Using The Gas Hob
Electrical details Rated Voltage: 220 - 240 Vac 50 / 60 Hz Supply Connection: Max Rated Inputs: 0.0008 kW Mains Supply Lead: 3 core x 0.75mm² (Type RR-F <HAR> marked) Gas details Connection: Rp ½ (ISO R7) Type: Natural Gas (1.0 KPa) LPG (2.75KPa) Using the gas hob Before first use... - Page 11 Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out. To ignite a burner: o Press in the control knob of the burner that you wish to light and turn it anti-clockwise to the maximum position.
- Page 12 o The burner flame must never extend beyond the diameter of the pan. o Use flat bottomed pans only. Cleaning Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from your mains supply before commencing any cleaning process.
- Page 13 o IMPORTANT: Make sure that the hob surface, pan stands and hob burners have cooled before you attempt to touch them. o Remove the hob burners by pulling them upwards and away from the hob top. o Soak them for about ten minutes in hot water and a little detergent.
- Page 14 o This appliance located kitchen. IMPORTANT: The appliance must not be installed in a bathroom or shower room.
- Page 15 This appliance is classified as Class 3 and therefore is to be built into a kitchen unit (depending on size) or 600mm worktop, providing the following minimum distances are allowed: o The edges of the hob must be a minimum distance of 55 mm from a side or rear wall.
- Page 16 o Do not leave a gap in the sealing agent or overlap the thickness. o NOTE: It will be difficult to remove the hob from the aperture in case it needed, if a silicon sealant used to seal the appliance against the aperture.
- Page 17 Important information o This hob is supplied to run on natural gas and cannot be used on any other type of gas without modification. o Conversion for use on LPG and other gases must only be undertaken by a licensed professional. o The hob must be installed by a qualified installer.
- Page 18 o Prolonged intensive use of the appliance may call for additional ventilation, either by the opening of a window, or by increasing the level of the mechanical ventilation device (where present). o This hob is not fitted with a device for discharging the products of combustion.
- Page 19 o Natural gas and liquefied petroleum gas conversion function, need to be set manually. o Operating Temperature:-20℃~60℃. o Inlet pressure setting: of natural gas 6 in.wc / liquefied gas 11 in.wc of. The performance parameters of the following table: Installation Method: Users to install the external threads coated with an appropriate amount of sealant to seal can also choose other sealing methods.
- Page 20 Please note: Do not adjust the regulator valve body piece in the above procedure, otherwise it will affect the performance parameters set in the factory. WARNING: ·Regulator valve outlet pressure is set at the factory, please do not adjust in order to avoid the occurrence of safety accidents.
- Page 21 Gas adjustment (Conversion to LPG) All gas adjustment or conversion work must be carried out by a licensed gas fitter. IMPORTANT: Always isolate the hob from the electricity and gas supply before changing the injectors and/or adjusting the minimum flow of the burners. Remove the pan-stands, burners and flame spreaders (A).
- Page 22 POWER (MJ/h) KIND NOZZLE BURNERS mm/100 OF GAS Maximum Minimum 14.4 Large 10.8 Natural Medium 3.24 Small 15.0 L.P.G. Large 11.0 Butane Medium 3.24 Propane Small o Reassemble all burners carefully; in particular you should make sure that the flame spreader is correctly placed on the burner. o IMPORTANT: The minimum flow adjustment process must be completed before the appliance is used.
- Page 23 o Place a small bladed screwdriver on the screw to adjust the minimum flow (as shown in the image on the left). o Unscrew the adjusting screw, in order to increase the gas flow or tighten the adjusting screw to decrease the gas flow.
- Page 24 o Disconnect the fixings holding the tap to the fascia panel and separate the assembly. Then clean the cone and seating, with a cloth dampened with solvent. o Lightly smear cone with high temperature grease, reassemble into position and rotate a few times. o Remove the cone again and remove any excess grease, making sure that the gas ducts are not obstructed with grease.
- Page 25 o Cable type: H05 RRF 3 core x 0.75 mm³ (Type RR-F <HAR> marked). o The mains supply cable is supplied with this product. Replacing the mains supply cable If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which The mains supply cable should be replaced in accordance with the following instructions:...
- Page 26 they do not touch any parts of the appliance which become hot. Gas pipe or connector shouldn't be bent or blocked by any other appliances. Check the dimensions of the appliance as well as the dimensions of the gap to be cut in the kitchen unit.
