- Page 1 DAN2GAG • DAN64GAG • DAN60GAS DAN75GAG • DAN95GAG • DAN9PAG 2,4 & 5 BURNER GAS COOKTOPS A p p l i a n c e U s e r M a n u a l danielaappliances.com.au...
- Page 2 From an Italian heritage our brand Daniela was then established in 2005 from a father’s love to a daughter and naming it after Daniela, now the new proprietor. Daniela has worked closely with her father for many years learning from his decades of industry experience. Daniela with her extensive knowledge and understanding of appliances, now continues her father’s legacy with a modern flare.
- Page 3 DAN2GAG 30CM 2 BURNER GAS COOKTOPS DAN64GAG • DAN60GAS 60 CM 4 BURNER GAS COOK TOPS DAN75GAG 77CM 5 BURNER GAS COOK TOPS DAN95GAG • DAN95GAG/P 90CM 5 BURNER GAS COOKTOPS DAN9PAG • DAN9PAGW 96CM 4 BURNER GAS COOKTOPS PA G E 3 02 9604 1226 sales@danielaappliances.com.au...
-
Page 4: Important Safety Instructions
SAVE THIS INSTRUCTION IN A SAFE PLACE FOR FUTURE REFERENCE Thank you for choosing Daniela appliances! Please read all instructions before using this appliance. This book contains valuable information about operation, care and service. Keep it in a safe place for future reference. - Page 5 CHILD SAFETY • We strongly recommend that babies and young children are prevented from being near the appliance and not allowed to touch the appliance at any time. During and after use, all surfaces will be hot. DURING USE • Any film or stickers that are present on the hob surface when it is delivered should be removed before use.
-
Page 6: Installation
AS4551, AS/NZS 5263.1.1: Domestic gas cooking appliances. Low voltage: 73/23 Safety standards: EN 60335-1, EN30-1-1, AS/NZS 3350-1, 3350-2-6 SPECIFICATIONS DAN2GAG PRODUCT SPECIFICATIONS: A = 1 x 10.8 MJ/h large burner B = 1 x 3.8 MJ/h small burner C = Control panel •... - Page 7 SPECIFICATIONS DAN64GAG PRODUCT SPECIFICATIONS: A = 14.4 MJ/h wok burner B = 2 x 6.5 MJ/h medium burners C = 3.8 MJ/h small burner • Right control operation • Automatic ignition • Heavy duty cast iron pan stands Flame failure safety device •...
- Page 8 SPECIFICATIONS DAN75GAG PRODUCT SPECIFICATIONS: A = 14.4 MJ/h large burner B = 10.8 MJ/h small burner C = 6.5 MJ/h medium burner D = 3.8 MJ/h small burner • Front control operation • Automatic ignition • Heavy duty cast iron pan stands Flame failure safety device •...
-
Page 9: Electrical Details
3 core x 0.75mm² (Type RR-F <HAR>marked) GAS DETAILS DAN64GAG • DAN75GAG • DAN95GAG/P • DAN95GAG DAN60GAS • DAN9PAG • DAN2GAG • DAN9PAGW Connection Type: Rp ½ (ISO R7) - Natural Gas (1.0 KPa) - LPG (2.75 KPa) PA G E 9 02 9604 1226 sales@danielaappliances.com.au... -
Page 10: Using The Hob
USING THE HOB BEFORE FIRST USE IMPORTANT: You should clean the hob surface (see “Cleaning and maintenance” section). SWITCHING THE HOB ON The following symbols will appear on the control panel, next to each control knob: = Gas off Large flame: maximum setting Small flame: minimum setting •... -
Page 11: Suitable Pans
SUITABLE PANS PANS BURNERS Minimum Diametre Maximum Diametre 220mm 260mm Rapid 180mm 220mm Semi-Rapid 120mm 200mm Auxilary 80mm 160mm • The diametre of the bottom of the pan should correspond to that of the burner. • The burner flame must never extend beyond the diametre of thepan. - Page 12 INSTALLATION The installation must be carried out by a suitably qualified and authorised person, in accordance with the current version of the following: • AS/NZS5601.1 Gas installations: current edition • NZS 5261: Code of Practice for the Installation of Gas Burning Appliances and Equipment (New Zealand) •...
-
Page 13: Installing The Appliance
• This appliance can be located in a kitchen, a kitchen diner or a bed sitting room. IMPORTANT: The appliance must not be installed in a bathroom or shower room. This appliance is classified as Class 3 and therefore is to be built into a kitchen unit (depending on size) or 600mm worktop, providing the following minimum distances are allowed: •... -
Page 14: Gas Connection
IMPORTANT: Do not use a silicon sealant to seal the appliance against the aperture. This will make it difficult to remove the hob from the aperture in future if it needs to be serviced. Using silicone could cause the glass to shatter and will void your warranty. Place the clamp (B) over the holes that match •... -
Page 15: Ventilation Requirements
VENTILATION REQUIREMENTS • The room containing the hob should have an air supply in accordance with the current edition of AS/NZS5601.1 Gas installations. • The room must have opening windows or equivalent; some rooms may also require a permanent vent. •... -
Page 16: Gas Adjustment (Conversion To Lpg)
• Put the gas seal inside of the 15mm x ½” female coupler. • Fully tighten the 15mm x ½” female coupler and seal onto the gas rail. IMPORTANT: The female coupler must be positioned the right way up, as shown in the •... - Page 17 DAN64GAG • DAN75GAG • DAN95GAG/P DAN95GAG • DAN60GAS • DAN2GAG POWER (MJ/h) NOZZLE KIND BURNERS mm/100 OF GAS Maximum Minimum 14.4 Large 10.8 Natural Medium 3.24 Small 15.0 L.P.G. Large 11.0 Butane Medium 3.24 Propane Small DAN9PAG • DAN9PAGW POWER (MJ/h)
-
Page 18: Minimum Flow Adjustment For Hob Gas Taps
MINIMUM FLOW ADJUSTMENT FOR HOB GAS TAPS All work must be carried out by a registered gas fitter and in accordance with current standards. IMPORTANT: Always isolate the hob from the electricity supply before changing the injectors and/or adjusting the minimum flow of the burners. •... -
Page 19: Gas Tap Maintenance
GAS TAP MAINTENANCE These maintenance operations MUST ONLY be carried out by a registered gas fitter. IMPORTANT: Before carrying out any maintenance operations, disconnect the appliance from the gas and electricity supplies. If a gas tap becomes stiff t•operate, then you should proceed as follows: •... -
Page 20: Safety Warnings
SAFETY WARNINGS PA G E 2 0 02 9604 1226 sales@danielaappliances.com.au danielaappliances.com.au... -
Page 21: Electrical Connection
ELECTRICAL CONNECTION This appliance must be installed by a qualified person in accordance with the latest edition of the AS/NZS 3000 Wiring Regulations and in compliance with the instructions outlined within this user manual. WARNING: 240 VOLTS. DISCONNECT POWER BEFORE SERVICING UNIT. Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. - Page 22 SAFETY WARNINGS DAN2GAG DAN75GAG • DAN95GAG/P • DAN95GAG PA G E 2 2 02 9604 1226 sales@danielaappliances.com.au danielaappliances.com.au...
-
Page 23: Replacing The Mains Supply Cable
REPLACING THE MAINS SUPPLY CABLE If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which The mains supply cable should be replaced in accordance with the following instructions: • Switch the appliance off at your mains supply. •... - Page 24 This appliance is marked according to the European directive 2002/96/EC for Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 25 INSTALLATION RECEIPT NUMBER: ........................If you require more information, service, warranty or spare parts enquiries please contact customer care. DANIELA APPLIANCES PTY LTD (02) 9604 1226 (9am – 5pm EST, Monday – Friday) PA G E 2 5 02 9604 1226 sales@danielaappliances.com.au...
-
Page 26: Terms And Conditions
If your goods remain boxed and in an unopened condition, they may be returned with in 30 days of the invoice date for a full refund. A collection fee of $50 will be charged should you require Daniela Appliances Pty Ltd to collect the stock. - Page 27 NOTES ....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................PA G E 2 7 02 9604 1226 sales@danielaappliances.com.au danielaappliances.com.au...
- Page 28 02 9604 1226 sales@danielaappliances.com.au A 6/9 Hume Road, Smithfield NSW 2164 danielaappliances.com.au...
