- Page 1 DAN9TY 90CM CERAMIC COOKTOP A p p l i a n c e U s e r M a n u a l danielaappliances.com.au...
- Page 2 From an Italian heritage our brand Daniela was then established in 2005 from a father’s love to a daughter and naming it after Daniela, now the new proprietor. Daniela has worked closely with her father for many years learning from his decades of industry experience. Daniela with her extensive knowledge and understanding of appliances, now continues her father’s legacy with a modern flare.
- Page 3 DAN9TY 90CM CERAMIC COOKTOP PA G E 3 02 9604 1226 sales@danielaappliances.com.au danielaappliances.com.au...
-
Page 4: Installation
SAVE THIS INSTRUCTION IN A SAFE PLACE FOR FUTURE REFERENCE Thank you for choosing Daniela appliances! Please read all instructions before using this appliance. This book contains valuable information about operation, care and service. Keep it in a safe place for future reference. -
Page 5: Operation And Maintenance
• In order to avoid a hazard, this appliance must be installed according to these instructions for installation. • This appliance is to be properly installed and earthed only by a suitably qualified person. • This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. - Page 6 IMPORTANT SAFETY INSTRUCTIONS • Never leave the appliance unattended when in use. Boil over causes smoking and greasy spillages that may ignite. • Never use your appliance as a work or storage surface. • Never leave any objects or utensils on the appliance. •...
- Page 7 • This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed and breakfast type environments. WARNING: The appliance and its accessible parts become hot during use.
-
Page 8: Product Overview
PRODUCT OVERVIEW TOP VIEW CONTROL PANEL Max. 1200 W zone Heating zone selection indicator Max. 2300/1600/800 W zone Timer indicator Max. 2000/1100 W zone Power / Timer regulating controls Max. 1200 W zone Keylock control Max. 1800 W zone ON/OFF control Glass plate Dual / Triple zone control Control panel... -
Page 9: Using The Touch Controls
USING THE TOUCH CONTROLS • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •... -
Page 10: Using Your Ceramic Hob
USING YOUR CERAMIC HOB TO START COOKING • After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the state of standby mode. Touch the ON/OFF control. -
Page 11: Locking The Controls
2. Turn the cooking zone off by touching the “-“ and scrolling down to “0 “. 3. Turn the whole cooktop off by touching the “ON/OFF” control. Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. -
Page 12: Over Temperature Protection
OVER-TEMPERATURE PROTECTION A temperature sensor equipped can monitor the temperature inside the ceramic hob. When an excessive temperature is monitored, the ceramic hob will stop operation automatically. RESIDUAL HEAT WARNING When the hob has been operating for some time, there will be some residual heat. The letter “H”... - Page 13 Adjust the timer setting by touch the “-“ or “+” controls. The minute minder indicator will start flashing and will show in the timer display. Hint: Touch the “-“ or “+” control of the timer once to decrease or increase by 1 minute.
- Page 14 Set the time by touching the control of the timer Hint: Touch the “-“ or “+” control of the timer once to decrease or increase by 1 minute. Touch and hold the “-“ or ”+” control of the timer to decrease or increase by 10 minutes. If the setting time exceeds 99 minutes, the timer will automatically return to 0 minute.
-
Page 15: Cooking Guidelines
COOKING GUIDELINES COOKING TIPS • When food comes to the boil, reduce the temperature setting. • Using a lid will reduce cooking times and save energy by retaining the heat. • Minimise the amount of liquid or fat to reduce cooking times. •... -
Page 16: Heat Settings
HEAT SETTINGS HEAT SETTING SUITABILITY 1 - 2 • delicate warming for small amounts of food • gentle simmering • melting chocolate, butter, and foods that burn quickly • slow warming 3 - 4 • reheating • rapid simmering • cooking rice 5 - 6 •... -
Page 17: Hints And Tips
This is normal for cookware and does not crackling or your cookware (layers of different metals indicate a fault. clicking noises. vibrating differently). TECHNICAL SPECIFICATION COOKING HOB DAN9TY Cooking Zones 5 zones Supply Voltage 220-240V~ Installed Electric Power 7777-9255W Product Size L×W×H(mm) 900X520X52 Building-in Dimensions A×B (mm) - Page 18 INSTALLATION Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant work surface material to avoid larger deformation caused by the heat radiation from the hotplate.
- Page 19 Before you install the hob, make sure that • the work surface is square and level, and no structural members interfere with space requirements. • the work surface is made of a heat-resistant material. • if the hob is installed above an oven, the oven has a built-in cooling fan. •...
- Page 20 Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Adjusting the bracket position Fix the hob on the work surface by screw 4 brackets on the bottom case of hob (see picture) after installation.
- Page 21 Connecting the hob to the mains power supply The power supply should be connected in compliance with the relevant standard, or a single- pole circuit breaker. The method of connection is shown below. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.
- Page 22 INSTALLATION RECEIPT NUMBER: ........................If you require more information, service, warranty or spare parts enquiries please contact customer care. DANIELA APPLIANCES PTY LTD (02) 9604 1226 (9am – 5pm EST, Monday – Friday) PA G E 2 2 02 9604 1226 sales@danielaappliances.com.au...
-
Page 23: Terms And Conditions
If your goods remain boxed and in an unopened condition, they may be returned with in 30 days of the invoice date for a full refund. A collection fee of $50 will be charged should you require Daniela Appliances Pty Ltd to collect the stock. - Page 24 02 9604 1226 sales@danielaappliances.com.au A 6/9 Hume Road, Smithfield NSW 2164 danielaappliances.com.au...
