- Page 1 DAN2CM 20CM CERAMIC COOKTOP A p p l i a n c e U s e r M a n u a l danielaappliances.com.au...
- Page 2 From an Italian heritage our brand Daniela was then established in 2005 from a father’s love to a daughter and naming it after Daniela, now the new proprietor. Daniela has worked closely with her father for many years learning from his decades of industry experience. Daniela with her extensive knowledge and understanding of appliances, now continues her father’s legacy with a modern flare.
- Page 3 DAN2CM 20CM CERAMIC COOKTOP PA G E 3 02 9604 1226 sales@danielaappliances.com.au danielaappliances.com.au...
-
Page 4: Installation
SAVE THIS INSTRUCTION IN A SAFE PLACE FOR FUTURE REFERENCE Thank you for choosing Daniela appliances! Please read all instructions before using this appliance. This book contains valuable information about operation, care and service. Keep it in a safe place for future reference. -
Page 5: Operation And Maintenance
• In order to avoid a hazard, this appliance must be installed according to these instructions for installation. • This appliance is to be properly installed and earthed only by a suitably qualified person. • This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply. - Page 6 CUT HAZARD • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted. Use with extreme care and always store safely and out of reach of children. • Failure to use caution could result in injury or cuts. IMPORTANT SAFETY INSTRUCTIONS •...
- Page 7 • Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can scratch the induction glass. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
-
Page 8: Product Overview
PRODUCT OVERVIEW TOP VIEW Max. 1800 W zone Max. 1200 W zone Glass plate ON / OFF CONTROL PANEL Control panel ON/OFF control Power or Timer regulating controls Heating zone selection controls Timer control Key/lock control PRODUCT INFORMATION The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. -
Page 9: Using The Touch Controls
USING THE TOUCH CONTROLS • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •... -
Page 10: Using Your Ceramic Hob
USING YOUR CERAMIC HOB TO START COOKING • After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the state of standby mode. Touch the ON/OFF control. -
Page 11: Locking The Controls
Turn the cooking zone off by scrolling down to “0” or touching “-” and “+” control together. 8. Turn the whole cooktop off by touching the ON/OFF control Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. -
Page 12: Over Temperature Protection
OVER-TEMPERATURE PROTECTION A temperature sensor equipped can monitor the temperature inside the ceramic hob. When an excessive temperature is monitored, the ceramic hob will stop operation automatically. RESIDUAL HEAT WARNING When the hob has been operating for some time, there will be some residual heat. The letter “H”... - Page 13 • Touching the “-” and “+” together, the timer is cancelled,and the “--” will show in the minute display. • When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. •...
- Page 14 • Touching the “-” and “+” together, the timer is cancelled, and the will show “--” in the minute display. • When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds.
-
Page 15: Cooking Guidelines
COOKING GUIDELINES COOKING TIPS • When food comes to the boil, reduce the temperature setting. • Using a lid will reduce cooking times and save energy by retaining the heat. • Minimise the amount of liquid or fat to reduce cooking times. •... -
Page 16: Heat Settings
HEAT SETTINGS HEAT SETTING SUITABILITY 1 - 2 • delicate warming for small amounts of food • gentle simmering • melting chocolate, butter, and foods that burn quickly • slow warming 3 - 4 • reheating • rapid simmering • cooking rice 5 - 6 •... -
Page 17: Hints And Tips
(layers of different metals indicate a fault. clicking noises. vibrating differently). TECHNICAL SPECIFICATION COOKING HOB DAN2CM Cooking Zones 2 zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 2700W-3300W Product Size L × W × H (mm) 288 x 520 x 52 Building-in Dimensions A ×... - Page 18 INSTALLATION Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate.
- Page 19 Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As shown below. Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm.
- Page 20 Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Adjust the bracket position to suit for different work surface’s thickness. Cautions The ceramic cooker hob must be installed by qualified personnel or technicians.
- Page 21 Connecting the hob to the mains power supply The power supply should be connected in compliance with the relevant standard, or a single- pole circuit breaker. The method of connection is shown below. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents.
- Page 22 INSTALLATION RECEIPT NUMBER: ........................If you require more information, service, warranty or spare parts enquiries please contact customer care. DANIELA APPLIANCES PTY LTD (02) 9604 1226 (9am – 5pm EST, Monday – Friday) PA G E 2 2 02 9604 1226 sales@danielaappliances.com.au...
-
Page 23: Terms And Conditions
If your goods remain boxed and in an unopened condition, they may be returned with in 30 days of the invoice date for a full refund. A collection fee of $50 will be charged should you require Daniela Appliances Pty Ltd to collect the stock. - Page 24 02 9604 1226 sales@danielaappliances.com.au A 6/9 Hume Road, Smithfield NSW 2164 danielaappliances.com.au...
