ASDATAxx , AQDATA

™
The D T monitor will output continuous data averaged over a user-defined time interval using the
UST RAK
command "ASDATAxx", where xx is a two digit value from 01-60, and represents time in seconds. The
data is averaged over the user defined time interval and is output every xx seconds. The returned seven
character string (three digits, a decimal point and three more digits) represents the average aerosol
3
reading in mg/m . The data output will continue until the command "AQDATA" is received by the
™
D T monitor.
UST RAK
THE ASDATA FUNCTION DOES NOT WORK PROPERLY FOR
D T
UST RAK

Serial Interface Connections

With the instrument lying flat on a table face up with the data port facing you, pin 1 is on the right side and
pin 8 is on the left.

Data Port Pin Assignments

Pin Number Function
1 Not used
2 Not used
3 Receive data (Rx)
4 Data Set Ready (DSR)
5 Transmit data (Tx)
6 Not used
7 Signal Ground (G)
8 Data Terminal Ready (DTR)
Cable Wiring for Communications with IBM-PC compatible Computer Using
25-Pin, or 9-Pin RS-232 Port
Instrument Data Port Computer 25-Pin Connector
Pin (Use TSI 800560 Cable)
1
2
3
4
5
6
7
8
TSI Incorporated – Visit our website www.tsi.com for more information.
USA Tel: +1 800 874 2811
UK Tel: +44 149 4 459200
France Tel: +33 4 91 11 87 64
Germany Tel: +49 241 523030
ITI-044 Rev. B (9/26/2012) ©2012 TSI Incorporated
NOTE
™ MONITORS WITH FIRMWARE REVISIONS BELOW v1.9.
Direction
To D
From D
From D
To D
8
5
2
6
3
22
7
20
India Tel: +91 80 67877200
China Tel: +86 10 8251 6588
Singapore Tel: +65 6595 6388
Printed in U.S.A.
™
T monitor
UST RAK
™
T monitor
UST RAK
™
T monitor
UST RAK
™
T monitor
UST RAK
Computer 9-Pin Connector
(Use TSI 800563 Cable)
1
8
3
6
2
9
5
4
