UG241: EFM8UB2-SLSTK2001A User's Guide
Kit Block Diagram
2. Kit Block Diagram
An overview of the EFM8UB2 Starter Kit is shown in the figure below.
Board
USB Micro-B
Controller
EFM8UB2
Connector
Microcontroller
Joystick
Figure 2.1. EFM8UB2-SLSTK2001A Block Diagram
silabs.com | Building a more connected world.
Rev. 0.3 | 3
