UG591: EFR32xG22E Energy Harvesting
Explorer Kit
EFR32xG22E Energy Harvesting Explorer Kit is an excellent starting point to explore
and evaluate different Energy Harvesting solutions with Silicon Labs' Multiprotocol
Wireless Systems on Chip (SoC).
This unique Energy Harvesting kit selection includes a lightweight board with one of
Silicon Labs most popular Multi-protocol Wireless SoCs, based on the Explorer Kit plat-
form, and different shields and adapters which, combined with the Explorer Kit's fea-
tures enable evaluation of multiple solutions for Energy Harvesting, making use of en-
ergy sources like photovoltaic cells, inductive or piezoelectric sources, Thermoelectric
Generators (TEG), in different applications, for example pulsed or continuous supply,
single or dual source.
• The Dual Harvester Shield is the most flexible shield, that can be used to harvest
energy from one or two sources at the same time. Typical use case scenarios are
complimentary photovoltaic cells, one photovoltaic cell and one piezoelectric source
taking energy from vibrations, etc. Adapters, for interfacing AC and DC sources to
the Dual Harvester Shield, are also provided
• The Kinetic Button Shield is engineered to demonstrate a specific application, using
an inductive switch, aka kinetic switch, to temporarily power the Wireless SoC and
transmit a sequence of packages, typically for interacting with a light bulb or coordi-
nator
• A supplementary Battery Shield is provided for debugging for example stand-alone
operation scenarios or evaluating battery lifetime
When connected to the Explorer Kit, the shield supplies exclusively the Wireless SoC,
while the debugger is left powered off, allowing stand-alone operation and true real-
time current measurements.
silabs.com | Building a more connected world.
Copyright © 2025 by Silicon Laboratories
FEATURES
• Energy Harvesting
• Self-powered operation
• Flexible PMIC
• Hardware and Software configurable
registers
• AC and DC sources
• Automatic power selection (self-powered
or debugger)
• Test Points for current and voltage
measurements
• Single or Dual source
ITEMS INCLUDED IN THIS KIT:
• BRD8201A Dual Harvester Shield
• BRD8202A Kinetic Button Shield,
equipped with the BRD8206A Kinetic
Switch Adapter
• BRD8203A Battery Shield
• BRD8204A AC Input Adapter
• BRD8205A DC Input Adapter
• BRD2710A EFR32xG22E Explorer Board
• 1x photovoltaic cell
• 1x lithium capacitor
ORDER INFORMATION:
• xG22-EK8200A
Rev. 1.0
