Pepperl+Fuchs UC2000-L2-E7-V15 Quick Start Manual page 3

Ultrasonic sensor
Technical Data
Output 2
Beam width
Evaluation procedure
General information
Supplementary information
Connection
1
L+
4
Switch output 1
2
Switch output 2
5
Synchronization
3
L-
Connection Assignment
1
5
2
3
Wire colors in accordance with EN 60947-5-2
1 BN (brown)
2 WH (white)
3 BU (blue)
4 BK (black)
5 GY (gray)
Characteristic Curve
Characteristic response curve
Distance Y [mm]
1000
flat surface 100 mm x 100 mm
800
600
400
200
0
-200
-400
round bar, Ø 25 mm
-600
0 500 1000 1500 2000 2500
Y
wide sound lobe
X
narrow sound lobe
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: +1 330 486 0001
www.pepperl-fuchs.com fa-info@us.pepperl-fuchs.com
near switch point: 150 mm
far switch point: 1000 mm
output function: Window mode
output behavior: NO contact
wide
averaging (MxN)
M = 5
N = 2
Switch settings of the external programming adapter:
"output load": pull-up
"output logic": inv
4
3000 3500 4000
Distance X [mm]
Germany: +49 621 776 1111
fa-info@de.pepperl-fuchs.com
Singapore: +65 6779 9091
fa-info@sg.pepperl-fuchs.com
UC2000-L2-E7-V15
3
