Supermicro SuperServer SYS-E302-12D-4C User Manual page 14

Connector
JMD3
JMD1_SRW1, JMD2_SRW1/2
JMD3_SRW1
JNVI2C1, JNVI2C2
JOPPS
JPH1
JPI2C1
JPWR1
JPV1
JRK1
JSD1
JSDP1 - JSDP4
JSFPLED1
JSIM1
JSLIM1, JSLIM2
JSMB1
JSTBY1
JTPM1
JUIDB1
LAN1/2, LAN3/4
LAN5/6
MH1 - MH6
SLOT6
SLOT7
USB0/1, USB2/3
USB4/5
VGA
Description
M.2 PCIe 3.0 x1 or USB 2.0 Slot (E-Key 2230)
M.2 Mounting Holes
Non-Volatile Memory (NVMe) I
2
Reserved for One Pulse Per Second
4-pin HDD Power Connector
Power System Management (SMB) I
24-pin ATX Power Connector (Required)
8-pin CPU Power Connector (Required)
Intel RAID Key Header
SATA DOM Power Connector
Reserved for time synchronization
LAN5/6 Activity LED header
NANO SIM Slot for JMD2
SlimSAS PCIe 3.0 x4 Slots
System Management Bus Header
Standby Power Header
Trusted Platform Module (TPM)/Port 80 Connector
Unit Identifier Switch
Gigabit Ethernet RJ45 Ports
25GbE SFP28 LAN Ports
Motherboard Mounting Holes
CPU SLOT6 PCIe 4.0 x8
CPU SLOT7 PCIe 4.0 x16
Front Accessible USB 2.0 Headers
Back Panel USB 3.0 Ports
VGA Port
14
Chapter 1: Introduction
C Headers
C Header
2
