SuperServer
®
SYS-E302-12D-4C
SYS-E302-12D-8C
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SuperServer SYS-E302-12D-4C and is the answer not in the manual?

Questions and answers

Related Manuals for Supermicro SuperServer SYS-E302-12D-4C

Summary of Contents for Supermicro SuperServer SYS-E302-12D-4C

  • Page 1 SuperServer ® SYS-E302-12D-4C SYS-E302-12D-8C USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View and Control Panel .....................9 Rear View ..........................10 Chassis Dimensions ......................11 1.3 Motherboard Layout ......................12 Quick Reference Table ......................13 Motherboard Block Diagram .....................15 Motherboards ........................16 Chapter 2 Server Installation 2.1 Overview ..........................17 2.2 Preparing for Setup ......................17 Choosing a Setup Location ....................17...
  • Page 5 Preface 3.4 Motherboard Battery ......................29 3.5 Storage Drives ........................30 Installing the Storage Drive ....................30 M.2 Solid State Drives .....................32 Installing an M.2 SSD ....................32 Chapter 4 Motherboard Connections 4.1 Power Connections ......................33 4.2 Headers and Connectors ....................35 Control Panel .........................40 4.3 Input/Output Ports ......................43 Rear I/O Ports ........................43 4.4 Jumpers ..........................46...
  • Page 6 Preface 7.4 Crash Dump Using BMC ....................62 7.5 UEFI BIOS Recovery ......................63 Overview ...........................63 Recovering the UEFI BIOS Image ..................63 Recovering the Main BIOS Block with a USB Device ............63 7.6 CMOS Clear ........................68 7.7 Where to Get Replacement Components ................69 7.8 Reporting an Issue ......................69 Technical Support Procedures ..................69 Returning Merchandise for Service ...................69...
  • Page 7 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    (WxHxD) 11.6 x 2.9 x 8.1 in (295 x 73 x 205 mm) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-E302-12D-4C/8C have been certified...

  • Page 9: System Features

    Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View and Control Panel The CSE-E302iL is a compact embedded 1U chassis for Mini ITX and Flex ATX motherboards. See the figure below for the features included on the front of the chassis.

  • Page 10: Rear View

    Chapter 1: Introduction Rear View IPMI LAN Port Power Input K-slot VGA Port Two SFP28 Ports Four GbE LAN Ports USB 3.0 Ports Figure 1-2. System: Rear View System Features: Rear Feature Description The main power switch applies or removes primary power from the power supply to the Power input server but maintains standby power.

  • Page 11: Chassis Dimensions

    Chapter 1: Introduction Chassis Dimensions The compact chassis measures 205 x 295.2mm from the top view and 275.2 x 73.2mm from the I/O view. 295.2 Figure 1-3. Chassis Dimensions (Top View) 275.2 Figure 1-4. Chassis Dimensions (I/O View)

  • Page 12: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the X12SDV-4C-SP6F motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4 or the Motherboard Manual.

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting Pins 1-2: High Active (Default) SIM Card Detection Pins 2-3: Low Active Pins 1-2: IPMI Share Lan Disabled JBM1 Disable IPMI Share LAN Open: IPMI Share Lan Enabled (Default) JBT1 CMOS Clear Open (Normal) Pins 1-2: 4X SATA...
  • Page 14 Chapter 1: Introduction Connector Description JMD3 M.2 PCIe 3.0 x1 or USB 2.0 Slot (E-Key 2230) JMD1_SRW1, JMD2_SRW1/2 M.2 Mounting Holes JMD3_SRW1 JNVI2C1, JNVI2C2 Non-Volatile Memory (NVMe) I C Headers JOPPS Reserved for One Pulse Per Second JPH1 4-pin HDD Power Connector JPI2C1 Power System Management (SMB) I C Header...

  • Page 15: Motherboard Block Diagram

    Chapter 1: Introduction Motherboard Block Diagram DDR4 2400/2667/2933 MHz PCIe 4.0 x16 PE1[15:0] PCIe Switch JPCIe1 SLOT7 PCIe 4.0 x16 JLAN1 25G PHY JPCIe2 SLOT6 PCIe 4.0 x8 PCIe 3.0 x1 I210IT Flexible I/O SFP28 PCIe 3.0 x1 Quad0 Flexible I/O I210IT Lane 0,2 JLAN2...

  • Page 16: Motherboards

    Chapter 1: Introduction Motherboards The table below lists the systems and their corresponding motherboards and processors. Systems Feature SYS-E302-12D-4C SYS-E302-12D-8C Motherboard X12SDV-4C-SP6F X12SDV-8C-SP6F Processor D-1718T D-1736NT Cache 10MB 15MB Processor TDP Processor Base Frequency 2.6 GHz 2.7 GHz Intel Turbo Boost Technology Number of Memory Channels Intel QuickAssist Technology Intel Virtualization Technology...

  • Page 17: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those components.

  • Page 18: Server Precautions

    Chapter 2: Server Installation • In single-rack installations, stabilizers should be attached to the rack. In multi-rack instal- lations, the racks should be coupled together. • Always verify that the rack is stable before extending a server or other component from the rack.

  • Page 19: Mechanical Loading

    Chapter 2: Server Installation Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 20: Adding Components To Your System

    Chapter 2: Server Installation Adding Components to your System • Memory: If your system is not already fully integrated with system memory, refer to Chapter 3 for details on compatible types of memory and the installation procedure. • Drives and Storage: To add storage capabilities to your server, see Chapter 3. •...

  • Page 21: Mounting On A Wall

    Chapter 2: Server Installation 2.3 Mounting on a Wall The chassis can be mounted on a wall using a bracket (optional, MCP-290-30201-0B). 1. Secure the bracket to the wall where you want the server to be mounted by using four screws through the holes around the center of the bracket, as shown below.
  • Page 22 Chapter 2: Server Installation 3. With the input/output ports facing up, hang the server on the mounting bracket by hooking the four keyholes on the bottom of the chassis on the four knobs of the bracket. Figure 2-3. Hanging Server on the Bracket 4.
  • Page 23 Chapter 2: Server Installation 6. The power adapter can be secured to this lower bracket by partially unscrewing its latch, sliding the latch upward, placing the power adapter in the bracket, lowering the latch, and tightening the screw to secure it in place. Power Adapter Bracket Latch Screw of Power Adapter Bracket Latch Figure 2-5.

  • Page 24: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 25: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The CSE-E302iL features a removable top cover to access the inside of the chassis. Screws Screws Figure 3-1. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 3.1. 2.

  • Page 26: Memory

    Use a grounded wrist strap designed to prevent static discharge. • Handle the memory module by its edges only. • Put the memory modules into the antistatic bags when not in use. • Check the Supermicro website for recommended memory modules. Recommended Population (Balanced) DIMMA1 DIMMB1 DIMMA2 DIMMB2...

  • Page 27: General Guidelines For Optimizing Memory Performance

    Chapter 3: Maintenance and Component Installation General Guidelines for Optimizing Memory Performance When installing memory modules, the DIMM slots should be populated in the following order: DIMMA1, DIMMB1, DIMMA2, DIMMB2. • Always use DDR4 DIMM modules of the same type and speed. •...

  • Page 28: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation Caution: Exercise extreme caution when installing or removing memory modules to prevent any possible damage to the DIMMs or slots. Begin by removing power from the system as described in Section 3.1. 1.

  • Page 29: Motherboard Battery

    Chapter 3: Maintenance and Component Installation 3.4 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 30: Storage Drives

    Chapter 3: Maintenance and Component Installation 3.5 Storage Drives Installing the Storage Drive The CSE-E302iL can accommodate one fixed 2.5" storage drive of 7mm height, installed to a mounting tray inside the chassis. Installing the Hard Drive The motherboard should be installed before installing the drive(s). 1.
  • Page 31 Chapter 3: Maintenance and Component Installation Figure 3-5. Preparing to Install the Hard Drive 7. Connect the drive data and power cables. 8. Secure the tray to the chassis by pushing the tray down into the slots. 9. Attach the cables to the appropriate motherboard connector(s). 10.

  • Page 32: Solid State Drives

    Chapter 3: Maintenance and Component Installation M.2 Solid State Drives The motherboard supports three M.2 slots, one M.2 PCIe 3.0 x4 or SATA 3.0 Slot (M-Key 2280), one M.2 PCIe 3.0 x2 or SATA 3.0 or USB 3.0 Slot (B-Key 2280/3042/3052), and one M.2 PCIe 3.0 x1 or USB 2.0 Slot (E-Key 2230).

  • Page 33: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 34 Chapter 4: Motherboard Connections 8-Pin Power Connector The 8-pin (JPV1) connector is used to provide alternative power for a special enclosure when the 24-pin ATX power is not in use. Refer to the table below for pin definitions. 8-pin Power Pin Definitions Pin# Definition...

  • Page 35: Headers And Connectors

    Chapter 4: Motherboard Connections JMD3 4.2 Headers and Connectors M.2-H PCIe 3.0 X1 Chassis Intrusion A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable 3_SRW1 from the chassis to inform you of a chassis intrusion when the chassis is opened. Refer to the table below for pin definitions.
  • Page 36 Chapter 4: Motherboard Connections Disk-On-Module Power Connector One power connector for SATA Disk-On-Module (DOM) devices is located at JSD1. Connect appropriate cables here to provide power support for your Serial Link DOM devices. DOM Power Pin Definitions Pin# Definition Ground Ground Fan Headers There are six 4-pin fan headers (FAN1 - FAN4, FANA, FANB) on the motherboard.
  • Page 37 I-SATA 3.0 Ports This motherboard has two I-SATA 3.0 ports (I-SATA1, I-SATA3). I-SATA1 can be used with Supermicro SuperDOMs that are yellow SATA DOM connectors with power pins built in, and do not require external power cables. Supermicro SuperDOMs are backwards compatible with regular SATA HDDs or SATA DOMs that need external power cables.
  • Page 38 The SlimSAS connectors at JSLIM1 and JSLIM2 support PCIe 3.0 x4 devices. NVMe I C Header Connectors JNVI2C1 and JNVI2C2 are management headers for the Supermicro AOC NVMe PCIe peripheral cards. Connect the I C cable to these connectors. Power SMB (I...
  • Page 39 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...

  • Page 40: Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 41 Chapter 4: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button. To turn off the power when the system is in suspend mode, press the button for four seconds or longer.
  • Page 42 Chapter 4: Motherboard Connections HDD LED The HDD LED connection is located on pins 13 and 14 of JF1. Attach a cable to pin 14 to show hard drive activity status. Refer to the table below for pin definitions. HDD LED Pin Definitions (JF1) Pins Definition...

  • Page 43: Input/Output Ports

    Chapter 4: Motherboard Connections 4.3 Input/Output Ports Rear I/O Ports See the figure below for the locations and descriptions of the I/O ports on the rear of the motherboard. JPL1 JBM1 JPG1 JSDP2 JSDP3 JPL2 JLANLED3 AST2600 Intel IPMI_LAN JLAN2 i350-AM2 JLAN1 USB4/5 (3.0)
  • Page 44 Chapter 4: Motherboard Connections VGA Port A video (VGA) port is located on the I/O back panel. LAN Ports Four Gigabit Ethernet RJ45 ports (LAN1/2/3/4) and two SFP28 25G LAN ports (LAN5/6) are located on the I/O back panel. There is also a dedicated IPMI LAN above the USB4/5 ports on the back panel.
  • Page 45 Chapter 4: Motherboard Connections Universal Serial Bus (USB) Ports There are two USB 3.0 ports (USB4/5) on the I/O back panel and two USB 2.0 headers (USB0/1 and USB2/3) on the motherboard. The onboard headers can be used to provide front side USB access with a cable (not included).

  • Page 46: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers Connector Pins To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 Jumper is identified with a square solder pad on the printed circuit board.
  • Page 47 Chapter 4: Motherboard Connections Watchdog Watchdog (JWD1) is a system monitor that can reboot the system when a software application hangs. Close pins 1-2 to reset the system if an application hangs. Close pins 2-3 to generate a non-maskable interrupt (NMI) signal for the application that hangs. Refer to the table below for jumper settings.
  • Page 48 Chapter 4: Motherboard Connections LAN Port Enable/Disable Use JPL1 to enable or disable LAN1, JPL2 to enable or disable LAN2, and JPL3 to enable or disable LAN3/4. The default setting is Enabled. LAN Port Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3...

  • Page 49: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators Power LED LED1 is the Power LED. When this LED is lit, power is present on the motherboard. In suspend mode, this LED will blink on and off. Turn off the system and unplug the power cord before removing or installing components.
  • Page 50 Chapter 4: Motherboard Connections LAN LEDs Four LAN ports (LAN1 - LAN4) are located on the I/O back panel of the motherboard. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection. Refer to the tables below for more information.

  • Page 51: Chapter 5 Software

    1. Create a method to access the MS Windows installation ISO file. That might be a USB flash drive or media drive, or the BMC KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 52 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 53: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or media drive.

  • Page 54: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 55: Bmc

    There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 56: Chapter 6 Optional Components

    Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes optional system components. 6.1 Optional Parts List Optional Parts List Description Part Number Quantity Wall Mount Kit MCP-290-30201-0B Cable CBL-0473L Cable CBL-SAST-0886...

  • Page 57: Chapter 7 Troubleshooting And Support

    Chapter 7: Troubleshooting and Support Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by the Products option. •...

  • Page 58: Baseboard Management Controller (Bmc)

    Security Center for recent security notices Supermicro Phone and Addresses 7.2 Baseboard Management Controller (BMC) The system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring and management. There are several BIOS settings that are related to BMC.

  • Page 59: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support 7.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Power down the system before changing any non hot-swap hardware components.

  • Page 60: No Video

    • Memory: Make sure that the memory modules are supported. Refer to the product page on our website at www.supermicro.com. Test the modules using memtest86 or a similar utility. • Storage drives: Make sure that all drives work properly. Replace if necessary.
  • Page 61 Also check the Control panel Overheat LED. • Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Refer to the Supermicro website for the minimum power requirements. •...

  • Page 62: Crash Dump Using Bmc

    In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using BMC. The BMC manual is available at https://www.supermicro.com/en/solutions/ management-software/bmc-resources. Check BMC Error Log 1.

  • Page 63: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 64 USB flash or media drive. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 65 Chapter 7: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 66 Chapter 7: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
  • Page 67 Chapter 7: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen below indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.

  • Page 68: Cmos Clear

    Chapter 7: Troubleshooting and Support 7.6 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.

  • Page 69: Where To Get Replacement Components

    7.7 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 70: Vendor Support Filing System

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 7.9 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.

  • Page 71: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 72 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 73 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 74 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 75 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 76 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 77 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 78 Appendix A: Warning Statements ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 79 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 80 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 81 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 82 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 83 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 84 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 85 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 86 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 87 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 88 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 89 ‫حجم املوصل والقابس السليم. استخدام أي كابالت ومحوالت أخرى قد يتسبب يف عطل أو حريق. يحظر قانون السالمة لألجهزة الكهربائية واملعدات استخدام الكابالت املعتمدة‬ ‫ من قبل‬UL ‫ أو‬CSA ‫( والتي تحمل عالمة‬UL/CSA) ‫ مع أي معدات أخرى غري املنتجات املعنية واملحددة من قبل‬Supermicro.
  • Page 90 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 91: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Supports an Intel Xeon D-1700 series processor with a thermal design power (TDP) of up to 67W Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. BIOS 256Mb SPI Flash with AMI BIOS®...
  • Page 92 Appendix B: System Specifications Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B Class A ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 EN/BS 55032 EN/BS 55035 CISPR 32 CISPR 35 EN/BS 61000-3-2 EN/BS 61000-3-3 EN/BS 61000-4-2 EN/BS 61000-4-3 EN/BS 61000-4-4...
