Rear View

IPMI LAN Port
Power
Input
Feature Description
The main power switch applies or removes primary power from the power supply to the
Power input server but maintains standby power. To perform most maintenance tasks, unplug the
system to remove all power.
LAN Ports One dedicated IPMI LAN port, four GbE LAN ports, two 25G SFP28 ports
USB Ports Two USB 3.0 ports
VGA Port Video port
K-slot for lock Accepts a standard Kensington cable locking device (not included).
Figure 1-2. System: Rear View
System Features: Rear
10
Chapter 1: Introduction
VGA Port
Two SFP28 Ports
Four GbE LAN Ports
USB 3.0 Ports
K-slot
