SATA Product Manual
Standard models
ST6000VN001
100856098, Rev. A
July 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRONWOLF ST6000VN001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Seagate IRONWOLF ST6000VN001

  • Page 1 SATA Product Manual Standard models ST6000VN001 100856098, Rev. A July 2019...
  • Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. IronWolf and SeaTools are either trade- marks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
  • Page 3: Table Of Contents

    Seagate® Technology Support Services ........
  • Page 4 S.M.A.R.T. commands............. . 33 Seagate IronWolf Product Manual, Rev. A...
  • Page 5 Mounting dimensions (6TB models) ............23 Seagate IronWolf Product Manual, Rev. A...
  • Page 6: SeagateĀ® Technology Support Services

    For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate IronWolf Product Manual, Rev. A...
  • Page 7: Introduction

    • Supports ATA8 streaming commands • Supports latching SATA cables and connectors • Transient power on management - <=1.8A spin-up current • Workload ratings of 180TB/year • Worldwide Name (WWN) capability uniquely identifies the drive Seagate IronWolf Product Manual, Rev. A...
  • Page 8: About The Sata Interface

    SATA ports are represented to host software as a Device 0 (master) and Device 1 Note (slave) accessed at the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two sets of shadow registers. This is not a typical SATA environment. Seagate IronWolf Product Manual, Rev. A...
  • Page 9: Drive Specifications

    Operating temperature (drive case max °C) 70° 20°C per hour max (operating) Temperature gradient 30°C per hour max (non-operating) 5% to 90% (operating) Relative humidity 5% to 95% (non-operating) Relative humidity gradient (max) 30% per hour Seagate IronWolf Product Manual, Rev. A...
  • Page 10 † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. The operating case temperature is 0 to 70C (32 to 158F).
  • Page 11: Formatted Capacity

    Recording and interface technology Models Interface SATA Recording density (kBPI) 2197 Track density (ktracks/inch avg) Areal density (Gb/in Interface transfer rate (MB/s) Data transfer rate (MB/s) up to 190 Seagate IronWolf Product Manual, Rev. A...
  • Page 12: Physical Characteristics

    Standby to ready 15 (typical) (in seconds) Ready to spindle stop 18 (typical) (in seconds) Time-to-ready may be longer than normal if the drive power is removed without going through normal OS powerdown procedures. Seagate IronWolf Product Manual, Rev. A...
  • Page 13: Power Specifications

    • Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note Seagate IronWolf Product Manual, Rev. A...
  • Page 14: Voltage Tolerance

    If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all com- mands and returns to Active mode when disk access is necessary. Seagate IronWolf Product Manual, Rev. A...
  • Page 15: Environmental Specifications

    † Operating (Drive case max °C) 70° (158°F) † Seagate does not recommend operating at sustained case temperatures above 60°C. Operating at higher temperatures will reduce useful life of the product. HDA Temp. Check Point Location of the HDA temperature check point Note Image is for reference only, may not represent actual drive.
  • Page 16: Altitude

    The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 5Hz to 22Hz 3.0 Gs (Limited displacement) 22Hz to 350Hz 3.0 Gs 350Hz to 500Hz 3.0 Gs Seagate IronWolf Product Manual, Rev. A...
  • Page 17: Acoustics

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.
  • Page 18: Warranty

    2.11.2 Storage Maximum storage periods are 180 days within original unopened Seagate shipping package or 60 days unpackaged within the defined non-operating limits (refer to environmental section in this manual). Storage can be extended to 1 year packaged or unpackaged under optimal environmental conditions (25°C, <40% relative humidity non-condensing, and...
  • Page 19: Australian Rcm Compliance Mark

    2.12.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user.
  • Page 20: Fcc Verification

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
  • Page 21: China Requirements -China Rohs 2

    The European Union REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Regulation (EC) 1907/ 2006 regulates chemicals shipped into and used in Europe. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of REACH substances in these articles and materials.
  • Page 22: Taiwan Requirements - Taiwan Rohs

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging.
  • Page 23: Configuring And Mounting The Drive

    For installations which require cables, users can connect the drive as illustrated in Figure 1 Figure 1 Attaching SATA cabling Each cable is keyed to ensure correct orientation. IronWolf drives support latching SATA connectors. Seagate IronWolf Product Manual, Rev. A...
  • Page 24: Drive Mounting

    • Do not overtighten the mounting screws (maximum torque: 6 inch-lb). Figure 2 Mounting dimensions (6TB models) 3X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION BOTH SIDES 4X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.14 MAXIMUM FASTENER PENETRATION Seagate IronWolf Product Manual, Rev. A...
  • Page 25: Sata Interface

    There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate back- plane configuration. • All used voltage pins (V ) must be terminated. Seagate IronWolf Product Manual, Rev. A...
  • Page 26: Supported Ata Commands

    Read Sectors Extended Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seagate IronWolf Product Manual, Rev. A...
  • Page 27 Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate IronWolf Product Manual, Rev. A...
  • Page 28: Identify Device Command

    Capabilities: (see 7.17.7.17) 15 Shall be cleared to zero 14 Shall be set to one 4000 13:2 Reserved 1 Obsolete 0 Shall be set to one to indicate a vendor specific Standby timer value minimum Seagate IronWolf Product Manual, Rev. A...
  • Page 29 6 0 = Optional ATA device 28-bit commands supported 5 Trimmed LBA range(s) returning zeroed data is supported 4 Device Encrypts All User Data 3 Extended Number of User Addressable Sectors is supported 2 All write cache is non-volatile 1:0 Reserved Seagate IronWolf Product Manual, Rev. A...
  • Page 30 Commands and feature sets supported 41DE Commands and feature sets supported or enabled 409C 121-127 ATA-reserved 0000 Security status 0021 129–159 Seagate-reserved xxxx 160–167 ATA-reserved 0000 Device Nominal Form Factor 0002 169-205 ATA-reserved 0000 Seagate IronWolf Product Manual, Rev. A...
  • Page 31 Integrity word xxA5 Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported. Note See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Seagate IronWolf Product Manual, Rev. A...
  • Page 32 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate IronWolf Product Manual, Rev. A...
  • Page 33: Set Features Command

    Disable use of SATA features Enable read look-ahead (read cache) feature (default) Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above. Seagate IronWolf Product Manual, Rev. A...
  • Page 34: Commands

    S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate IronWolf Product Manual, Rev. A...
  • Page 35 Seagate Technology LLC AMERICAS Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 Publication Number: 100856098, Rev. A July 2019...
