Product Manual
Seagate
Enterprise NAS HDD
®
ST6000VN0011
ST5000VN0011
ST4000VN0011
ST3000VN0011
ST2000VN0011
Gen 2
100771866
Rev. B
February 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST6000VN0011 and is the answer not in the manual?

Questions and answers

Related Manuals for Seagate ST6000VN0011

Summary of Contents for Seagate ST6000VN0011

  • Page 1 Product Manual Seagate Enterprise NAS HDD ® ST6000VN0011 ST5000VN0011 ST4000VN0011 ST3000VN0011 ST2000VN0011 Gen 2 100771866 Rev. B February 2015...
  • Page 2 States and/or other countries. Enterprise NAS HDD v2 and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trade- marks or registered trademarks are the property of their respective owners.

  • Page 3: Table Of Contents

    Seagate® Technology Support Services ........
  • Page 4 Mounting dimensions (6TB model) ..........19 Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 5: Seagate Technology Support Services

    Authorized Service Centers For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 6: Introduction

    Introduction ® This manual describes the functional, mechanical and interface specifications for the following: Seagate Enterprise NAS HDD +SRS model drives: +SRS models ST6000VN0011 ST5000VN0011 ST4000VN0011 ST3000VN0011 ST2000VN0011 These drives provide the following key features: • Off-the-shelf compatibility • Rated for 1M hours MTBF •...

  • Page 7: Drive Specifications

    –40° to 70°C (non-operating) 20°C per hour max (operating) Temperature gradient 30°C per hour max (nonoperating) 5% to 90% (operating) Relative humidity 5% to 95% (nonoperating) Relative humidity gradient (max) 30% per hour Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 8: Formatted Capacity

    ST2000VN0011 2000GB 3,907,029,168 *One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 9: Lba Mode

    101.6mm / 4.0 in (± 0.010 in) Maximum length 146.99mm / 5.787 in Typical weight 780g / 1.72 lb 700g / 1.54 lb 620g / 1.372 lb 540g / 1.19 lb Cache buffer 128MB Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 10: Seek Time

    Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track loca- tion. • Standby mode During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write electronics are in power-down mode. Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 11: Conducted Noise

    • Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note 2.8.3 Voltage tolerance Voltage tolerance (including noise): • 5V ±5% • 12V +10%/-7.5% Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 12: Power-Management Modes

    0° to 70°C (32° to 158°F) Non-operating –40° to 70°C (–40° to 158°F) 2.9.2 Temperature gradient Operating 20°C per hour (68°F per hour max), without condensation Non-operating 30°C per hour (86°F per hour max) Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 13: Humidity

    The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 5Hz to 22Hz 3.0 Gs (Limited displacement) 22Hz to 350Hz 3.0 Gs 350Hz to 500Hz 3.0 Gs Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 14: Acoustics

    Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.

  • Page 15: Seagate® Rescue™ Data Recovery Service - 3-Year Coverage (Concurrent With Bare Drive Warran

    3-year coverage (concurrent with bare drive warranty) If you suffer a data loss event within the three year Seagate Rescue Data Recovery warranty period, and you are eligible to participate in and submit a case under the Rescue program, contact SRS at (1-800-723-1183) in the US, or if you are calling from outside the US please visit our website for numbers in your local and language: http://www.seagate.com/contacts/contact-numbers/.
  • Page 16 Seagate reserves the right to refuse service to or the return of any storage devices that have been determined to violate these regulations.

  • Page 17: Agency Certification

    Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.

  • Page 18: Environmental Protection

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.

  • Page 19: Configuring And Mounting The Drive

    • Use only 6-32 UNC mounting screws. • The screws should be inserted no more than 0.150 inch (3.81mm) into the bottom or side mounting holes. • Do not overtighten the mounting screws (maximum torque: 6 inch-lb). Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...
  • Page 20 2X 6-32 UNC 2B 3.750±.010 3 MIN THREAD DEPTH 4.000±.010 .15 MAX FASTENER PENETRATION MOUNTING HOLES BOTH SIDES. MAX TORQUE 6 IN/LBS 1.028 MAX 26.11 MM .142±.015 2 2.000 C L OF DRIVE Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 21: Sata Interface

    There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate back- plane configuration. • All used voltage pins (V ) must be terminated. Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 22: Supported Ata Commands

    Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Set Features Set Max Address Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...
  • Page 23 Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 24: Identify Device Command

    48-bit addressing feature. Retired 0000 Multiword DMA active and modes supported xx07 (see note following this table) Advanced PIO modes supported (modes 3 and 4 supported) 0003 Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...
  • Page 25 Advanced Power Management (APM) and Automatic Note Acoustic Management (AAM) features are not supported. See the bit descriptions below for words Note 63, 84, and 88 of the Identify Drive data. Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...
  • Page 26 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 27: Set Features Command

    Enable read look-ahead (read cache) feature (default) Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...

  • Page 28: Commands

    S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Enterprise NAS HDD +SRS Product Manual, Rev. B...
  • Page 29 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100771866, Rev. B...
