- Page 1 Surveillance HDD SATA Product Manual ST8000VX0002 ST6000VX0001 ST5000VX0001 100762250, Rev. H Gen 3 - January 2016...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 Mounting dimensions ............... . . 18 Seagate Surveillance HDD Product Manual, Rev. H...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/seagate-recovery- services/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Surveillance HDD Product Manual, Rev. H... -
Page 6: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following: Seagate® Surveillance HDD model drives: ST8000VX0002 ST6000VX0001 ST5000VX0001 These drives provide the following key features: • Reliability for 24×7 video surveillance applications • Thermal monitoring and reporting for 24×7 operations •... -
Page 7: Drive Specifications
Operating temperature (Drive case min °C) † Operating temperature (Drive case max °C) 20°C per hour max (operating) Temperature gradient 30°C per hour max (nonoperating) 5% to 90% (operating) Relative humidity 5% to 95% (nonoperating) Seagate Surveillance HDD Product Manual, Rev. H... - Page 8 * ** During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. † Recommend 60°C or less case temperature under sustained work conditions. Seagate Surveillance HDD Product Manual, Rev. H...
-
Page 9: Formatted Capacityy
Track density (ktracks/inch avg) Areal density (Gb/in 1333 Internal data transfer rate (Mb/s max) 2546 2347 Maximum sustained data transfer rate, OD read (MB/s) Average data rate, read/write (MB/s) I/O data-transfer rate (MB/s max) Seagate Surveillance HDD Product Manual, Rev. H... -
Page 10: Physical Characteristics
(in seconds) 20 (max) Ready to spindle stop 10 (typical) (in seconds) 11 (max) Time-to-ready may be longer than normal if the drive power is removed without going through normal OS powerdown procedures. Seagate Surveillance HDD Product Manual, Rev. H... -
Page 11: Power Specifications
• Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note Seagate Surveillance HDD Product Manual, Rev. H... -
Page 12: Voltage Tolerance
If the standby timer reaches zero before any drive activity is required, the drive makes a transi- tion to Standby mode. In both Idle and Standby mode, the drive accepts all commands and returns to Active mode when disk access is necessary. Seagate Surveillance HDD Product Manual, Rev. H... -
Page 13: Environmental Specifications
Wet bulb temperature Operating 26°C / 78.8°F (rated) Non-operating 29°C / 84.2°F (rated) 2.9.4 Altitude Operating –304m to 3048m (–1000 ft. to 10,000 ft.) Non-operating –304m to 12,192m (–1000 ft. to 40,000+ ft.) Seagate Surveillance HDD Product Manual, Rev. H... -
Page 14: Shock
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 15: Electromagnetic Immunity
Storage Maximum storage periods are 180 days within original unopened Seagate shipping package or 60 days unpackaged within the defined non-operating limits (refer to environmental section in this manual). Storage can be extended to 1 year packaged or unpackaged under optimal environmental conditions (25°C, <40% relative humidity non-condensing, and non-corrosive environment). -
Page 16: Agency Certification
Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. Operation with non-certified assemblies is likely to result in interference to radio and television reception. -
Page 17: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 18: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 1 Attaching SATA cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Surveillance HDD drives support latching SATA connectors. Seagate Surveillance HDD Product Manual, Rev. H... -
Page 19: Drive Mounting
2X 6-32 UNC 2B 3.750±.010 3 MIN THREAD DEPTH 4.000±.010 .14 MAX FASTENER PENETRATION MOUNTING HOLES BOTH SIDES. MAX TORQUE 6 IN/LBS Temperature 1.028 MAX Check Point 26.11 MM .142±.015 2 2.000 C L OF DRIVE Seagate Surveillance HDD Product Manual, Rev. H... -
Page 20: Sata Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate back- plane configuration. • All used voltage pins (V ) must be terminated. Seagate Surveillance HDD Product Manual, Rev. H... -
Page 21: Supported Ata Commands
Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Set Features Set Max Address Seagate Surveillance HDD Product Manual, Rev. H... - Page 22 Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Surveillance HDD Product Manual, Rev. H...
-
Page 23: Identify Device Command
Advanced PIO modes supported (modes 3 and 4 supported) 0003 Minimum multiword DMA transfer cycle time per word (120 nsec) 0078 Recommended multiword DMA transfer cycle time per word (120 nsec) 0078 Seagate Surveillance HDD Product Manual, Rev. H... - Page 24 Integrity word xxA5 Advanced Power Management (APM) and Automatic Acoustic Management (AAM) features are not supported. Note See the bit descriptions below for words 63, 84, and 88 of the Identify Drive data. Note Seagate Surveillance HDD Product Manual, Rev. H...
- Page 25 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Surveillance HDD Product Manual, Rev. H...
-
Page 26: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default) Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Surveillance HDD Product Manual, Rev. H... -
Page 27: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate Surveillance HDD Product Manual, Rev. H... - Page 28 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100762250, Rev. H...
