- Page 1 Surveillance HDD v2 SATA Product Manual ST8000VX000 ST6000VX000 100758083, Rev. C Gen 2 - October 2015...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SeaTools are either trademarks or reg- istered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the prop- erty of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 Mounting dimensions (8TB & 6TB)............. . 19 Seagate Surveillance HDD Product Manual, Rev. C...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/seagate-recovery- services/recover/ For Seagate OEM, Distribution partner portal and reseller portal, visit: http://www.seagate.com/partners Seagate Surveillance HDD Product Manual, Rev. C... -
Page 6: Introduction
Introduction ® This manual describes the functional, mechanical and interface specifications for the following Seagate Surveillance HDD model drives: ST8000VX000 ST6000VX000 These drives provide the following key features: • Host aware firmware designed to function using ZAC command set • Reliability for 24×7 video surveillance applications •... -
Page 7: Zone Structure
ZONE EXT to Open, Close, and Finish zones. To achieve optimal performance, an SMR-aware Host driver will need to write sequentially to all sequential write referred zones. See the T13 Web Site at http://www.t13.org for ACS-4, T13/BSR INCIT 529 for command details. Seagate Surveillance HDD Product Manual, Rev. C... -
Page 8: Drive Specifications
Temperature gradient 30°C per hour max (nonoperating) 5% to 90% (operating) Relative humidity 5% to 95% (nonoperating) Relative humidity gradient (max) 30% per hour 30°C max (operating) Wet bulb temperature (max) 37.7°C max (nonoperating) Seagate Surveillance HDD Product Manual, Rev. C... - Page 9 ** One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. *** During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Surveillance HDD Product Manual, Rev. C...
-
Page 10: Formatted Capacityy
8TB & 6TB 1950 KFCI Track density (ktracks/inch avg) Areal density (Gb/in 8TB & 6TB Internal data transfer rate (Mb/s max) 1900 Maximum sustained data transfer rate, OD read (MB/s) I/O data-transfer rate (MB/s max) Seagate Surveillance HDD Product Manual, Rev. C... -
Page 11: Physical Characteristics
20 (typical) / 25 (max) Ready to spindle stop (in seconds) 15 (typical) / 20 (max) Time-to-ready may be longer than normal if the drive power is removed without going through normal OS powerdown procedures. Seagate Surveillance HDD Product Manual, Rev. C... -
Page 12: Power Specifications
• Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note Seagate Surveillance HDD Product Manual, Rev. C... -
Page 13: Voltage Tolerance
Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000ft. (305 meters), the maximum temperature is derated linearly by 1°C every 1000 ft. Drive case temperature should be measured at the location indicated in Figure 2 Seagate Surveillance HDD Product Manual, Rev. C... -
Page 14: Ambient Temperature
The non-operating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently put into operation is 300 Gs based on a non-repetitive half-sine shock pulse of 2ms duration. Seagate Surveillance HDD Product Manual, Rev. C... -
Page 15: Non-Operating Vibration
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 16: Electromagnetic Immunity
(or part number) and country of purchase. The system will display the warranty information for the drive. 2.13 Agency certification 2.13.1 Safety certification These products are certified to meet the requirements of UL60950-1, CSA60950-1 and EN60950 and so marked as to the certify agency. Seagate Surveillance HDD Product Manual, Rev. C... -
Page 17: Electromagnetic Compatibility
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 18: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. -
Page 19: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 1 Figure 1 Attaching SATA cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Seagate Surveillance HDD drives support latching SATA connectors. Seagate Surveillance HDD Product Manual, Rev. C... -
Page 20: Drive Mounting
• The screws should be inserted no more than 0.140 inch (3.56mm) into the bottom or side mounting holes. • Do not overtighten the mounting screws (maximum torque: 6 inch-lb). Figure 2 Mounting dimensions (8TB & 6TB) Seagate Surveillance HDD Product Manual, Rev. C... -
Page 21: Sata Interface
For detailed information about the SATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. Hot-Plug compatibility Seagate Surveillance HDD drives incorporate connectors which enable users to hot plug these drives in accordance with the SATA Revision 3.0 specification. This specification can be downloaded from www.serialata.org. SATA device plug connector pin definitions Table 5 summarizes the signals on the SATA interface and power connectors. -
Page 22: Supported Ata Commands
Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Seagate Surveillance HDD Product Manual, Rev. C... - Page 23 ZAC Management Out command template * / 01 , 02 , 03 , 04 * For specific ZAC command reference refer to the following documentation: T13 INCITS BSR 537, Zoned-device ATA Command Set (ZAC) (planned as ISO/IEC 17760-171) Seagate Surveillance HDD Product Manual, Rev. C...
-
Page 24: Zac Supported Capabilities Log Page
Retired 0400 Obsolete 0000 Firmware revision 23–26 x.xx (8 ASCII character string, padded with blanks to end of string) Drive model number: 27–46 (40 ASCII characters, padded with blanks to end of string) Seagate Surveillance HDD Product Manual, Rev. C... - Page 25 SATA capabilities xxxx Reserved for future SATA definition xxxx SATA features supported xxxx SATA features enabled xxxx Major version number 01F0 Minor version number 0028 Command sets supported 364B Command sets supported 7F09 Seagate Surveillance HDD Product Manual, Rev. C...
- Page 26 Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active. Multiword DMA mode 1 is currently active. Multiword DMA mode 2 is currently active. Word 84 SMART error login is supported. Seagate Surveillance HDD Product Manual, Rev. C...
- Page 27 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Surveillance HDD Product Manual, Rev. C...
-
Page 28: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above. Seagate Surveillance HDD Product Manual, Rev. C... -
Page 29: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate Surveillance HDD Product Manual, Rev. C... - Page 30 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100758083, Rev. C...
