- Page 1 Enterprise NAS HDD SATA Product Manual ST8000NE0001 ST6000VN0001 100780707, Rev. C January 2017...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Power Choice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ -
Page 4: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM, Distribution partner portal and reseller portal, visit: http://www.seagate.com/partners Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 5: Introduction
Introduction Introduction This manual describes the functional, mechanical and interface specifications for the following: Seagate® Enterprise NAS HDD model drives:. Standard 512e models ST8000NE0001 & ST6000VN0001 These drives provide the following key features: • 7200 RPM spindle speed. • PowerChoice™ for selectable power savings •... -
Page 6: Drive Specifications
Relative humidity 5% to 95% (nonoperating) Relative humidity gradient 30% per hour max 26°C (operating) Wet bulb temperature (max) 29°C (nonoperating) –304.8 m to 3,048 m Altitude, operating (–1000 ft to 10,000+ ft) Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 7 *One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise NAS HDD Product Manual, Rev. C...
-
Page 8: Formatted Capacity
216 MiB/s I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) 25 (max) Standby to Ready (sec) 30 (max) Ready to spindle stop (sec) 12 (max) Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 9: Power Specifications
Maximum DC 0.46 0.62 Maximum DC (peak) 0.57 1.03 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 10 Maximum DC 0.54 0.69 10.98 Maximum DC (peak) 0.72 1.08 16.56 Peak operating current (sequential write 64K16Q) Typical DC 0.44 0.68 10.35 Maximum DC 0.46 0.72 10.94 Maximum DC (peak) 0.60 1.06 15.72 Seagate Enterprise NAS HDD Product Manual, Rev. C...
-
Page 11: Conducted Noise
• Using 5V power, the drive is expected to operate with a maximum of 100mV peak-to-peak square-wave injected noise at up to 10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note 2.5.3 Voltage tolerance Voltage tolerance (including noise): 5V ± 5% 12V ± 5% Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 12: Extended Power Conditions - Powerchoicetm
• Saved enabled state, and timer value • Current enabled state, and timer value S.M.A.R.T. Read Data Reports • Attribute 192 - Emergency Retract Count • Attribute 193 - Load/Unload Cycle Count Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 13 Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate Enterprise NAS HDD Product Manual, Rev. C...
-
Page 14: Environmental Specifications
Wet bulb temperature Operating 26°C / 78.8°F (rated) Non-operating 29°C / 84.2°F (rated) 2.6.5 Altitude Operating –61m to 3048m (–200 ft. to 10,000 ft.) Non-operating –61m to 12,192m (–200 ft. to 40,000+ ft.) Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 15: Shock
The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 10–500 Hz 5.0 Grms ref Linear Random Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 16: Acoustics
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 17: Reliability
EN 55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. The drive is designed for operation inside a properly designed enclosure, with properly shielded I/O cable (if necessary) and terminators on all unused I/O ports. -
Page 18: Fcc Verification
Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 19: Environmental Protection
2.13 Corrosive environment Seagate electronic drive components pass accelerated corrosion testing equivalent to 10 years exposure to light industrial environments containing sulfurous gases, chlorine and nitric oxide, classes G and H per ASTM B845. However, this accelerated testing cannot duplicate every potential application environment. -
Page 20: Product Warranty
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 21: Configuring And Mounting The Drive
• The screws should be inserted no more than 0.120 in (3.05mm) into the bottom or side mounting holes. • Do not overtighten the mounting screws (maximum torque: 6 in-lb). • Do not cover breather hole on top cover. Figure 3. Breather hole location - top cover Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 22: Mechanical Specifications
.12 MAX FASTENER PENETRATION 4.000±.010 MOUNTING HOLES BOTH SIDES. MAX TORQUE 6 IN/LBS 1.028 MAX 26.11 MM .138±.015 5 2.000 C L OF DRIVE Figure 4. Mounting dimensions—top, side and end view (6TB) Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 23 3 MIN THREAD DEPTH .14 MAX FASTENER PENETRATION MOUNTING HOLES BOTH SIDES. MAX TORQUE 6 IN/LBS 1.028 26.11MM .142±.015 2.000 C L OF DRIVE Figure 5. Mounting dimensions—top, side and end view (8TB) Seagate Enterprise NAS HDD Product Manual, Rev. C...
-
Page 24: Serial Ata (Sata) Interface
Power 5V power 5V power Ground 2nd mate Ground or LED signal If grounded, drive does not use deferred spin Ground 1st mate. 12V power, pre-charge, 2nd mate 12V power 12V power Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 25: Supported Ata Commands
Read DMA Extended Read FPDMA Queued Read Log DMA Ext Read Log Ext Read Multiple Read Multiple Extended Read Sectors Read Sectors Extended Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 26 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Enterprise NAS HDD Product Manual, Rev. C...
-
Page 27: Identify Device Command
LBAs specified in words 100-103. This is required for drives that support the 48-bit addressing feature. Retired 0000 Multiword DMA active and modes supported (see note following this table) xx07 Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 28 NOTE: This field is valid if word 84, bit 8 is set to 1 indicating 64-bit WWN support. 112–118 ATA-reserved 0000 Commands and feature sets supported 41DE Commands and feature sets supported or enabled 40DC 121-127 ATA-reserved 0000 Security status 0021 129–159 Seagate-reserved xxxx Seagate Enterprise NAS HDD Product Manual, Rev. C...
- Page 29 Ultra DMA mode 0 is supported. Ultra DMA mode 1 is supported. Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported. Seagate Enterprise NAS HDD Product Manual, Rev. C...
-
Page 30: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Enterprise NAS HDD Product Manual, Rev. C... -
Page 31: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate Enterprise NAS HDD Product Manual, Rev. C... - Page 32 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100780707, Rev. C...
