Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
1. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
2. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
Snap Screw Studs
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
If any parts are damaged or missing please contact customer service at (800) 213-7981.
The cab for you U-Force is made up of 3 different components that work together to enclose your vehicle.
Install the cab in the following order.
1) Soft Doors
2) Rear Window
Soft Doors:
1. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn
perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive
Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that
the adhesive strip holds it firmly in place. The following diagrams show how it should look.
3510-1 Port Jacksonville Pkwy, Jacksonville, FL 32226
Instructions for Installation and Care of CF Moto U Force
Soft Door Rear Window Combo
CF-UFORCE-DRW01
"
"
"
"
"
"
"
"
"
"
"
"
800-213-7981
Soft Doors
18 each------------3"
2 each------------36"
15 each (1 extra)
Rear Window
2 each------------5"
1 each------------32"
Advertisement
Related Manuals for FALCON RIDGE CF-UFORCE-DRW01
Summary of Contents for FALCON RIDGE CF-UFORCE-DRW01
- Page 1 Instructions for Installation and Care of CF Moto U Force Soft Door Rear Window Combo CF-UFORCE-DRW01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
- Page 2 2. Next take the 50" adhesive Velcro strip and run it down the back of the roll cage facing towards the rear of the vehicle. You will see two double-sided Velcro tabs sewn along the back of the doors. The adhesive strip must be aligned so that both tabs can attach to it.
- Page 3 3. Once all the Velcro is in place the last thing to do is install the screw snap studs. NOTE: The best way to install the snap studs is to put them in the sockets in the door first. Then push them into the plastic to make an indention.
-
Page 4: Rear Window
REAR WINDOW: 4. Begin by placing the two 5" and one of the 45" adhesive Velcro strips across the top of the roll cage. Make sure to place them on top of the bar. Photo below shows how it should look. 5. - Page 5 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
-
Page 6: Return Policy
Any returns submitted to Falcon Ridge without a return authorization number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you must first call them and see what their return policy is. Once your item reaches our production facility, our customer satisfaction team will inspect your item to ensure unused, factory new condition.
