Printronix LP844C User Manual page 86

• Configuration > Network
Item
Network Information Printer Name
Short Printer Name
Enabling Default Gateway Displays the valid default gateway.
Wired
IPv4 Address
Subnet Mask
Gateway Address
MAC Address
NIC Program Version
Web Remote Version
IPv6 Address (Local)
IPv6 Address (Stateless
Address)
IPv6 Address (Stateful
Address)
Wireless Firmware Version
(Infrastructure)
Wireless (Infrastructure)
Information
SSID
Security
State
Band
Channel
RSSI
IPv4 Address
Subnet Mask
Gateway Address
MAC Address
IPv6 Address (Local)
IPv6 Address (Stateless
Address)
IPv6 Address (Stateful
Address)
Description
Displays the full printer name.
Displays the abbreviated printer name.
Displays the status (enabled/disabled) of the wired LAN.
Displays the IPv4 Address of the network.
Displays the Subnet Mask of the network.
When [Enabling Default Gateway] is set to [Wired], displays
the Gateway Address of the network.
Displays the MAC Address of the printer.
Displays the Network firmware revision.
Displays the Web remote version.
Displays the IPv6 Address (Local) of the network.
Displays the IPv6 Address (Stateless Address) of the
network.
Displays the IPv6 Address (Stateful Address) of the network.
Displays the Wireless LAN Firmware Version.
Displays the status (enabled/disabled) of the wireless LAN
(Infrastructure mode).
Displays the SSID of the connection destination.
Displays the security of the wireless LAN function.
Displays the state of the wireless LAN.
Displays the using band of the wireless LAN.
Displays the using channel number of the wireless LAN.
Displays the receiving signal strength. Percentage of signal
strength.
Displays the IPv4 Address of the wireless LAN.
Displays the Subnet Mask of the wireless LAN.
When [Enabling Default Gateway] is set to [Wireless
(Infrastructure)], displays the Gateway Address of the
wireless LAN.
Displays the MAC Address of the wireless LAN I/F.
Displays the IPv6 Address (Local) of the network.
Displays the IPv6 Address (Stateless Address) of the
network.
Displays the IPv6 Address (Stateful Address) of the network.
Item
Wireless (AP Mode) Wireless (AP Mode)
Information
SSID
Password
Number of Connected
IPv4 Address
• Print Information
Item
Configuration Prints information about the configuration of the printer.
Network Prints information about the network settings.
File List Prints a job file list.
PS Font List Prints the list of PostScript Emulation font samples
PCL Font List Prints the list of PCL font samples.
IBM PPR Font List Prints a font list of IBMPPR.
EPSON FX Font List Prints a font list of EPSON FX.
Usage Report Prints the total of the job logs.
Supplies Report Prints the supplies report.
Error Log Prints an error log.
Color Profile List Prints the list of color profiles.
Job Log Prints a job history.
CMYK TEST 1 Prints CMYK Test.
• Menu
• Menu > Tray Configuration
Item
MPTray Config Paper Size A4[LEF] or
Letter[LEF] *
X Dimension 210 millimeter
or 8.5 inch *
Y Dimension 297 millimeter
or 11.0 inch *
Media Type Plain
Media Weight Light
Tray Usage When
Mismatching
- 86 -
5. Management / Setting the Printer
Description
Displays the status (enabled/disabled) of the wireless LAN
(AP mode).
Displays the SSID of the connection destination.
Displays the SSID of connection. (When AP Node User
Setting is disclosed.)
Displays the number of connected devices.
Displays the IPv4 Address.
Description
Factory Description
Default
Selects a paper size for MP tray.
2
Sets a width of a custom paper for MP tray.
2
Sets a length of a custom paper for MP tray.
2
Selects a paper type for MP tray.
Selects a paper weight for MP tray.
Sets an MP tray usage.
