V200-18-E46B Technical Specifications
Digital Inputs
Number of inputs
Input type
Galvanic isolation
Digital inputs to bus
Digital inputs to digital inputs in
same group
Group to group, digital inputs
Nominal input voltage
Input voltage
pnp (source)
npn (sink)
Input current
Response time
High-speed inputs
Resolution
Frequency
Minimum pulse width
Notes:
1. Inputs 0 and 2 can each function as either high-speed counter or as part of a shaft encoder. In each
case, high-speed input specifications apply. When used as a normal digital input, normal input
specifications apply.
2. Inputs 1 and 3 can each function as either counter reset, or as a normal digital input; in either case, its
specifications are those of a normal digital input. These inputs may also be used as part of a shaft
encoder. In this case, high-speed input specifications apply.
Digital Outputs
Digital Output's Power Supply
Nominal operating voltage
Operating voltage
Quiescent current
Max. current consumption
Galvanic isolation
Digital power supply to bus
Digital power supply to relay
outputs
Digital power supply to
transistor outputs
Notes:
3. Maximum current consumption does not provide for pnp output requirements.
The additional current requirement of pnp outputs must be added.
Relay Outputs
Number of outputs
Output type
Isolation
Type of relay
Outputs' power supply
Galvanic isolation
Relay outputs to bus
Group to group, relay
outputs
Relay to transistor outputs
Output current
Rate voltage
Minimun load
Life expectancy
Response time
Contact protection
Unitronics
18 (in two groups)
pnp (source) or npn (sink)
Yes
No
Yes
24VDC
0-5VDC for Logic '0'
17-28.8VDC for Logic '1'
17-28.8VDC for Logic '0'
0-5VDC for Logic '1'
8.8mA@24VDC for inputs 0 to 3
6mA@24VDC for inputs 4 to 17
10mSec typical
Specifications below apply when these inputs are wired for use as a high-
speed counter input/shaft encoder. See Notes 1 and 2.
32-bit
10kHz maximum
40μs
24VDC
20.4 to 28.8VDC
5mA@24VDC.
85mA@24VDC. See Note 3.
Yes
Yes
No
15 relays (in two groups). See Note 4.
SPST-NO (Form A)
By relay
Tyco PCN-124D3MHZ or compatible
See Digital Output's Power Supply page 11.
Yes
Yes
Yes
3A maximum per output (resistive load)
8A maximum total for common (resistive load)
250VAC / 30VDC
1mA@5VDC
100k operations at maximum load
10mS (typical)
External precautions required (see Increasing Contact Life Span, p.5)
UG_V200-18-E46B Snap-in I/O Module
