  • Page 1 Operating Manual PSSu E F PS(-T) Operating Manual PSSu E F PS(-T) PSSu E F PS(-T) Decentralised system PSSuniversal I/O Operating Manual — No. 21292-EN-04...
  • Page 2 Preface...

  • Page 3: Table Of Contents

    Inserting and removing an electronic module 5.3.1 Inserting an electronic module 5.3.2 Removing an electronic module 5.3.3 Changing an electronic module during operation Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 4 Display elements for the status of the module supply and periphery supply Status byte Chapter 8 Technical details Technical details Order reference Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 5: Chapter 1 Introduction

    1100 Validity of documentation 1- ][BA Einf Gültigkeit_(T) This documentation is valid for the products PSSu E F PS and PSSu E F PS-T. It is valid until new documentation is published. Einf Einleitung This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product .

  • Page 6: Overview Of Documentation

    This chapter explains the display elements and advises on what to do if a fault occurs. 8 Technical Details This chapter contains the product's technical details and order refer- ence. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 7: Definition Of Symbols

    This gives advice on applications and provides information on special features, as well as highlighting areas within the text that are of particular importance. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 8 Introduction Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 9: Chapter 2 Overview

    Application range depends on the base module ][Merkmale_Zusatz  ][Geraetemerkmal_T Coated version of the module: PSSu E F PS-T: for increased environmental requirements Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 10: Front View

     5: Connection level 1  6: Connection level 2  7: Connection level 3  8: Connection level 4 Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 11  11: Mounting slot for colour marker to label the connection level (con- nection levels 1, 2, 3 and 4) Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 12 Overview Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 13: Chapter 3 Safety

    Supply module to refresh the module supply and periphery supply  Supply module to form supply groups Bestimm_Verwend_Zusatz-(T) The module PSSu E F PS-T is suitable for use where there are increased environmental requirements (see Technical Details). Bestimmung/Gertebeschreibung_Ausschluss Intended use includes making the electrical installation EMC-compliant.
  • Page 14 Safety Intended use The PSSu E F PS module may be used in conjunction with the following base modules:  ][BA_Basismodule PS PSSu BS 1/8S  PSSu BS-R 1/8S  PSSu BS 1/8C  PSSu BS-R 1/8C ][BA_Basismodule PS-T The PSSu E F PS-T module may be used in conjunction with the follow- ing base modules: ...

  • Page 15: Safety Regulations

    When decommissioning, please comply with local regulations regard- ing the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 16 Safety Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 17: Chapter 4 Function Description

    The relevant base module interrupts the connection to the incoming (left-hand) periphery supply and C-rail on the module bus. Each sup- ply group requires its own supply module. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 18: Module Features

    If the current load is higher, the C-rail must use a different supply to prevent overload. Please refer to the derating diagram. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 19 Function description Module features PSSu E F PS: Derating diagram for periphery supply and C-rail: Temperature T dependent on load current I PSSu E F PS-T: Derating diagram for infeed for periphery supply: Permitted ambient temperature T dependent on load current I T [°C]...

  • Page 20: Integrated Protection Mechanisms

    Function description Module features PSSu E F PS-T: Derating diagram for infeed for module supply: Permitted ambient temperature T dependent on load current I T [°C] I [A] 4.1.2 Integrated protection mechanisms Integrated protection mechanisms 4- ][Schutzmechanismen PS The module has the following protection mechanisms: ...

  • Page 21: Configuration

    - - - (“R”) INFORMATION Further information on the structure and contents of the status byte can be found under “Operation”. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 22: Fs Error Behaviour

    The I/O-Group switches to a STOP condition. An error telegram is then triggered on SafetyBUS p and the error is entered in the PSSuniversal error stack. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 23: Chapter 5 Installation

    5.1.1 Dimensions Dimensions 5- ][Abmessungen 1xR Base modules with four connection levels: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 24: Installing The Base Module

    On the mounting rail, slide the base module to the left until you hear the two lateral mounting hooks on the adjacent module lock into po- sition [3]. Schematic representation: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 25: Inserting And Removing An Electronic

    The electronic module must audibly lock into position [1].  Mark the electronic module using the labelling strips [2]. Schematic representation: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 26: Removing An Electronic Module

    5- ][Montage BA Hot Swapping PS NOTICE Supply voltage modules may only be inserted and removed when the supply voltage is switched off. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 27: General Wiring Guidelines

    Use a flat blade screwdriver (DIN 5264-A)!  Strip the wire back 8 mm.  If necessary, label the connection level with a colour marker [3]. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 28 (AWG16) – Test pulse outputs: 1.5 mm (AWG16) – Power supply: 2.5 mm (AWG12) – Functional earth: 2.5 mm (AWG12) Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 29 EN 60947-1, such as the PZ 1.5 or PZ 6.5 from Weidmüller, for example. – Maximum torque setting: 0.8 Nm  Use copper wiring. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 30: Terminal Configuration

    (13-23 linked within the base module) 14-24 C-rail supply, interrupted to the left (14-24 linked within the base module) Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 31 (13-23 linked within the base module) 14-24 C-rail supply, interrupted to the left (14-24 linked within the base module) Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 32 Wiring Terminal configuration Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 33: Connecting The Module

    6- ][Anschluss PS Separate power supplies for module supply and periphery supply Common power supply for module supply and periphery supply Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 34 Wiring Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 35: Chapter 7 Operation

    Change faulty supply voltage module. odes fective. Further information on PSSu error messages is available in the online help for PSS WIN-PRO or PAS4000. Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 36: Display Elements

    The module has an LED for displaying module errors (“Err” LED). Name Colour Status - - - No error Module error Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 37: Display Elements For The Status Of The

    Green No supply volt- age for periph- ery supply Supply voltage for periphery supply is error- free Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 38: Status Byte

    At least one FS module is registering an error No error on the ST modules At least one ST module is registering an error Reserved Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 39: Chapter 8 Technical Details

    Max. operating height above sea level 5000 m coated version (-T) EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-2, EN 61000-6-4 Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 40 12.6 mm Depth 60.2 mm Weight 38 g 40 g coated version (-T) Mechanical coding Type Colour yellow Technische Daten_Satz Normen Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...

  • Page 41: Order Reference

    (Base module with cage clamp terminals, for use only to re- fresh the voltage and form supply groups, coated version) Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
  • Page 42 Technical details Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de...
