RGBlink mini-mx Quick Start Manual page 8

HDMI-A
4
(PROGRAM)
HDMI-A
5
(MULTI-VIEW)
6 1-4 HDMI IN
7 Locking Hole
8 Power Socket
9 Power Switch
10 3.5mm mini-Jack
6.35mm TRS Jack
11
(AUDIO OUT)
12 LINE IN
13 MIC IN 2
14 MIC IN 1
15 +48V Dip Switch
mini-mx
and firmware upgrade.
● PROGRAM output port.
● PREVIEW output port. Multi-view output port.
MULTI-VIEW / HDMI 1/2/3/4 / PROGRAM optional.
● 1-4 HDMI inputs to connect HDMI video sources, up
to 4K resolution and downward compatible with all
resolution.
● Can be used with T-lock to fix the device.
● PD 12V, 3A USB-C power input.
● Rocker switch to power on or off your device.
● Audio Jack for PREVIEW or PROGRAM monitoring.
● Balanced 6.35mm XLR Jack.
● Balanced 6.35mm XLR Jack to connect to mobile
phone, computer or audio console.
● XLR/TRS NEUTRIK MIC IN Port.
● XLR/TRS NEUTRIK MIC IN Port with 48V Phantom
Power supported.
● 48V Phantom Power supported.
● Defaults to OFF.
Quick Start 7
