Hardware Orientation

Front Panel

1
2
3
4
5
Audio Volume
1
Control Knob
2 Adjuster
Layer Selection
3
Button
mini-mx
13
● Embedded audio volume adjustment of HDMI 1-4
input signals. User can check audio status via touch
screen.
● Knob color adjustable.
● Zoom in/out when PTZ control is enabled.
● Adjust size of sub-picture when it is under position
and scale adjustment.
● Indicate BG, Layer A, Layer B, STILL, LOGO and
TEXT from left to right.
● Light turns blue in PVW. Light flashes in green
