RGBlink mini-mx Quick Start Manual page 6

4 Channel Fader
Monitoring &
5
Mute Button
6 T-Bar
7 Page UP
8 Page Down
9 Buttons 1-8
5-Direction
10
Joystick
11 MENU
12 ON AIR
mini-mx
when this layer is selected.
● Button color adjustable.
● To control audio volume level for each channel.
● Indicate MIC1/MIC2/LINE IN/Bluetooth/PREVIEW
/PROGRAM from left to right.
● Click monitoring button to switch audio to the
monitoring port.
● Click mute button to stop adding audio to PGM if it
turns red; click mute button again to add audio to
PGM if it turns green then.
● PVW and PGM views can be transitioned manually
by pushing the T-bar bidirectionally from the top to
the bottom or from the bottom to the top.
● Press to return to the previous page.
● Press to enter the next page.
● For option selection of the right edge on the touch
screen.
● Button color adjustable.
● Set pan, tilt, zoom for PTZ camera.
● For adjustment of layer position.
● Press to return to the previous menu; press and
hold to return to the main menu.
● Button color adjustable.
● Click to start or end streaming.
● Streaming status can be checked on LCD screen
through indicator light: steady red shows ON AIR;
flashing red shows unstable network ON AIR; unlit
Quick Start 5
