1129 WIRELESS GLASSBREAK DETECTOR
Installation Guide
Figure 1: 1129 Wireless
Glassbreak Detector
DESCRIPTION
The 1129 Glassbreak wireless
sensor is omni-directional,
providing 360° detection
coverage of framed glass
mounted in an outside wall.
Mount the 1129 Glassbreak
on the ceiling or an opposing
wall for maximum flexibility
and coverage. The 1129
Glassbreak operates using
the supplied 3 VDC Lithium
battery.
Compatibility
All DMP 1100 Series
Wireless Receivers.
What is Included?
•
One Glassbreak
detector with DMP
wireless transmitter
installed
•
One 3 V lithium CR123
battery
•
Hardware pack
1
PROGRAM THE PANEL
Refer to the panel programming guide as needed.
At a keypad, enter 6653 (PROG) to access the
1.
PROGRAMMER menu.
Press CMD until ZONE INFORMATION displays and
2.
press a top row select key or area.
3.
Enter the wireless ZONE NO and press CMD.
4.
Enter the ZONE NAME and press CMD.
5.
Select NT (night) the ZONE TYPE.
Select the AREA NO and press CMD.
6.
At the NEXT ZN? prompt, select NO and press CMD
7.
until WIRELESS? displays.
8.
Select YES when WIRELESS? displays and press
CMD.
9.
Enter the eight-digit SERIAL# and press CMD.
10.
Enter the SUPRVSN TIME and press CMD.
11.
At the NEXT ZN? prompt, select YES if you are
finished programming the zone. Select NO if you
would like to access additional programming
options.
2
INSTALL THE BATTERY
Keep in mind, when setting up a wireless system, program
zones and connect the receiver before installing the included
CR123A battery in the transmitter.
1.
Remove the snap on lid on the 1129 case and gently
lift off the cover.
2.
Observing polarity, place the battery in the holder
and press into place.
Advertisement
Related Manuals for DMP Electronics 1129 WIRELESS GLASSBREAK DETECTOR
Summary of Contents for DMP Electronics 1129 WIRELESS GLASSBREAK DETECTOR
- Page 1 1129 WIRELESS GLASSBREAK DETECTOR Installation Guide PROGRAM THE PANEL Refer to the panel programming guide as needed. At a keypad, enter 6653 (PROG) to access the PROGRAMMER menu. Press CMD until ZONE INFORMATION displays and press a top row select key or area.
- Page 2 SELECT A LOCATION The 1129 Glassbreak coverage is measured from the sensor to the farthest point on the glass. The sensor can be mounted as close as 3.3’ (1m) from the glass. Refer to the table below to determine the best location to place the 1129 based on window type, glass thickness, window to wall range, and wall type.
- Page 3 MOUNT THE 1129 MOUNTING HOLES With the 1129 already open, place the 1129 base on the wall in the desired location. Use the provided hardware pack to mount the Glassbreak Microphone base to the wall. See Figure 3 for mounting hole Mounting Sealed Glassbreak 4-Pin...
- Page 4 FCC INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm (7.874 in.) from all persons.
