TSC PEX-2000 Series User Manual page 51

Item
Speed Set the print speed.
Slew Speed Set feed speed
Back Speed Set back speed
Density Set printing darkness. Setting range: 0 to 15, and the step is 1.
Set the printout direction. Setting Value: 0 and 1.
Direction
Direction 0:
Set the print mode. There are 3 modes in total:
Batch Mode: Once finishing the printing process, label will be fed to the tear plate location.
Print mode
Applicator: The printer prints a label when it receives a signal from the applicator.
Rewinder Mode: Enable the label rewinder mode.
Offset Adjust media stop location. Available value setting range: -999 dots to 999 dots.
Shift X
Adjust print position. Available value setting range: -999 dots to 999 dots.
Shift Y
Reference X
Set the origin of printer coordinate system horizontally and vertically. Available setting range: 0 dot to 999 dots.
Reference Y
Code page Set the code page of international character set.
Country Set the country code. Available setting value range: 1 to 358.
Note: If printing from enclosed software/driver, the software/driver will send out the commands, which will overwrite the settings set
from the panel.
Description
Direction 1:
Default
203 dpi: 6
300 dpi: 4
203 dpi: 6
300 dpi: 4
2
8
0
Applicator
0 dot
0 dot
0 dot
0 dot
0 dot
850
001
49
