The left side printout position is
incorrect
The printing position of small
label is incorrect
* Wrong label size setup.
* The parameter Shift X in LCD menu is
incorrect.
* Media sensor sensitivity is not set properly.
* Label size is incorrect.
* The parameter Shift Y in the LCD menu is
incorrect.
* The vertical offset setting in the driver is
incorrect.
* Set the correct label size.
* Press [MENU] → [SELECT] x 3 → [DOWN] x 5 →
[SELECT] to fine tune the parameter of Shift X.
* Calibrate the sensor sensitivity again.
* Set the correct label size and gap size.
* Enter LCD menu (or via TSC Console) to fine tune the
parameter of Shift Y.
* If using the software BarTender, please set the vertical
offset in the driver.
