Copyboard
N - 20S/N - 20W
User's Manual
Thank you for your purchase of the PLUS Copyboard.
Please read this User's Manual carefully before use to take full advan-
tage of the functions of this product. After you have finished reading
the manual, please keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N-20S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Plus N-20S

Summary of Contents for Plus N-20S

  • Page 1 N - 20S/N - 20W User’s Manual Thank you for your purchase of the PLUS Copyboard. Please read this User’s Manual carefully before use to take full advan- tage of the functions of this product. After you have finished reading...

  • Page 2: Introduction

    Cautions on using networks About the network connection environment • The required operating environment is subject to change without notice. Also, PLUS does not guarantee all operations. • Even if all required operating environment conditions are met, it may happen that operations do not work properly or that some problems arise. Depending on the communications status, displays may be delayed and communication errors may occur. Disclaimer • PLUS will accept no responsibility whatsoever for any consequences of problems of communication impediments in con- nected devices due to the network functions. • PLUS will accept no responsibility whatsoever for impediments incidental to usage of or the inability to use the network func- tions (loss of business profits, losses due to interruption of activities, etc.). • PLUS will accept no responsibility whatsoever for malfunctions due to combinations with connected devices or the software used, nor for damages arising from hang-up, etc. NOTE Do not use ruled type tapes.

  • Page 3: Table Of Contents

    Table of Contents Introduction ...............E-2 Deleting image files from the copyboard ... E-25 Table of Contents ............E-3 When the folder for saving is set to “FTP Server” ............E-26 Package Contents ............E-4 Deleting image files on the FTP server ....E-27 Names of the Parts ............E-5 CB Setup and Network Setting Procedure ....E-28 Front ..............

  • Page 4: Package Contents

    Pen tray [1] Pen tray fixing screws (M4 × 20) (temporarily fastened on main unit) Wall brackets [1 set] N-20S: 3 screws, N-20W: 4 screws These are brackets for mounting the main unit on a wall. (See the Assembly and Setup Manual for assembly instruc- (See the Assembly and Setup Manual.) tions.)

  • Page 5: Names Of The Parts

    Names of the Parts Front Main unit Frame cover Sheet Dedicated markers are used on the sheet to draw diagrams and to write. Control panel (See Page E-8) Pen tray Input/output terminals (see next page) * Located on the bottom surface. Printer table The printer* is placed here. (See the Assembly and Setup Manual.) * The printer is sold separately. AC adapter box Store the AC power adapters of the copyboard * This illustration does not show the connection cords.

  • Page 6: Input/Output Terminals

    Names of the Parts Input/output terminals USB memory port (type A) Insert a commercially available USB memory device here. Scanned images can be saved. (See page E-16) The connector is located on the bottom sur- face of the main unit. The diagram view is seen from the bottom. * This illustration does not show the printer or connection cords. DC input connector Connect this with the DC plug end of the AC power Personal computer (PC) dedicated USB adapter. (See Page E-10, E-49.) (Only connect the port (Type B) supplied AC power adapter; nothing else.)

  • Page 7: Changing The Height Of The Unit

    Names of the Parts Changing the Height of the Unit This is the height adjustment when setting up the copyboard on the optional stand. The stand height can be adjusted to 3 levels by 100 mm. CAUTION • At least two persons should hold the main unit. If not, the main unit could drop or tip, resulting in accidental injury. • Lock the stand’s casters by pressing the bottom of the caster lock button. If not, the stand could move while the main unit is being mounted or removed, resulting in accidental injury.

  • Page 8: Control Panel

    Names of the Parts Save ( ) button (USB memory storage) Control Panel The sheet is moved by 1 screen and read, and the image is stored on the USB memory device. When pressing a button, please press the center area When connected to a computer by USB cable, the image (the square bulge). The button may not work if it is is stored in the copyboard’s internal memory. pressed on a corner. Network button Scrolls and scans the sheet one screen’s worth and saves the data in the folder for saving.

  • Page 9: Operation Steps

    Operation Steps The copyboard uses an image scanner to scan characters or diagrams drawn using special markers (four col- ors). When the Color Print or B/W Print button is pressed, the image on the screen is printed out to the printer.

  • Page 10: Connecting The Power

    Connecting the Power Note About the connection and the AC adapter box Place the AC power adapters of the main unit and printer in the AC adapter box. If you only have one power outlet, connect the AC power adapters of the main unit and printer to a commer- cially available cable tap, place them in the AC adapter box, and connect the cable tap’s power plug to the wall power outlet. Also, if not connected or placed in the AC adapter box, see the separate “Assembly and Setup Manual” and connect according to the purpose. Wall outlet Printer’s AC power adapter AC adaptor box Copyboard’s AC power adapter * Be sure to insert all the plugs securely. To use the copyboard, connect the copyboard’s AC power plug to a wall power outlet. The main power turns on. In this manual, this is referred to as the “standby mode”. The descriptions in this manual assume that the AC power plug is connected (that the unit is in the standby mode). About the printer’s power supply • When using a printer, connect its power plug to a wall power outlet.

  • Page 11: Setting The Time

    Setting the Time The date and time are stamped on the printing paper and recorded in the file information when files are stored on the copyboard and FTP server, so set the copyboard’s time correctly. The time can also be set from a computer via a network (when connected to a LAN). (See page E-36.) Description of Operations Switch to “CB Setup”.
  • Page 12 Setting the Time While “F1” is displayed, press the Save button to enter. The display switches to “c1” (first 2 digits of year). If no buttons are operated for 10 seconds while in the time setting mode, the mode returns to the “CB Setup” mode. Press the Save button to move to the last dig- its of the year The display switches to “c2” (last 2 digits of year). Notice: The first two digits of the year (“20”) are fixed. Simply press the Save button to switch to the last 2 digits of the year setting position.

  • Page 13: Printing (Printer Sold Separately

    Printing (printer sold separately) Use a printer to print out the image that has been drawn on the sheet surface. Use a PLUS-designated printer. Operations and names of parts differ from printer to printer. For details of operations, see your printer’s operat- ing instructions.

  • Page 14: Basic Printing Operation

    Printing Basic Printing Operation Preparation: Preparation: Check that the AC power plugs of the copyboard and printer are connected to wall power outlets. See Page E-10. Press the ON/Standby button and switch on the power. Prepare the printer. (See the previous page.) Note • When turning on the power, wait about 5 seconds or more after the power plug has been connected before pressing the Power button.

  • Page 15: Moving The Sheet Surface Manually

    Printing Press the Color Print or the B/W Print button to print. • The reading operation is performed for a one-sheet portion (while the sheet is scrolled) and the printing operation is performed. Cancellation of the print operation in progress When the ON/Standby button is pressed, the reading of the sheet stops, and the partially read image data is printed. Wait until the sheet is expelled from the printer. Note • If the ON/Standby button is pressed while the sheet surface is being read, printing is interrupted and only part of the image will be printed. To move the sheet surface, wait until scrolling stops, then press the Scroll/Stop button . • The one-screen portion is reduced to A4 paper size and printed. For wide type copyboards (model N-20W), the image is compressed about 75% in the horizontal direction. To print with the same proportions as the image on the sheet surface, see “Making the Device Settings” (page E-36).

  • Page 16: Using Usb Memory

    Using USB Memory The content of what has been drawn on the sheet surface of the copyboard can be saved in USB memory. Later, the saved image can be read into a personal computer and made into a document of the proceedings of the meeting, or affixed to a document.
  • Page 17 Using USB Memory Press the Save button to store. Flashing indicator “rotates” sequentially during USB memo- ry storage operation. Display window • The reading operation is performed for a one-sheet portion (while the sheet is scrolled) and USB memory stor- age starts after the scrolling completes. The (5 second) flashing “US” display indicates that the USB memory has not been inserted. Please insert the USB memory and then press the Save button.

  • Page 18: Saving Image Files On A Computer/Deleting Image Files

    Using USB Memory Saving Image Files on a Computer/Deleting Image Files Examples of operations follow for saving the image files in the USB memory device to the hard disk of the per- sonal computer, and for deleting the folder when the USB memory capacity is full. (There are various methods that can be used for saving and deleting including the use of Explorer.) See the instruction manual of your per- sonal computer or the software that you are using for information about using a personal computer.
  • Page 19 Using USB Memory Deleting USB memory image files with the com- puter Before deleting important image files, be sure to save them on the computer (as a data backup). Open “My Computer (or “Computer”)” and then open the drive icon which shows USB memory. The folder named “CB_Image” contains the memory stor- age data of the copy-board.

  • Page 20: Using The Copyboard Connected To A Computer

    Using the copyboard connected to a computer When the copyboard and a computer are connected by USB cable, the copyboard is recognized as an exter- nal memory device (removable device). Below is the procedure for copying the “CBImage” file from this device onto the computer.

  • Page 21: Using The Copyboard Connected To A Network

    • Be sure to transfer important image files stored on the copyboard itself to a computer (data backup). If the copyboard should for some reason malfunction, depending on the malfunction the stored data may be lost or become impossible to transfer. Note that PLUS will accept no responsibility whatsoever for loss of data, etc. • The copyboard will not operate properly if the firewall is activated. The following explanation assumes that the LAN cable has been connected and the various network settings have been completed.
  • Page 22 Using the Copyboard Connected to a Network Press the Network button to save the image. LEDs flash in circular motion during saving [Display window] • The scanning operation (scrolling) is performed over one sheet’s worth of image, and when scanning stops the data is stored in the save to location set in the network settings. For instructions on selecting the save to location, see “Network Settings” on page E-38. Note • Depending on the network communications conditions, some time may be required for identification and storage. • If “E8” flashes (for about 5 seconds), “Invalid” is set at “Security Setting” → “Network Storage”. (See page E-40.) • If “L1” to “L5” flashes (for about 5 seconds), this indicates that the network settings are incorrect. (See page E-45.) • If “FL” flashes (for about 5 seconds), there is not enough space in the save to location. Delete image files to pro- vide space. (See pages E-25 and E-27.)

  • Page 23: Transferring Image Files To/Deleting Them From The Computer

    Using the Copyboard Connected to a Network Transferring image files to/deleting them from the computer Image files stored in the folder for saving (“Board” or “FTP Server”) can be transferred to your own computer. The operation differs according to the setting for where scanned images are stored. (See “Network Settings” on page E-38.) The image files are saved in JPEG (default), PNG or PDF format, according to the image format setting.
  • Page 24 Using the Copyboard Connected to a Network Click the desired date. • Image files are managed in groups by date (the date the scanned image files were saved). Because of this, display the date list. • Check that “Download” is selected for the [Download/Delete] selection button. When “▾” is clicked, a pull-down list is displayed. Click [Down- load]. [Download/Delete] selection button From the file list, select the image to be transferred to the computer. When the radio button is clicked, it is checked and a preview image is displayed. Download the image onto the computer. (1) Click the [Download] button.

  • Page 25: Deleting Image Files From The Copyboard

    Using the Copyboard Connected to a Network Deleting image files from the copyboard Notice • When “Invalid” is set at “Delete User Image Data” in “Security Setting”, files cannot be deleted. This can be changed to “Valid” with the administrator’s authority. (See page E-40.) Perform steps 1, 2 and 3 on page E-23 to display the file list screen. Select [Delete].

  • Page 26: When The Folder For Saving Is Set To "Ftp Server

    Using the Copyboard Connected to a Network When the folder for saving is set to “FTP Server” When the folder for saving is set to “FTP Server”, the scanned images are saved on the FTP server connected on the network. Transfer these images onto the computer connected on the network. The following explains how to transfer the files using Explorer on the computer. Click the computer icon or, from the Start menu, click “Computer”. Explorer opens. Log in to the FTP server. Click on Explorer’s address field, input the FTP server’s IP address after “ftp://”, then press the [Enter] key. The FTP server’s verification screen opens. Input the required fields on the verification screen. Input the user name and password registered on the FTP server, then click the [Log In] button.

  • Page 27: Deleting Image Files On The Ftp Server

    Using the Copyboard Connected to a Network Note • Logging in to the FTP server from a web browser The procedure is the same as for “When the folder for saving is set to “Board”” on page E-23. However, to log in, input the FTP server’s IP address (input “ftp://”, then input the IP address), and at the verification screen input the user name and password registered on the FTP server. Deleting image files on the FTP server At step 4 on the previous page, select the folder(s) or image file(s) to be deleted, right-click the mouse to display a pull-down menu and select “Delete”. At the verification screen, click “Yes”. The folder(s) or file(s) are deleted. If folder(s) or file(s) cannot be deleted • Is access to the FTP server’s folder restricted? Notice • Be very careful when deleting folders or files from the FTP server. • Check again before deleting to avoid accidentally deleting other folders or files. E-27...

  • Page 28: Cb Setup And Network Setting Procedure

    CB Setup and Network Setting Procedure There are three ways to make the device settings: using the copyboard’s operation buttons to make the set- tings (“CB Setup”), making the settings using a USB connection (simple network settings, and making the set- tings via LAN (detailed settings: “CB Setup”...

  • Page 29: Table Of Function Numbers And Settings

    CB Setup and Network Setting Procedure Table of Function Numbers and Settings Function Setting Item Description Setting Status Indicators Number The date and time are stamped on the printing paper Year, month, Not lit Time Setting and recorded in the file information when files are day, hours, stored. minutes Selection of whether to print in A4 paper size or letter Printer size. (Lit) (Off) Paper Size • This operates when the copyboard is connected to Letter Printer...
  • Page 30 CB Setup and Network Setting Procedure Function Setting Item Description Setting Status Indicators Number Setting of whether or not to notify the user that char- Disable* Printer acters or diagrams drawn on the back side of the (Lit) (Off) copyboard’s sheet surface have not been erased. Enable Printer This is effective for confidential meetings, etc. (Off) (Lit) Disable: T he Erase Reminder function does not work. (Setting upon factory shipment) Enable: W hen the Power button is pressed to turn Erase Reminder...

  • Page 31: Simple Network Settings (Via Usb

    (type A) To copyboard’s computer USB port (type B) Open “My Computer”, and in this open the copyboard (removable device). 1 Double-click the “My Computer” (or “Computer”) icon to open. 2 Double-click the copyboard (a device displayed as a removable disk) to open the copyboard’s computer storage memory. • T o check that the copyboard is operating as a device, right-click “My Computer” (or “Computer”) to display the menu, then check that “PLUS Copyboard USB Device” is displayed as the disk drive name at “Management” → “Device Manager” for Windows 7 (“Properties” → “Device Manager” for Windows XP). Use a program on the computer (Notepad, etc.) to open the “setting.ini” file in the “setup” folder. 1 Double-click the “setup” folder to open it. 2 Open the “setting.ini” file (text format) located in this folder using Notepad or another program on the computer and directly overwrite the contents of the settings file. • The only characters that can be input are numbers and periods. Do not insert any spaces. If so, the file will be identified as corrupt when the copyboard is started and the settings will be reset to the defaults.
  • Page 32 CB Setup and Network Setting Procedure Contents upon purchase and when network settings are reset IP Address=* Input the IP address (fixed). Subnet Mask=* Input the subnet mask. Default Gateway=* Input the default gateway if necessary. Item Item name Setting Default IP address IP Address Any value Blank Subnet mask Subnet Mask Any value Blank Default gateway Default Gateway Any value Blank Save the “setting.ini” settings file, overwriting the previous file. Save to location: “ setup” folder on copyboard (removable disk) File name: s etting.ini • We recommend making a note of changed settings for future reference.

  • Page 33: Making Detailed Settings (Via Lan

    CB Setup and Network Setting Procedure Making Detailed Settings (via LAN) Use this procedure to make the copyboard device settings (“CB Setup”), network settings, etc., with the copyboard connected to a local area network (hereafter referred to as “LAN” or “the network”) using a computer’s web browser. Access authority is required to make the detailed settings. There are three levels of authority – “administrator authority”, “file list browsing authority” and “no authority”, and the selectable menu items (some setting items) are restricted accordingly. Register the administrator and users at “User Setting” on page E-39. Table of Menu Items and Access Authority Levels Menu Item Some Setting Items Administrator Authority File List Browsing No Authority Authority CB Setup • • • Board File List Preview and Download • • — Delete : Note •...
  • Page 34 CB Setup and Network Setting Procedure Input the copyboard’s IP address. In the web browser’s URL field, input “http://” followed by the copy- board’s IP address, then press the [Enter] key. When the copyboard is connected, the top screen appears. Connecting the copyboard to the network upon purchase Upon purchase, the copyboard’s IP address and subnet mask are not yet set. Be sure to check the section “Simple Network Settings (via USB)” (see page E-31) and set the IP address, etc. From the menu, click the desired setting item. When setting items for which verification are required are clicked, the user verification screen is displayed. Input the user name and password, then click the [OK] button. • No password is set upon purchase. For the user name, input “admin”, then click the [OK] button.
  • Page 35 CB Setup and Network Setting Procedure Make the changes or settings. The screen at the right is an example of what may be displayed, here showing the “CB Setup” page. Selecting and inputting Radio buttons One of the selection items can be selected. When is clicked, it switches to . Input boxes When a box is clicked, the arrow cursor switches to the “ | ” char- acter input cursor. Input characters in the same way as you would on a computer. • The characters that can be input are restricted according to the item’s type of setting. (See page E-39) Browse and Upload buttons See “Header/Footer”. (Page E-37) Setup button When clicked, the settings/changes are sent to the copyboard, overwriting previous settings.

  • Page 36: Cb Setup

    CB Setup and Network Setting Procedure CB Setup This is the page where the copyboard’s various functions are set and changed. The settings are the same as on “Table of Function Numbers and Settings” in the section on making the settings operating the copyboard’s buttons. (For instructions on displaying the screen, see “Basic Setting Operations” step 3 on page E-34.) Copyboard Setting Item Setting/Description Default Paper size Select the printing paper size. Aspect Ratio Setting Select the aspect ratio for printing. Match to printing paper size Time Date Stamp Set the copyboard’s date and time. Input as follows: Year: 4 digits, Month: 2 digits (Ex.: 03 for March), Day: 2 digits (Ex.: 06 for the 6th), Hours: 2 digits in 24-hour mode (Ex.: 14 for 2 pm, 06 for 6 am), Minutes: 2 digits (Ex.: 00 for 0 minutes) • Do not insert spaces. If the date and time setting values are incorrect, an error message is displayed. Get Current Time: When the “Get Current Time” button is clicked, the display switches to the computer’s current time. This eliminates the need to make the cur- rent date and time setting. Color Printing Color printing can be set to Valid or Invalid.

  • Page 37: Header/Footer

    CB Setup and Network Setting Procedure Header/Footer This is the screen for registering headers and footers on the copyboard and checking the image. (For instructions on displaying the screen, see “Basic Setting Operations” step 3 on page E-34.) Image Select screen Preview screen Image Select/Preview Item Setting/Description Default Select Header/Footer Select whether the image to be registered on the copyboard is a header Header Image or footer. Click the radio buttons to select. • For instructions on creating images, see page E-43. Browse When the [Browse] button is clicked, the computer’s “Browse Files” — screen opens. Select the image, then click the [OK] button to set it. Upload This uploads the selected header or footer image to the copyboard. — When the [Upload] button is clicked, uploading starts. • If an image is already registered on the copyboard, that image is over- written.

  • Page 38: Network Setting

    CB Setup and Network Setting Procedure Network Setting Make the settings for the copyboard’s IP address, the FTP server’s IP address, etc. (For instructions on displaying the screen, see “Basic Setting Operations” step 3 on page E-34.) Network Setting Item Setting/Description Default IP address Change the copyboard’s IP address. Use a fixed IP address for the Any value copyboard. When connecting to a network using the DHCP of a router, etc., change the IP address to one that is outside of the automatic acquisition range Subnet Mask Set the copyboard’s subnet mask.

  • Page 39: User Setting

    CB Setup and Network Setting Procedure User Setting Set the user name and password required for administrator and user verification and the number required for resetting the network settings. (For instructions on displaying the screen, see “Basic Setting Operations” step 3 on page E-34.) User Setting Item Setting/Description Default Admin User name Set the administrator’s user name. admin • Input using no more than 14 characters. The name will be case sensi- tive for verification. Admin Password Set the administrator’s password. None • Input using no more than 14 characters. The password will be case sensitive for verification. User Name Set the user name. admin The limit to the number characters that can be input is the same as for the administrator’s user name.

  • Page 40: Security Setting

    CB Setup and Network Setting Procedure Security Setting These security settings can be made to restrict access to setting items. For this page, the security settings page cannot be displayed unless [Administrator Menu] is clicked and the administrator’s user name and password are input on the verification screen. (For instructions on displaying the screen, see “Basic Setting Operations” step 3 on page E-34.) Security Setting Item Setting/Description Default USB Memory Set whether or not to enable or disable saving on USB memory devices. Valid PC connection (USB) Set whether or not to enable or disable saving in a computer storage Valid memory. Network Storage Set whether or not to enable or disable transfer of image files to network Valid storage (folder for saving: “Board” or “FTP Server”) to a computer or FTP server. Notice: • When set to “Invalid”, the network storage memory is formatted.

  • Page 41: Disk Management Setting

    CB Setup and Network Setting Procedure Disk management Setting The amount of disk space used can be checked, the disk can be checked and the disk can be formatted here. (For instructions on displaying the screen, see “Basic Setting Operations” step 3 on page E-34.) Disk Management Setting Setting/Description Default Item Disk Usage This displays the amount of network storage memory used (in percent- — age). Disk Check When the [Disk Check] button is clicked, checking of the network stor- — age memory starts. When checking is completed, the results of the check are displayed. If a warning is displayed, format the disk. Disk Format When the [Disk Format] button is clicked, the disk is formatted. — Notice: • Transfer important image files to a computer before formatting. CB Information This displays the contents of the detailed settings made on the copyboard and the copyboard’s firmware version.

  • Page 42: Resetting The Network Settings

    CB Setup and Network Setting Procedure Resetting the Network Settings Operate the buttons on the copyboard to reset the network settings to their defaults. Setting items that are reset: A dmin User name, Admin Password, User Name, Password, IP Address, Subnet Mask, Default Gate- way, Folder for saving, FTP User Name, FTP Password, FTP Server IP Address, FTP Server Port, FTP Save Directory Name Notice • Once reset, the network settings cannot be restored. While pressing the Power button, press the Network but- ton. The copyboard switches to the network settings reset mode and “00” flashes on the display window. Press the Color Print (Increase) or B/W Print (Decrease) button to display the network reset number. • The network reset number can be viewed when User Setting is selected with administrator authority.

  • Page 43: Creating And Registering Headers And Footers

    CB Setup and Network Setting Procedure Creating and Registering Headers and Footers The header/footer function allows you to superimpose your company name, logo, etc., at the top or bottom of scanned images for printing or display. The date and time are printed at the top right of the header. Creating header and footer images Use your image software to create a JPEG file. Create the image with the resolutions below. Max. size for header images: 1248 × 110 dots * Image format: JPEG Max. size for footer images: 1248 × 40 dots Image format: JPEG * This is sometimes expressed as “pixels”. Note: Even for image data whose resolution is within the allowable limits, it may happen that the top and bottom of the image are not displayed. Image display position Images are displayed at roughly the center in the horizontal direction. In the vertical direction they are positioned next to the scanned image area. Consider this when creating images with less than the maximum size.

  • Page 44: Meaning Of Error Messages

    When the “USb” letter display is • A USB memory device is plugged into • Did you press the ON/Standby button flowing...Warning that disconnec- the main unit. When the USB memory while the USB memory device was plugged tion of USB memory has been for- device is disconnected, the power will into the main unit? gotten be switched off and the unit will enter the standby mode. If the problem persists, please contact your nearby PLUS Corporation sales office, dealer, or store. E-44...
  • Page 45 Meaning of Error Messages Network (main unit) related errors Error Display Number Problem and Solution LAN cable dis- • No cable is connected to the LAN terminal. • Connect the LAN cable properly. connected FTP server rec- • The user name or password is wrong. • Input the correct user name and pass- ognition error word. (See page E-38.) FTP server con- • The FTP server’s IP address is wrong. • Consult the network administrator then nection failure set the FTP server’s IP address. (See page E-38.) FTP server writ-...

  • Page 46: Troubleshooting

    When the copyboard and PC are con- • Check whether the copyboard is in an operable condition, and whether the nected, the PC does not recognize the USB cable is connected properly. copyboard • Is the copyboard connected to the PC via a USB hub? (Connect the copyboard directly to the USB port of the PC.) The date is not updated. • The copyboard’s battery is dead. Contact your store of purchase. * If the problem persists, please contact your nearby PLUS Corporation sales office, dealer, or store. Condition Please Check The copyboard’s power turns on, but the • Check whether the printer’s power plug (DC plug) is securely inserted. printer’s power does not. If the power still does not turn on, disconnect the AC adapter box and check whether the printer’s AC power adapter side plug is unplugged from the AC power adapter. (For some printers it is directly mounted.) Printing is not possible when Color Print (or • Check that the power cable of the printer and the printer cable are securely...
  • Page 47 • Is “Caps Lock” set on the computer’s keyboard while inputting the user name and password? Test Printing 1) With the copyboard’s power on (with the display window lit), press the Number of Copies button repeatedly to display “ ” on the display window. 2) Press the Color Print ( ) button for a color print, the B/W Print ( ) button for a black-and-white print. * Test printing starts. Check the print • Is the each color line printed uniformly? • Are there missing dots, pale lines, lines with thinner ink than others, etc.? Remedy • If the nozzle is partially choked, clean it. • If the quality of the print does not improve even though the nozzle has been cleaned, wipe off the ink on the surface of te nozzle. For details, see the “User’s Guide” included with the printer. * Please see your printer manual for information about printing problems, printer maintenance, and details related to printing. Updating the copyboard’s internal program See the PLUS website for instructions on updating the program and to download the latest program. E-47...

  • Page 48: Specifications

    Specifications BOARD TYPE (Model name) Standard (N-20S) Wide (N-20W) Installation method Self-standing (T-shaped legs), or wall mounting External dimensions (T-shaped W1480 × D675 × H1947*² mm W1980 × D675 × H1947*² mm legs*¹) Form Main unit weight 20 kg*³ 25 kg*³...

  • Page 49: Appendix

    Appendix Connections and Wiring Diagram • The connections and wiring diagram below is included here for checking the connections. [Copyboard and Printer Connections Diagram] Copyboard front panel To Printer connector To DC INPUT connector USB cable (supplied with the printer) To USB connector Printer To DC connector Printer AC power adapter AC power adapter (supplied) (supplied with the printer) To wall power outlet * Appearance of printer is for illustration purposes. Note • The AC power adapters of accessories and printers that have been verified to be operation many differ from the ones shown on the connections diagram (they may be of the built-in or mounted-on type).
  • Page 50 26-4606-11A...
