- Page 1 Flight Type dishwasher EFTD052E-EFTD064E-EFTD082E- EFTD108E-EFTD052S-EFTD064S- EFTD082S-EFTD108S Installation manual * PM00509- 2020.03 *Original instructions...
- Page 2 Installation diagram EFTD052...1 left to right (with ESD)
- Page 3 Installation diagram EFTD052...1 right to left (with ESD)
- Page 4 Installation diagram EFTD052...1 left to right (without ESD)
- Page 5 Installation diagram EFTD052...1 right to left (without ESD)
- Page 6 Installation diagram EFTD064...1 left to right (with ESD)
- Page 7 Installation diagram EFTD064...1 right to left (with ESD)
- Page 8 Installation diagram EFTD064...1 left to right (without ESD)
- Page 9 Installation diagram EFTD064...1 right to left (without ESD)
- Page 10 Installation diagram EFTD082... left to right (with ESD)
- Page 11 Installation diagram EFTD082...1 right to left (with ESD)
- Page 12 Installation diagram EFTD082...1 left to right (without ESD)
- Page 13 Installation diagram EFTD082...1 right to left (without ESD)
- Page 14 Installation diagram EFTD1081...1 left to right (with ESD)
- Page 15 Installation diagram EFTD1081...1 right to left (with ESD)
- Page 16 Installation diagram EFTD1081...1 left to right (without ESD)
- Page 17 Installation diagram EFTD1081...1 right to left (without ESD)
- Page 18 CWI = Cold water inlet pipe [3/4″] EQ = Equipotential screw HWI = Hot water inlet pipe [3/4″] V = Vents D = Drain pipe [⌀ = 2″] * = Adjustable feet [100~180 mm] EI = Electrical inlet...
- Page 19 Foreword The installation, use and maintenance manual (hereinafter Manual) provides the user with information necessary for correct and safe use of the machine (or “appliance“). The following must not be considered a long and exacting list of warnings, but rather a set of instructions suitable for improving machine performance in every respect and, above all, preventing injury to persons and animals and damage to property due to im- proper operating procedures.
-
Page 20: Table Of Contents
Contents A SAFETY INFORMATION ........................21 General information ........................21 General safety ........................... 21 Personal protection equipment ...................... 22 Transport, handling and storage ....................22 Installation and assembly ......................23 Water connection........................23 Electrical connection ........................23 Service............................. 24 Disposal of packing ........................24 A.10 Machine disposal........................ -
Page 21: Asafety Information
SAFETY INFORMATION General information To ensure safe use of the machine and a proper understanding of the manual it is necessary to be familiar with the terms and typographical conventions used in the documentation. The following symbols are used in the manual to indicate and identify the various types of hazards: WARNING Danger for the health and safety of operators. -
Page 22: Personal Protection Equipment
• Machine positioning, installation and disassembly must be carried out by the specialised personnel in conformity with the current safety regulations, regarding the equipment used and the operating procedures. Personal protection equipment Summary table of the Personal Protection Equipment (PPE) to be used during the various stages of the machine's service life. -
Page 23: Installation And Assembly
• Do not push or pull the machine to move it, as it may tip over. Use proper tool to lift the machine. • Machine transport, handling and storage personnel must be adequately instructed and trained regarding the use of lifting systems and personal protection equipment suitable for the type of operation carried out. -
Page 24: Service
The Electrolux Professional warranty does not cover: designed, and as described within the appropriate equipment documentation. • service trips cost to deliver and pick up the product;... -
Page 25: Cgeneral Information
(including tampering, modifications and repairs carried subject to local terms and conditions. out by third parties not authorized third parties) and Check on Electrolux Professional website the list of authorized modification of safety systems; customer care. – Use of non-original components (e. g.: consumables, wear and tear, or spare parts);... -
Page 26: Appliance Identification
The factory description on the dataplate has the following meaning (some examples are given below): 1081 1081 Variable description (1) Brand E = Electrolux (2) Machine type FTD = Flight Type Dishwasher (3) Dishes/hour 052 = 5200 dishes/hour 064 = 6400 dishes/hour... -
Page 27: Copyright
• the carrier and handling personnel; and can only be given to third parties with the permission of • installation and commissioning personnel; Electrolux (Shanghai) Professional Appliance Co, Ltd. • specialised personnel - Customer Care service (see service manual). PRODUCT OVERVIEW... - Page 28 Modules composition EFT052D...1 1.000 4.150 EFT052D...1 1.000 4.150 EFT062D...1 1000 5150 EFT062D...1 1000 5150...
- Page 29 Modules composition (cont'd.) EFT082D...1 1.300 6.250 EFT082D...1 1.300 6.250 EFT108D...1 1.600 7.350 EFT108D...1 1.600 7.350 Modules descriptions 3 optional lengths Inlet 750 mm 950 mm 1100 mm Optional module Prewash section 800 mm...
-
Page 30: Etechnical Data
Modules descriptions (cont'd.) Wash section 3 optional lengths 800 mm 1600 mm 2400 mm Rinse section Rinse module 800 mm Rinse section Rinse module 800 mm Dryer section Optional module 800 mm 5 optional lengths Outlet section 1000 mm 1300 mm 1600 mm 1900 mm 2200 mm... - Page 31 Electrical models (cont'd.) For appliance with Energy Saving Device If the inlet water temperature is higher than 45℃, reduce the boiler heating power of 9 KW. Recommended cold water supply temperature 10℃ Recommended hot water supply temperature 50℃. Steam Models Model EFTD052S1 EFTD064S1...
-
Page 32: Characteristics Of Power Supply
Main ON/OFF switch (residual current circuit breaker) Max power 30-36 53-60 61-67 68-87 88-110 [KW] 220V 125A 200A 225A 300A 350A 380V 125A 125A 160A 200A Power supply cable Max power 37-42 43-69 70-85 86-108 [KW] YJV3*2.5 YJV3*6+2*4 YJV3*16+2*10 YJV3*25+2*16 YJV3*35+2*16 YJV3*50+2*25 +2*1.5... -
Page 33: Ginstallation And Assembly
Note • The driver must sign the dispatch note: the forwarder can reject the claim if the dispatch note is not signed (the • The forwarder is responsible for the goods during transport forwarder can provide the necessary form). and delivery. •... -
Page 34: Mechanical Connection
NOTE! Join the modules General ventilation for the room should be still • Remove the front and back panels of each modules. provided in accordance with “UNI ISO EN 7730“ norm, “VDI2052“ guideline and “DW/172 UK“ or local regulation. Mechanical connection NOTE! Make sure that the room temperature where you install the machine must be at least 18℃... - Page 35 • Fit the adhesive seal all around each module opening. • Install the energy saving device [ESD] on the top of the appliance. Join the openings of the modules with the bolts, washer and nuts (see detail “C“). CH 10 x 37 •...
- Page 36 • Remove the front and the side panel from the loading • Join all separated pieces of the conveyor belt all together. module. • Remove all upper panels and lower front panel from the unloading module. • Insert the conveyor belt from the loading module by sliding it on the upper guide rails.
-
Page 37: Disposal Of Packing
• Check the tension of the conveyor belt and, if necessary, adjust it. • Refit all panels previously removed. Level the machine • Adjust the equipment by turning the special adjustable feet. Make sure it is perfectly level, both length wise and crosswise. - Page 38 If the water pressure is: Drain outlet hose connection • more than600 kPa [6 bar], a pressure reducing valve must • Connect the drain outlet hose to the main drain pipe, fitting a be installed on the inlet pipe. The supply water temperature trap, or place the outlet pipe over an “S“...
-
Page 39: Plumbing Circuits
Plumbing circuits Models without ESD EFTD052...1 82°- 90°C 55-65°C EFTD064...1 82°- 90°C 55-65°C 40-50°C EFTD082...1 82°- 90°C 55-65°C 55-65°C 40-50°C EFTD108...1 82°- 90°C 55-65°C 55-65°C 55-65°C 40-50°C... - Page 40 Models with ESD EFTD052...1 82°- 90°C 55-65°C EFTD064...1 82°- 90°C 55-65°C 40-50°C EFTD082...1 82°- 90°C 55-65°C 55-65°C 40-50°C EFTD108...1 82°- 90°C 55-65°C 55-65°C 55-65°C 40-50°C • M4 = Wash pump LEGEND • M5 = Wash pump • CWI = Water inlet •...
-
Page 41: Positioning Of Emergency Switches
To obtain excellence washing performance, use detergent, rinse aid and descaling agent sug- Contact with chemical substan- gested by Electrolux Professional. In the Electrolux Professional web site, open the “Accessories and ces (e. g. detergent, rinse aid, Consumables“ web page and navigate into the scale remover, etc.) without... -
Page 42: G.11 Changing The Type Of Detergent/Rinse Aid
Connect the power cable to the equipment: • Remove the top panel and insert the power supply cable through the cable gland. 380-415 • Connect the power supply cable to the terminal block. G.11 Changing the type of detergent/rinse aid If changing to a different detergent/rinse aid type (even one by the same manufacturer), you must rinse the suction and pressure hoses with fresh water before connecting the new... -
Page 43: G.13 Fitting Curtains
DRYER [1/2D] DRYER [2/2D-1/1D] UNLOAD SOLENOID IMPORTANT NOTE! Make sure to refit the top panel of the electric box at For additional information, refer to the wiring the end of the installation. diagram, supplied with the equipment. G.13 Fitting curtains With the machine switched off and cold, fit the curtains and splashing plate as illustrated below. -
Page 44: Hcontrol Panel Description
Curtains and splashing plate position (cont'd.) EFTD082..1 EFTD108..1 A. inlet module; D.rinse module; B. pre-wash module; E.drying module; C. wash module; F. outlet module. Double long curtain Double short curtain Long splashing plate Short splashing plate CONTROL PANEL DESCRIPTION Control panel description OFF button POWER light ON button... -
Page 45: Icommissioning
ON button and POWER indicator Press this button to switch the appliance on. The Power indicator light light is on and the water start to fill the tanks. After some minutes also the tank heating elements start to warm the water. The red indicator light of the pause button blinks alternately every second during the filling and heating phases. -
Page 46: Fitting Of Wash And Rinse Arms
2. the filter of prewash and wash pump is correctly installed; 5. the filter and the overflow of the rinse tank are correctly installed. Fitting of wash and rinse arms Make sure that: 1. the upper and lower washing arm are correctly installed; 3. -
Page 47: First Use
