- Page 1 Sprayer Monitor Progra m m ing a nd Ope ra t ing M a nua l (v2 .1 0 A) 9 8 -7 0 0 1 3 -R0 TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 1 of 15...
-
Page 2: Table Of Contents
Appe ndix A: Ove rvie w of M onit or Displa ys____________________________________________1 4 Appe ndix B: Ove rvie w of Progra m m ing St e ps ________________________________________1 5 TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 2 of 15... -
Page 3: Progra M M Ing Guide Line S
Holding the Clr key restores the parameter with its minimum value (mostly zero) The value of a parameter is changed with the Up and Down keys. Holding the Up or Down key changes the parameter rapidly. TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 3 of 15... -
Page 4: St A Rt
This information will be needed when calling for service support. 814 US V2.10A Example : the 814-spray monitor is working in US units and the software version is V2.00A. After a short time the Console will change to the normal monitor mode. -
Page 5: Syst E M Se T Up M Ode
The speed sensor needs to be calibrated in order to provide the proper speed and area readings. The value for this step is the number of pulses generated by the speed sensor in 300 ft (100 meters). TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 5 of 15... - Page 6 To accept the value and advance to the next step press the Pro key. A radar speed sensor will be indicated with an "r" on the display e.g. Drive300ft r 11 TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 6 of 15...
-
Page 7: Simulated Speed
3 sections. All others should be set to 0). Use the Up and Down keys to change the value. > 10.0ft Sect 1 TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 7 of 15... -
Page 8: Pressure Sensor Calibration
In this programming step, the type of section valve (2-Way or 3-Way) must be selected. Use the Up and Down keys to change the value. >2 Way TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 8 of 15... -
Page 9: Completing The System Setup Mode
NOW, PRESS AND HOLD THE Pro KEY FOR THREE SECONDS AND THE CONSOLE WILL RETURN TO THE NORMAL MONITOR MODE. Note: For your protection, the 814 console will not automatically power down while in the System Setup Mode. You must exit properly as described above to enable the auto power down feature. -
Page 10: N Orm A L M Onit Or M Ode
In this display the flow rate in GPM (l/min) and the pressure in PSI (bar) is shown. The pressure is only shown when there is a pressure sensor installed. 35.2 GPA TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 10 of 15... -
Page 11: Sprayed Area And Sprayed Volume
In this display the current working width is shown. The working width depends on the number of closed sections and whether or not the Master switch is turned on. 45.0 ft <---> Press the Up or Down key to select another display. TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 11 of 15... -
Page 12: Ope Ra T Ing I Nst Ruc T Ions
♦ actual application rate in GPA (l/Ha) ♦ vehicle speed in MPH (Km/h) ♦ pressure in PSI (bar) ♦ actual working width in ft (m) ♦ application area covered in Ac (Ha) TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 12 of 15... -
Page 13: Aut Om A T Ic Pow E R Dow N
Aut om a t ic Pow e r Dow n The TeeJet 814 Sprayer Monitor has an automatic power down feature. With the Master switch in the “OFF” position, the Console will automatically shut down after 10 minutes of no inputs (when in normal monitor mode). -
Page 14: Appe Ndix A: Ove Rvie W Of M Onit Or Displa Ys
Appe ndix A: Ove rvie w of M onit or Displa ys 10.0 MPH 25.0GPA 25.0 GPA 36 PSI 51.3 GPM 45 PSI 5.126 Ac 152 Gal 90.0 ft <---> TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 14 of 15... -
Page 15: Appe Ndix B: Ove Rvie W Of Progra M M Ing St E Ps
Appe ndix B: Ove rvie w of Progra m m ing St e ps > US units > 250 puls/300ft > 650 puls/l > 9.00ft Sect1-9 >4.0 mA 0.0 Bar >10.0 Bar 20 mA > 2 Way TeeJet 814 Sprayer Monitor Programming and Operating Manual (V1.00) Page 15 of 15...
