DVD PLAYER
XV-515GD
O P E N /
DVD
CLOSE
RETURN
TV
/
/
STOP
PAUSE
PLAY
TITLE
MENU
ENTER
THEATER
POSITION
ON SCREEN
TM
3D PHONIC SUBTITLE STROBE ANGLE
CANCEL RESUME
ZOOM
DIGEST
XV-515
1
2
3
4
/
5
6
7
8
STANDBY
+ 10
9
10
0
TV/VIDEO
+
+
TV ch
TV VOL.
SHIFT
-
-
RM-SV511UG REMOTE CONTROL
3D PHONIC
DOLBY
D I G I T A L
INSTRUCTIONS
SHUTTLE
PLAY
STOP
PAUSE
SKIP
OPEN/CLOSE
DVD/SUPER VIDEO CD/VIDEO CD/CD
For Customer Use:
Enter below the Model No. and Serial No.
which are located on the rear, bottom or
side of the cabinet. Retain this informa-
tion for future reference.
Model No.
Serial No.
LVT0336-014A
[UX, 3U, 4U, US, A, UT, UB]
1
4
12
17
20
34
39
Advertisement
Table of Contents
Related Manuals for JVC XV-515GD
Summary of Contents for JVC XV-515GD
-
Page 1: Table Of Contents
DVD PLAYER XV-515GD Introduction Preliminary know ledge Getting started Basic operations Advanced operations O P E N / CLOSE RETURN STOP PAUSE PLAY TITLE MENU Setting and adjustment ENTER THEATER POSITION ON SCREEN VIDEO CD 3D PHONIC SUBTITLE STROBE ANGLE... - Page 2 Warnings, Cautions and Others CAUTION Caution –– button! To reduce the risk of electrical shocks, fire, etc.: Disconnect the mains plug to shut the power off completely. The button in any position does not disconnect the mains line. The power can be remote 1.
- Page 3 Introduction Table of contents To locate a desired scene from the opening Introduction Page 1 scene digest display [DIGEST] ....... 23 Features ..............Special picture playback Supplied accessories ..........To advance a still picture fram e-by-fram e ....24 About this instruction manual ....... To display still pictures [STROBE] ......
-
Page 4: Introduction
I nt roduc t ion Introduction Features Supplied accessories Picture functions • Audio/video cable (x 1) Strobe function The unit can display nine continuous still pictures on the TV screen. Digest function You can select the desired title from the opening scenes displayed on the TV screen. -
Page 5: About This Instruction Manual
Introduction About this instruction manual This instruction m anual basically explains operations as follow s: To display still pictures [STROBE] These sym bols indicate the types of discs w hich the O P E N / CLOSE RETURN operation can be STOP PAUSE used for. -
Page 6: Notes On Handling
Introduction Notes on handling Important cautions Safety precautions Installation of the unit Avoid moisture, w ater and dust • Select a place w hich is level, dry and neither too hot Do not place your player in m oist or dusty places. nor too cold (betw een 5˚C and 35˚C, 41˚F and 95˚F). -
Page 7: Preliminary Know Ledge
Pre lim ina ry k now le dge Prelim inary know ledge Names of parts and controls Refer to the corresponding pages indicated in () for details. Front panel 2 STANDBY indicator 3 3D PHONIC button (PLAY) button 9 SHUTTLE knob 5 Display 4 Remote sensor 8 8(PAUSE) -
Page 8: Display Window
Connects to the w all outlet. 4 AV COM PU LINK jacks (39) 8 Region Code label (11) Connects w ith other JVC equipm ent supporting the AV Show s Region Code num ber. Com pulink function to facilitate integrated operations. -
Page 9: Remote Control Unit
Prelim inary know ledge Remote control unit # Infrared signal-emitting w indow $ TV button % DVD button 1 RETURN button O P E N / CLOSE RETURN 3 ¡ button 2 OPEN/ CLOSE button STOP PAUSE 3 1 button ^ 8(PAUSE) button 4 7(STOP) button 5 ¢... - Page 10 Prelim inary know ledge 1 RETURN button (for DVD/ Video CD/ SVCD) (20) @ SHIFT button (16) When pressing and holding this button, the num eric keys (0 - Returns to the previous m enu. 9) select the TV channels. Also used to display the PARENTAL 2 OPEN/ CLOSE button (17) LOCK display.
-
Page 11: Operational Principles
Prelim inary know ledge Operational Principles On-screen displays The unit provides several on-screen displays as show n below for choosing preferences for initial settings and functions w hich are not frequently used. To access on-screen displays Press ON SCREEN. (Note that operation for accessing the “ PARENTAL LOCK” on-screen display is different.) Depending on the type of disc inserted ( or “... - Page 12 Prelim inary know ledge PARENTAL LOCK display (see page 37) PARENTAL LOCK You can set the parental lock from this display. Country Code To display the PARENTAL LOCK display LEVEL 8 Set Level – – – – PASSWORD Press ENTER w hile holding dow n SHIFT. The Parental Lock on-screen display appears on the TV screen.
-
Page 13: To Prevent The Monitor From Burning Out [Screen Saver]
Prelim inary know ledge To prevent the monitor from burning out [SCREEN SAVER] A television m onitor screen m ay be burned out if a static picture is displayed for a long tim e. To prevent this, the unit autom atically activates the screen DVD/Super VCD/Video CD/CD PLAYER saver function if a static picture, such as an on-screen display or m enu, is displayed for over 5 m inutes. -
Page 14: About Discs
Prelim inary know ledge About discs Playable disc types Playable and non-playable disc types are as follow s: Playable discs DVD VIDEO Video CD SVCD Audio CD VIDEO CD The DVD Logo is a tradem ark. • DVD players and DVD discs have their ow n Region Code num bers. This unit only can play back DVD discs w hose Region Code num bers include the unit’s Region Code, w hich is indicated on the region code sym bol on the rear panel. -
Page 15: Getting Started
Ge t t ing st a rt e d Getting started Connections * In the follow ing despription, "TV" m ay be substituted w ith "m onitor" or "projector." * Before using the unit, you have to connect the unit to a TV and/or am plifier. Before making any connections •... -
Page 16: To Connect To An Audio Amplifier Or Receiver
Getting started To connect to an audio amplifier or receiver You can enjoy high-quality audio by connecting the unit's audio output to your am plifier or receiver. The unit VIDEO OUT VIDEO S-VIDEO NTSC AV COMPU LINK AUDIO OUT LEFT PCM/STREAM OPTICAL RIGHT... -
Page 17: To Connect The Power Cord
Getting started To connect the power cord When all the connections have been m ade, insert the pow er plug into the w all outlet firm ly. The STANDBY indicator lights and setup is com pleted. Warning • Disconnect the pow er cord if you are not going to use the unit for a long tim e. •... -
Page 18: Using The Remote Control Unit
Getting started Using the remote control unit Using the rem ote control, you can operate not only all the functions of the unit but also basic functions of your TV. To install batteries in the remote control unit The battery com partm ent is located on the back of the rem ote control unit. Press dow n on the point show n by the arrow at the top of the com partm ent cover, and pull up the cover to open the com partm ent. -
Page 19: To Use The Remote Control Unit For Tv Operation
If your TV turns on or off, you have successfully set the control signal. NOTE • The remote control unit is initially set for operating a JVC TV. • If there is more than one code listed for the manufacturer of your TV, try them one by one until you succeed. -
Page 20: Basic Operations
Ba sic ope ra t ions Basic operations In the follow ing description, the buttons on the rem ote control unit are used, how ever, you m ay use the corresponding buttons on the front panel of the unit if available. Turning on/ off the unit * M ake sure that the PAL/NTSC sw itch on the rear panel is correctly set to m atch your TV. -
Page 21: Basic Playback
Basic operations Basic playback Now you can play a disc. First, let’s enjoy sim ple playback according to follow ing procedure. To play a disc from the beginning Press PLAY. The unit starts playback from the beginning. O P E N / CLOSE RETURN NOTES... -
Page 22: To Locate The Beginning Of The Scene Or Song
Basic operations To locate the beginning of the scene or song During playback Press ¢ or 4. Press 4 to locate the beginning of the current chapter, title, or track, and press ¢ to locate the beginning of the next chapter, title, or track. NOTE When you play a Video CD or SVCD disc w ith the PBC function or a DVD disc, the unit m ay locate a different place, but it w ill generally locate the beginning of the title or chapter or track. -
Page 23: Advanced Operations
Adva nc e d Ope ra t ions Advanced Operations NOTES Playing from a specific • When appears on the TV screen by pressing TITLE in position on a disc step 1: The disc does not have a m enu listing the titles. •... -
Page 24: To Locate A Desired Scene Or Track Directly
Advanced Operations You can also see the selected title or track num ber on the on- • To activate the PBC function w hen a PBC-com patible Video screen display. CD or SVCD disc is being played back w ithout the PBC function, press STOP then press PLAY. -
Page 25: To Locate A Desired Scene By Specifying The Chapter Number [Chap. Search]
Advanced Operations NOTES To locate a desired scene by specifying • When the chapter number is incorrect in step 3: the chapter number [CHAP. SEARCH] Overw rite the incorrect num ber w ith the correct num ber. • When is displayed in the TV screen in step 4: The chapter you have selected is not contained in the disc, or chapter search does not w ork on the disc. -
Page 26: To Locate A Desired Scene From The Opening Scene Digest Display [Digest]
Advanced Operations (for DVD) (for Audio CD) To locate a desired scene from the opening scene digest display [DIGEST] TRACK 01 TIME 3 : 54 EACH REMAIN ANGLE 1 / 3 TIME SELECT AUDIO 2 / 3 REPEAT PRESS NUMERIC KEY SUB- 1 / 3 TITLE... -
Page 27: Special Picture Playback
Advanced Operations Press ENTER. To display still pictures [STROBE] The unit starts playback from the selected title or track. O P E N / CLOSE RETURN STOP PAUSE When you press DIGEST during DVD playback, the unit PLAY displays the opening scene of each chapter and you can select TITLE MENU the desired chapter. -
Page 28: To Playback In Slow-Motion [Slow]
Advanced Operations To playback in slow-motion [SLOW] To zoom a scene [ZOOM] O P E N / CLOSE RETURN O P E N / CLOSE RETURN STOP PAUSE STOP PAUSE PLAY PLAY TITLE MENU TITLE MENU ENTER ENTER THEATER POSITION ON SCREEN THEATER POSITION... -
Page 29: Changing The Track Order
Advanced Operations • When you make a mistake Changing the track order Press CANCEL. The last track program m ed is erased. You can play tracks on a Audio CD, Video CD or SVCD in the desired order or in random order. Press PLAY to start program play. -
Page 30: Repeat Playback
Advanced Operations Press ENTER. • for DVD The current title or chapter w ill be repeated. The color of [RANDOM ] changes. Random play begins. ANGLE 1 / 3 AUDIO 2 / 3 SUB- 1 / 3 TITLE T. REPEAT •... -
Page 31: To Repeat A Desired Part [A-B Repeat]
Advanced Operations NOTES To repeat a desired part [A-B REPEAT] • To turn off the on-screen display Press ON SCREEN. • If appears w hen pressing ENTER in step 2 during DVD playback You cannot repeat the selected portion because of the O P E N / CLOSE RETURN... -
Page 32: Viewing From Multiple Angles
Advanced Operations Viewing from multiple angles To select a scene angle from the on- screen display [ANGLE] You can enjoy a variety of scene angles if the DVD disc contains “ m ulti-angle” parts, w here m ultiple cam eras w ere used to shoot the sam e scene from different angles. -
Page 33: To Select A Scene Angle From The Angle List Display [Angle]
Advanced Operations Changing the language and To select a scene angle from the angle list display [ANGLE] sound For DVD and SVCD discs, you can select the subtitle language, as w ell as the audio language/sound included on a disc. O P E N / For Video CD discs, you can select the audio channel(s). -
Page 34: To Change The Audio Language Or Sound [Audio]
Advanced Operations Press ON SCREEN. To change the audio language or sound The on-screen display appears on the TV screen. [AUDIO] Use CURSOR 5/∞ to move [ SUBTITLE] . By AUDIO selection, you can choose the audio language of m ovies or choose to enjoy karaoke w ithout Total num ber the vocal or w ith the vocal. -
Page 35: Selecting The Picture Character
Advanced Operations • For Video CD During playback Pressing CURSOR 2/3 cycles am ong the audio Press THEATER POSITION to select the channels as follow s. desired picture character. L / R Each tim e you press the button, the picture character changes as follow s: THEATER... -
Page 36: Checking The Disc Time
Advanced Operations For Audio CD: During playback or w hile * When you play a DVD disc recorded in Dolby stopped Digital w hich contains m ore than 2 channels, For Video CD/SVCD: While stopped ACTION does not appear. Press ON SCREEN. Press CURSOR 2/3 to adjust the effect level. -
Page 37: Setting And Adjustment
Se t t ing a nd a djust m e nt Setting and adjustm ent Selecting preferences To set the language and display preference items You can set various preferences for playback via the “ PREFERENCE” display. PREFERENCE 1 can be set as follow s: M ENU LANGUAGE How to set preferences on the You can select a default... -
Page 38: To Set Other Preference Items
Setting and adjustm ent M ONITOR TYPE ENGLISH = SPANISH = FRENCH = CHINESE = GERM AN = ITALIAN = JAPANESE = language code You can select the m onitor type to m atch your TV w hen from AA to ZU you playback DVD discs recorded for w ide screen (See “... -
Page 39: Video Cd
Setting and adjustm ent COM PRESSION The follow ing chart show s the relationship betw een types of playback discs and output signals. You can com press the PREFERENCE1 PREFERENCE2 dynam ic range of the DIGITAL AUDIO OUTPUT PCM ONLY Playback discs Output sound if needed. -
Page 40: Limiting Playback By Children
Setting and adjustm ent AV COM PULINK M ODE Use CURSOR 5/∞ to move to [ Country If you use the AV Code] , then use CURSOR 2/3 to select the PREFERENCE1 PREFERENCE2 Com pulink system , you country code and press ENTER. DIGITAL AUDIO OUTPUT PCM ONLY m ust set this item... -
Page 41: To Change The Settings [Parental Lock]
Setting and adjustm ent To change the settings [PARENTAL LOCK] To temporarily release the Parental lock [PARENTAL LOCK] O P E N / CLOSE RETURN STOP PAUSE PLAY TITLE MENU 1, 2, 3, O P E N / ENTER CLOSE RETURN THEATER POSITION... -
Page 42: Dvd Player
When you buy a separate TV, VCR, DVD player, receiver, or other com ponents and connect them to each other, you have to operate each com ponent individually. JVC’s AV COM PU LINK rem ote control system m eets the dem and for a system m ade up of single com ponents and has the ease of operation of a single unit. -
Page 43: Care And Handling Of Discs
Additional inform ation Notes for connection If you connect a DVD player w ith a receiver via AV COM PU LINK in a system including a Dolby digital decoder, ¶ some functions may not be performed automatically. The AV COM PU LINK terminal on some televisions indicates “II”. Do not connect the terminal indicating “II” ¶... -
Page 44: Troubleshooting
Additional inform ation Troubleshooting What appears to be a m alfunction m ay not alw ays be serious. Please go through the follow ing list before requesting service. Symptom Possible case Remedy Pow er does not com e on. Pow er plug is not inserted securely. Plug in securely. -
Page 45: Specifications
Additional inform ation Specifications General Readable discs: DVD VIDEO, Audio CD, Video CD, SVCD Video form at: PAL/NTSC selectable Other Pow er requirem ents: AC 110-240 V , 50/60 Hz Pow er consum ption: 21 W (POWER ON), 2 W (STANDBY m ode) M ass: 4.3 kg (9.5 lbs) Dim ensions (W x H x D):... -
Page 46: Table Of Languages And Their Abbreviations
Appendix A: Table of languages and their abbreviations When you select the subtitle language or sound, the languages show n below are displayed as abbreviations. To select the desired language, select the abbreviation corresponding the language you w ant to. Kirundi Afar Inupiak... -
Page 47: Country Code List For Parental Lock
Appendix B: Country code list for parental lock This list is used for the parental Lock operation. For details, see page 37. Spain Andorra Saudi Arabia Lebanon United Arab Em irates Ethiopia Solom on Islands Saint Lucia Finland Afghanistan Seychelles Liechtenstein Fiji Antigua and Barbuda... - Page 48 VICTOR COMPANY OF JAPAN, LIMITED 0999AOMUBNJSC...
- Page 49 This file has been downloaded from: www.UsersManualGuide.com User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes.. Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide, manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product, documentation manual, user maintenance, brochure, user reference, pdf manual Downloaded from:...
