Page 1: Table Of Contents
For Customer Use: Enter below the Model No. and Serial No. which are located on the rear, bottom or side of the cabinet. Retain this informa- tion for future reference. Model No. Serial No. Downloaded From Disc-Player.com JVC Manuals LVT0435-004B...
Page 2 2. DANGER: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. 3. CAUTION: Do not open the top cover. There are no user service- able parts inside the Unit; leave all servicing to qualified service personnel. Downloaded From Disc-Player.com JVC Manuals...
Page 3 To install batteries in the remote control unit ..15 Initial settings Page 35 To use the remote control unit for TV operation ... 16 To control the volume of a JVC’s amplifier or Selecting preferences receiver ..............16 How to set preferences ..........35 LANGUAGE page ............
Page 4: Introduction
Operation from the on-screen display User-friendly on-screen displays allow you to operate • AC power cord (x 1) the unit easily. Functions with (*) mark only work on a DVD VIDEO disc that is compatible with each function. Downloaded From Disc-Player.com JVC Manuals...
Page 5: About This Instruction Manual
To quit random playback, press STOP again while stopped. The “RANDOM” indicator in the display window turns off. NOTE Additional Some DVD VIDEO discs may not be played back correctly supplemental in random mode. remarks Downloaded From Disc-Player.com JVC Manuals...
Page 6: Notes On Handling
Manufactured under license from Digital Theater Systems, Inc. US Pat. No. 5,451,942 and other world-wide patents issues and pending. “DTS”and “DTS Digital Surround”, are trademarks of Digital Theater Systems, Inc. © 1996 Digital Theater Systems, Inc. All rights reserved. Downloaded From Disc-Player.com JVC Manuals...
Page 7: Preliminary Knowledge
Also used for slow-motion playback of a picture (for DVD Also used to erase all programmed tracks for the program VIDEO/Video CD). play. 7 # (PLAY) button (18) Starts playback. Also, used as a SELECT button for the PBC of Video CDs. Downloaded From Disc-Player.com JVC Manuals...
Page 8: Remote Control Unit
STOP + ENTER button - 8 (PAUSE) button ¡ 7 (STOP) button = TITLE button ™ MENU button LEFT RIGHT CURSOR ~ CURSOR (5 UP, ∞ DOWN, 2 LEFT, 3 RIGHT) button DOWN REMOTE CONTROL Downloaded From Disc-Player.com JVC Manuals...
Page 9 Pressing this button while holding down the SHIFT button 7 AMP VOL button (16) displays Preference on-screen display on the TV screen. Used to control the volume of a JVC audio amplifier/ ( DISPLAY - TIME button (33, 34) receiver.
Page 10: Display Window
The video output signal is selected from 4 AV COMPU LINK jacks (41) composite (COMP) and Y/C by the COMP-Y/C switch. The Connect with other JVC equipment supporting the AV audio signal is same as AUDIO OUT. Compulink function to facilitate integrated operations.
Page 11: Operational Principles
SHIFT button accesses the PARENTAL LOCK Country Code display in which you can set the level for limiting — Set Level - - - - PASS WORD playback. See page 39 for detailed information. EXIT PRESS ENTER Downloaded From Disc-Player.com JVC Manuals...
Page 12: To Prevent The Monitor From Burning Out [Screen Saver]
• You can select one of several screen saver modes available (see page 37). • The screen saver function is not activated during Audio CD playback or after stopping Audio CD playback. Downloaded From Disc-Player.com JVC Manuals...
Page 13: On-Screen Guide Icons
See the corresponding sections in this manual for the details. To select a TV channel. Press the corresponding numeric buttons (between 0 and 9) while holding down the SHIFT button. Downloaded From Disc-Player.com JVC Manuals...
Page 14: About Discs
(Example: DVD VIDEO disc) Title 1 Title 2 Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2 (Example: Audio CD/Video CD) Track 1 Track 2 Track 3 Track 4 Downloaded From Disc-Player.com JVC Manuals...
Page 15: Getting Started
• Connect VIDEO OUT of the unit directly to the video input of your TV. Connecting VIDEO OUT of the unit to a TV via a VCR may cause a monitor problem when playing back a copy-protected disc. • Connect the unit to a PAL television. Do not connect the unit to an NTSC television. Downloaded From Disc-Player.com JVC Manuals...
Page 16: To Connect To A Tv With The Scart Connector
VIDEO Amplifier or receiver White White LEFT AUDIO RIGHT Audio cable (not supplied) • Connect the unit's AUDIO OUT to any line-level inputs (such as AUX, DVD, CD, etc.) of an audio amplifier or receiver. Downloaded From Disc-Player.com JVC Manuals...
Page 17: To Connect To Audio Equipment With A Digital Input
Downloaded From Disc-Player.com JVC Manuals • Do not put anything heavy, or the unit, on the power cord, as this may cause fire, electric shock, or other accidents.
Page 18: Using The Remote Control Unit
• Never leave dead batteries lying around, take them apart, mix them with other refuse, or throw them into an incinerator. • Never touch liquid that has leaked out of a battery. • Do not mix new and old batteries, or batteries of different types, when replacing them. Downloaded From Disc-Player.com JVC Manuals...
Page 19: To Use The Remote Control Unit For Tv Operation
• If there is more than one code listed for the manufacturer of your TV, try them one by one until you succeed. To control the volume of a JVC’s amplifier or receiver You can control the volume of a JVC’s amplifier or receiver by using the AMP VOL button on the remote control unit. Downloaded From Disc-Player.com JVC Manuals...
Page 20: Basic Operations
• When loading a disc in the tray, be sure to position the disc inside the recess. Otherwise, the disc may be damaged when the tray is closed, and the disc may not be removed from the unit. Downloaded From Disc-Player.com JVC Manuals...
Page 21: Basic Playback
By releasing the shuttle knob, the unit returns to normal playback. The playback speed changes according to the amount you turn the shuttle knob. Downloaded From Disc-Player.com JVC Manuals Holding down the 4 or ¢ button on the front panel also advances or reverses playback rapidly.
Page 22: To Locate The Beginning Of The Scene Or Song
• In the case of a Video CD disc with PBC function, the unit may resume playback from a point slightly earlier than the resume point you stored. Downloaded From Disc-Player.com JVC Manuals • The resume function does not work in the program or random mode.
Page 23: Advanced Operations
You can return to the menu by pressing RETURN - CHOICE. With some discs, you can also select items by entering the corresponding number using the numeric buttons, which may Downloaded From Disc-Player.com JVC Manuals cause the unit to automatically start playback.
Page 24: To Locate A Desired Selection Using The Numeric Buttons
• See page 10 for details about how to use the with PBC function numeric buttons. The selected title or track number appears in the display window on the front panel. Display window TITLE TRACK Downloaded From Disc-Player.com JVC Manuals...
Page 25: To Locate A Desired Scene By Specifying The Chapter Number [Chap. Search]
Use the numeric buttons (0 ~ 9) to enter the The “10” and “+10” buttons are not used in this function. time. You can specify the elapsed time of the current title or track to set the location which you want to playback from. Downloaded From Disc-Player.com JVC Manuals...
Page 26: To Locate A Desired Scene From The Digest Display [Digest]
4 returns to the previous page. during Video CD playback with the PBC function. • To turn off the play mode menu: Press PLAY MODE. • The TIME SEARCH function cannot be used during program playback. Downloaded From Disc-Player.com JVC Manuals...
Page 27: Special Picture Playback
The unit pauses playback. Press AUDIO - STROBE while holding down SHIFT. Nine continuous still pictures appear on the TV screen. • Pressing PAUSE when the nine still pictures appear will Downloaded From Disc-Player.com JVC Manuals advance to the next nine still pictures.
Page 28: To Playback In Slow-Motion [Slow]
To play forward slow-motion, turn the SHUTTLE knob to the right. To play reverse slow-motion (for DVD VIDEO discs only), turn it to the left. The more you turn the knob, the more the slow- motion speed increases. Downloaded From Disc-Player.com JVC Manuals...
Page 29: To Zoom A Scene [Zoom]
• To return to normal playback Press ANGLE - ZOOM while holding down SHIFT. NOTE During Zoom play, the picture may be garbled or noisy. Downloaded From Disc-Player.com JVC Manuals The programmed title/track number is shown under each program number.
Page 30: To Playback In Random Order [Random]
To quit random playback, press STOP again while stopped. The “RANDOM” indicator in the display window turns off. NOTE Some DVD VIDEO discs may not be played back correctly in random mode. Downloaded From Disc-Player.com JVC Manuals...
Page 31: Repeat Playback
TV screen. REPEAT ALL (all title repeat) * REPEAT TITLE (current title repeat) * REPEAT CHAPTER (current chapter repeat) No indication (off) * While stopped, you cannot select REPEAT TITLE or REPEAT CHAPTER. Downloaded From Disc-Player.com JVC Manuals...
Page 32: To Repeat A Desired Part [A-B Repeat]
A 0:00:16 B 0:01:16 A 0:00:16 B 0:01:31 Point A Point B Point A Point B (for Video CD) VCD CONTROL REPEAT A-B REPEAT TIME SEARCH PBC CALL A 0:00:16 B 0:01:31 Point A Point B Downloaded From Disc-Player.com JVC Manuals...
Page 33: Selecting A Scene Angle Of Dvd Video
10 seconds. • To turn off the Angle selection display manually, press ENTER. • When appears on the TV screen Downloaded From Disc-Player.com JVC Manuals The current scene is not recorded from multiple angles.
Page 34: Changing The Language And Sound
• To turn off the Subtitle selection display manually, press ENTER. ENTER. • When appears on the TV screen (for a DVD VIDEO disc): • When appears on the TV screen: Downloaded From Disc-Player.com JVC Manuals You cannot select the audio. You cannot select the subtitle.
Page 35: Selecting The Picture Character
Suitable for action movies and sports programs in which sounds dynamically move. • DRAMA: Natural and warm sound. You can enjoy movies in a relaxed mood. • THEATER: You can enjoy sound effects like in a major theater in Downloaded From Disc-Player.com JVC Manuals Hollywood.
Page 36: Checking The Status
(for Audio CD or Video CD playing without PBC) 00:08 TRACK TIME EACH Time mode Time Current track number (for Video CD playing with PBC) 25:25 PBC TRACK TIME PBC on status Time Current track number Downloaded From Disc-Player.com JVC Manuals...
Page 37: To Check The Dvd Function Status
(selected) track time appears. When only REMAIN is indicated, the total disc time appears. You can change the current (selected) track by pressing 4 or ¢. • To turn off the disc/time display Press DISPLAY-TIME. Downloaded From Disc-Player.com JVC Manuals...
Page 38: Initial Settings
* If the selected language is not recorded, the disc’s LANGUAGE AUDIO DISPLAY SYSTEM default audio language will be played. ENGLISH MENU LANGUAGE AUDIO LANGUAGE ENGLISH SUBTITLE ENGLISH ENGLISH ON SCREEN LANGUAGE EXIT PRESS Downloaded From Disc-Player.com JVC Manuals...
Page 39: Audio Page
If you connect the analog outputs and digital outputs simultaneously, be sure to select the source of the amplifier correctly, or set the level control of the amplifier connected to the analog outputs to minimum. Downloaded From Disc-Player.com JVC Manuals...
Page 40: Display Page
OFF and a static picture is displayed for a long time. • The screen saver function is not activated when the selected disc is an Audio CD. Downloaded From Disc-Player.com JVC Manuals...
Page 41: System Page
LANGUAGE AUTO STANDBY must set this item RESUME correctly. DVD 1 AV COMPULINK MODE Select from the three EXIT options: “DVD1,” “DVD2” PRESS and “DVD3” according to the equipment to be connected. See page 42. Downloaded From Disc-Player.com JVC Manuals...
Page 42: Limiting Playback By Children
If you enter an undesired password in step 6 above, reenter the PARENTAL LOCK password before pressing ENTER. Country Code — Set Level PASS WORD ---- EXIT PRESS ENTER Press ENTER. moves to [Set Level]. Downloaded From Disc-Player.com JVC Manuals...
Page 43: To Change The Settings [Parental Lock]
If you do not change the password, enter the same password as in the step When you enter the wrong password more than 3 times in step 2 above, moves to [NO] automatically and Downloaded From Disc-Player.com JVC Manuals CURSOR 5/∞ do not work.
Page 44: Additional Information
Sometimes during play noise or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the unit. Downloaded From Disc-Player.com JVC Manuals...
Page 45: Av Compu Link Remote Control System
When you buy a separate TV, VCR, DVD player, receiver, or other component and connect them to each other, you have to operate each component individually. JVC’s AV COMPU LINK remote control system meets the demands of a system made up of single components and has the ease of operation of a single unit.
Page 46: Operation
• Setting the source of the television to the external input (VIDEO-1 or VIDEO-2). • Turning on the power for the receiver. • Setting the source of the receiver to the component which has started playback. Downloaded From Disc-Player.com JVC Manuals...
Page 47: Troubleshooting
Turn off the power and unplug the power lightning or static electricity. cord, then connect the power cord again. Moisture condensation caused by a Turn off the power, then turn it on a few hours sudden change of temperature or later. humidity. Downloaded From Disc-Player.com JVC Manuals...
Page 48: Specifications
20 bit: More than 106 dB 24 bit: More than 106 dB Wow and flutter: Unmeasurable (less than ± 0.002%) Total harmonic distortion: Less than 0.002% * Specifications and appearance subject to change without prior notice. Downloaded From Disc-Player.com JVC Manuals...
Page 49: Table Of Languages And Their Abbreviations
Scots Gaelic Dutch Tatar Galician Norwegian Ukrainian Guarani Occitan Urdu Gujarati (Afan) Oromo Uzbek Hausa Oriya Vietnamese Hindi Panjabi Volapuk Croatian Polish Wolof Hungarian Pashto, Pushto Xhosa Armenian Portuguese Yoruba Interlingua Quechua Zulu Interlingue Rhaeto-Romance Downloaded From Disc-Player.com JVC Manuals...
Page 50: Country Code List For Parental Lock
Korea, Republic of Cocos (Keeling) Islands Ghana Kuwait Central African Republic Gibraltar Cayman Islands Congo Greenland Kazakhstan Switzerland Gambia Lao People’s Democratic Côte d’Ivoire Guinea Republic Cook Islands Guadeloupe Lebanon Chile Equatorial Guinea Saint Lucia Downloaded From Disc-Player.com JVC Manuals...
Page 51 Sao Tome and Principe Mayotte Nicaragua El Salvador Yugoslavia Netherlands Syrian Arab Republic South Africa Norway Swaziland Zambia Nepal Turks and Caicos Islands Zaire Nauru Chad Zimbabwe Niue French Southern New Zealand Territories Oman Togo Panama Thailand Downloaded From Disc-Player.com JVC Manuals...
Page 52: Safety Instructions
— NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case -this could result in a fatal electrical shock.; — NEVER guess or take chances with electrical equipment of any kind -it is better to be safe than sorry! VICTOR COMPANY OF JAPAN, LIMITED Downloaded From Disc-Player.com JVC Manuals 0500RIMUBNJSC...
