Table Of Contents; How To Use Your Shower - Redring Selectronic Handbook

Thank you for choosing a quality "Redring" product manufactured in Peterborough, England.
Contents
User information
How to use your shower...............................................2
Routine Maintenance....................................................5
How your shower works ...............................................6
Troubleshooting ............................................................6
Additional spares & accessories ................................11
Warning
Do Not Switch The Shower On If You Suspect It Of Being Frozen, Wait Until You Are Sure That It Has
Been Completely Thawed Out.

How To Use Your Shower

Your shower has two modes of operation, Normal and Temperature Lock.
The temperature lock feature ensures a factory preset maximum temperature is not exceeded.
This is achieved by disabling the temperature control buttons, so that the less-able, elderly and children can
use the shower with confidence.
The mode of operation is set on commissioning / installation (see page 10). The unit leaves the factory in
temperature lock mode.
Button Function
At The Bottom Of The
Start / Stop
Shower
Above And To The Right Of
Flow
The Start / Stop
Towards The Top Right Of
Warmer
The Shower
Underneath The Warmer
Cooler
Button Following Curve
Normal Operation
Switch On Electricity at ceiling / isolating switch.
Press Start /Stop Button in the centre.
(Confirmed with a single bleep)
The unit will start and the motorised valve will reset. Display will
usually light up number 1.
This will increase until display shows number 6. The average
showering temperature.
When the unit has got close to this setting it sounds a double
bleep and the unit is ready for use.
The unit will only count up and double bleep once per shower
session.
Flow light (green) will be on high.
2
Page
Location
Installer Information
Fixing the shower to the wall ..................................8
Plumbing .................................................................9
Electrical .................................................................9
Commissioning .....................................................10
Guarantee .............................................................12
Shape / Texture
Large, A Raised Pip In The Centre, Made From Soft
Rubber.
Same Shape As The Start / Stop But, Smaller Smooth
With No Raised Pip Recessed. Made From Soft Rubber.
Textured Front And A Central Recess With A Raised Pip
In The Centre. Made From Hard Plastic.
Same Shape As Warmer However Smooth With A Central
Recess, No Raised Pip. Made From Hard Plastic.
Page
fig 1.
