Power Socket
Connect the female connector of the power cord here, and the male
connector to the AC power outlet. Make sure that the voltage of the
power supply meets the requirement of the input voltage (100–240 V~
50/60 Hz).
Alarm Input/Output
Connect to alarm input/output devices using the provided terminal blocks.
Audio Input/Output
Connector for audio input and output.
LAN Ports
Connect to an Ethernet device (eg. router and switch).
VGA
Output port for analog video signals. Connect your monitor to this port if
it uses VGA connection.
HDMI
Output port for high-definition audio and video signals. Connect your
monitor to this port if it uses HDMI connection.
USB 3.0
Connect to additional devices such as USB mouse, USB storage device,
and USB keyboard.
Kensington Security Slot
Secure the lock (not provided) into the security slot to prevent the device
from being stolen.
Grounding Terminal
The NVR already comes with lightning protection mechanism. You can
also ground the NVR through the PE (Protecting Earth) cable of AC cord
or with Ground Cable. For detailed lightning protection measures, go
to https://www.tp-link.com/support, search the model number of your
NVR and go to the product Support web page, refer to the Lightning
Protection Guide from the Related Documents:
https://www.tp-link.com/us/configuration-guides/lightning_protection_
guide/.
Caution:
Please use the provided power cord.
