B
This appendix describes the specifications and configuration
options for the 3C689 adapter.

Cabling

The 3C689 adapter supports industry-standard token ring
cabling that follows IEEE 802.5 specifications. Use Type 3
(UTP) or Types 1 or 6 (STP) cabling.

Physical Dimensions

Length:
Thickness:
Width:
Weight:

Environmental Operating Range

Operating temperature:
Relative humidity:

Power Requirements

Operating voltage:
FCC Certification
Part 15, Class A
S
PECIFICATIONS
3.370 in. (85.6 mm)
Type II, 0.197 in. (5.0 mm)
2.126 in. (54 mm)
1.49 oz. (42.5 g)
(32 to 131 ˚F) 0 to 55 ˚C
10 to 90% noncondensing
+5 V ± 5% @ 0.3 A
