IMPORTANT
Carefully remove all the parts from the carton and place them
individually on a soft cloth to prevent scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
This product is made of aluminum. Do not use power tools
above 8 volts to assemble and only tighten bolts until snug.
Over tightening can damage the aluminum.
Part List
Hardware List
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
home
6730-90
Ottoman
A.
Seat
1 pc.
B.
Side
2 pcs.
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
Spring Washer
10 pcs. (+1 extra)
M6x35
Head Cap Bolt
10 pcs. (+1 extra)
888-680-7460
C.
Cushion
1 pc.
Cap
10 pcs. (+1 extra)
Flat Washer
10 pcs. (+1 extra)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Homestyles 6730-90
Summary of Contents for Homestyles 6730-90
- Page 1 6730-90 Ottoman IMPORTANT Carefully remove all the parts from the carton and place them individually on a soft cloth to prevent scratches or other damage. Carefully and strictly follow these assembly instructions to ensure a completed product as designed. This product is made of aluminum. Do not use power tools above 8 volts to assemble and only tighten bolts until snug.
- Page 2 Assembly Instructions 2/3 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ Keep Hex Wrench as the bolts may need to be tightened in the future.
- Page 3 Assembly Instructions / 3 3 Velcro Velcro STEP 3 Turn Cushion (C) upside down. Use velcro on Cushion (C) to attach to unit. (See Figure 3) Figure 3 STEP 4 Turn over unit to it’s upright position.
- Page 4 CARE INSTRUCTIONS NEVER NEVER use glass cleaners on allow liquids to remain on furniture. finished furniture. Ammonia Absorption causes parts to warp chemically attacks the finish. and split and finishes to delaminate. Do not use power tools Do not place Do not write above 8 volts to assemble.
