IMPORTANT
Carefully remove all the parts from the carton and place them
individually on a soft cloth to prevent scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
This product is made of aluminum. Do not use power tools
above 8 volts to assemble and only tighten bolts until snug.
Over tightening can damage the aluminum.
Part List
A.
Top
1 pc.
Hardware List
Rotating Ratchet
1 pc.
Tool(s) required for assembly: Level
home
6730-836
Table
styles Customer Service: www.homestylesfurniture.com,
servicedesk@homestylesfurniture.com,
01
Head Cap Bolt
10 pcs. (+1 extra)
02
Spring Washer
10 pcs. (+1 extra)
B.
Side
2 pcs.
03
Flat Washer
10 pcs. (+1 extra)
04
Cap
10 pcs. (+1 extra)
888-680-7460
05
Cover
1 pcs.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Homestyles 6730-836
Summary of Contents for Homestyles 6730-836
- Page 1 6730-836 Table IMPORTANT Carefully remove all the parts from the carton and place them individually on a soft cloth to prevent scratches or other damage. Carefully and strictly follow these assembly instructions to ensure a completed product as designed. This product is made of aluminum. Do not use power tools above 8 volts to assemble and only tighten bolts until snug.
- Page 2 Assembly Instructions 2/3 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the bolts until each part is properly assembled. Ÿ Keep Rotating Ratchet as the bolts may need to be tightened in the future.
- Page 3 Assembly Instructions / 3 3 STEP 2 Attach Side (B) to unit with 01 02 5 pcs. of tightening only halfway. Tighten up all of Cover 10 pcs. of with (See Figure 3) Figure 3 STEP 3 Turn over unit to its upright position. Level table by adjusting the adjustable levelers on bottom of legs.
- Page 4 CARE INSTRUCTIONS NEVER NEVER use glass cleaners on allow liquids to remain on furniture. finished furniture. Ammonia Absorption causes parts to warp chemically attacks the finish. and split and finishes to delaminate. Do not use power tools Do not write above 8 volts to assemble.
